Evikon PluraSens E2608-NO User Manual

Nitric oxide
Colourless toxic gas, relatively insoluble in water. When exposed to oxygen
(including air), nitric oxide is converted into nitrogen dioxide.
Chemical formula NO
Molar weight 30
Relative gas density (to air) 1.03
Conversion 1 ppm = 1.23 mg/m
Boiling point -152 °C
Flammability Nonflammable, but accelerates the
burning of combustible materials.
Odour Pure NO is odourless, but in the air it
oxidizes to NO
odour
Hazards Irritates respiratory tract and eyes, at
high concentrations may cause lung
edema and death.
Exposure limits TWA 30 mg/m
(Directive 91/322/EEC)
IDLH (NIOSH) 123 mg/m
Conversion of ppm to mg/m 3 is calculated for 25°C and 1 atm.
Installation guidelines
(See Installation and connections section for general information.)
Nitric oxide has practically the same density as air. As it is easily oxidized to form
nitrogen dioxide, the sensor should be placed as close as possible to the gas source.
Calibration
E2608-NO detectors have been calibrated by Manufacturer with standard gas
mixtures before delivery. Provided that the sensor is used under moderate
conditions,the recommended interval for field recalibration is 6 months. Please
contact your dealer for more information.
Maintenance
Do not perform any maintenance operation with the power on.
Clean the device with soft damp cloth. Do not use any abrasive cleaning agents. Do
not immerse the device into water or any cleaning media.
Delivery set
–Detector-transmitter E2608 (wall mount or duct mount version)
– Mounting accessories:
4 cross-shaped mounting lug with screws and 4 screws with plastic dowels for wall
mount version
rubber flange for duct mount version
fixing clamp for remote probe versions
E2608-NO_UM_EN
Specifications
Sensor type
Sampling method
Typical detection range
Maximum overload
3
Resolution / digital unit
Response time T90
Sensor lifetime
Calibration interval
which has a pungent
2
Signal update
Power supply options
Power consumption
3 /25 ppm
Load resistance
3 /100 ppm
Digital interface
Analog outputs
Outputs assignment
Output scale width
Relay otputs
Default alarm setpoints
Cable connections
Enclosure
Dimensions
CE marking
Operating conditions
Warranty
This product is warranted to be free from defects in material and workmanship for a
period of one year from the date of original sale. During this warranty period
Manufacturer will, at its option, either repair or replace product that proves to be
defective. This warranty is void if the product has been operated in conditions outside
ranges specified by Manufacturer or damaged by customer error or negligence or if
there has been an unauthorised modification.
Evikon MCI OÜ
Tel. +372 733 6310
Rev 06.06.2020
electrochemical cell
diffusion
0...250 ppm
1000 ppm
1 ppm
< 40 s
> 12 months
6 months
every 1 second
11...30 VDC, 24 VAC
or 90...265 VAC (with mains power unit)
< 2 VA
R < (Us - 2 V) / 22 mA for 4-20 mA
L
R > 250 kOhm for 0-10 V mode
L
RS485, Modbus RTU protocol
no galvanic isolation
2 × 4-20 mA / 0-10 V, user settable
OUT1 2 gas; OUT2 2 gas
> 10 × resolution
Recommended: 20-100% of the detection range
2 × SPST, max 5 A, 30 VDC / 250 VAC
RE1 (LOW): set 10 ppm, release 8 ppm
RE2 (HIGH):set 25 ppm, release 20 ppm
screwless spring loaded terminals
grey ABS, wall mount, protection class IP65
H85 × W82 × D55 mm
according to 2014/30/EU and EN61326-1 requirements
-30...50 °C, 15...90% RH non-condensing, 0,9...1,1 atm
explosion safe indoor areas, non-aggressive atmosphere
NOTE The sensor may exhibit considerable sensitivity to
hydrogen sulfide and nitrogenr dioxide
Teaduspargi 7/9, Tartu info@evikon.eu
50411 Estonia www.evikon.eu
Nitric Oxide Detector-Transmitter
