WITH USB CHARGING STATION
MODEL CL030055 SERIES
Please read this instruction manual before using your new clock.
SECTION 1
MAIN FEATURES
The following buttons (except
functional only when the clock is powered with the DC adaptor.
TOP VIEW
FRONT VIEW
BACK VIEW
C
M
Y
CM
MY
CY
1.
button
CMY
• Press this button to turn off the LED display or decrease the
K
display's brightness.
• In time setting mode and alarm time setting mode,
press this button to decrease the value. Press and hold to
decrease the value rapidly.
2.
button
• Press this button to turn on the LED display or increase the
display's brightness.
• In time setting mode and alarm time setting mode,
press this button to increase the value. Press and hold to
increase the value rapidly.
button)
3.
• Press this button to view the alarm time.
• Press and hold this button, then press
alarm time.
• When the alarm sounds, press this button to turn off the current
alarm and turn on the snooze function.
4.
slide switch
• Slide this switch to turn off or on the alarm function.
5. 2 USB ports
6. DC jack
• Connect the DC adaptor to power the clock.
7.
button
RESET
• In case of a malfunction, press this button with a metal pin to
reset all values.
8. Battery compartment
• Accommodates 3 AAA batteries as a backup power source.
9.
button
• This button adds or subtracts one hour from the current time.
1
2018-07-03
10:13 AM
LED CLOCK
and
buttons) are
RESET
or
to set the
10.
button
• In normal time mode, press and hold this button to enter time
setting mode. Release the button to save the time and exit time
setting mode.
11.
slide switch
12 / 24
• Slide this switch to the "12" position to display the time in
12-hour format.
• Slide this switch to the "24" position to display the time in
24-hour format.
SECTION 2
POWERING ON
1. The clock must be powered by the DC adaptor. The 3 AAA
batteries are used only as a backup power source for the time
and alarm settings.
2. After powering on or resetting the clock, all LED segments will
be shown for 2 seconds. Then the clock will revert back to
normal time mode and display the time.
NOTE:
If nothing is visible on the LED display, please make sure the clock
is connected to an electrical outlet using the DC adaptor. Then,
press the
button with a metal pin.
RESET
SECTION 3
DISPLAY SYMBOLS
NORMAL TIME MODE
1. Normal time
ALARM TIME MODE
1. Alarm time
2. Alarm mode icon / Alarm on
SECTION 4
TIME SETTING
1. In normal time mode, press and hold the
the digits flash. While holding the
button or the
button to set the desired value.
2. Release the
button to save the time and exit time
setting mode.
Normal time mode
NOTE:
Press and hold the
button to increase the value rapidly.
Press and hold the
button to decrease the value rapidly.
SECTION 5
DAYLIGHT SAVING TIME
1.
Press the
button to activate the daylight saving time
function. One hour will be added to the current time.
2. Press the button again to deactivate this function. One hour will
be subtracted from the current time.
1
MANUAL
ENGLISH
button until
button, press the
Time setting mode
