Extech Instruments 461960 User Manual page 10

461955 Proximity Sensor Specifications (23±5 °C)
Output method
Sensing direction
Sensing distance
Operating voltage
Standard Sensing object
Current consumption
Response frequency
Output current
Leakage current
Residual voltage
Operating Temperature
Operating Humidity
Wire Dimension
Cable length
461957 Photoelectric Sensor Specifications
Range
Power
Response time
Output
Photo beam color
Photo beam wavelength
Cable length
E
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176
FAX 781.665.0780 - TestEquipmentDepot.com
PNP, NO(normal open)
Vertical.
4 mm.
10-30 VDC.
Iron 18 x 18 x 1 mm.
8 mA, no load.
600 Hz.
250 mA max.
1.1 mA.
0.9 VDC.
-4 to 158°F (-20 to 70 °C)
35 to 95% RH.
4.7 mm Dia. x 2 m x 3 cores.
6 ft (1.8 meters)
Up to 6000 RPM (100 Hz)
12 - 24VDC ±10%; Consumption: 40mA max.
< 1ms
NPN transistor; Max load 80mA
Green
5500 Angstroms
6 ft (1.8 meters)
