Egholm 2001 Operator's Manual

Salt & sand spreader
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OPERATOR'S MANUAL
Salt & Sand Spreader
90101371-03 UK

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Egholm 2001

Summary of Contents for Egholm 2001

  • Page 1 OPERATOR’S MANUAL Salt & Sand Spreader 90101371-03 UK...
  • Page 2 Reservations: As it is the Egholm policy to make continuous improvements, we reserve the right to alter the specifi- cations and equipment at any time without notice. Egholm Maskiner A/S accepts no liability for errors or shortcomings in the operator’s manual.

  • Page 3: Table Of Contents

    CONTENTS 1. General information Page: Safety..........Technical data.

  • Page 4: General Information

    1. GENEREL INFORMATION 1 General information The Salt and Sand Spreader was designed especially for the Egholm 2100. It will ensure winter maintenance by use of salt, sand, gravel and grit. The Salt and Sand Spreader can ideally be combined with the Dozer Blade, the Snow Blower and the Snow Sweeper.

  • Page 5: Safety

    1. GENEREL INFORMATION 1.1 Safety M M o o u u n n t t i i n n g g : : Before mounting the Salt and Sand Spreader, check that the console cover is closed and locked. (Picture 1) Make sure the Salt and Sand Spreader is mounted correctly and that the locking handle is left in locked position.
  • Page 6 1. GENERAL INFORMATION S S a a f f e e t t y y g g r r a a t t i i n n g g : : Never use the Salt and Sand Spreader unless the container is covered by a meshed grid safety grating.

  • Page 7: Technical Data

    1. GENERAL INFORMATION 1.2 Technical data M M o o u u n n t t e e d d : : Length: 2225 mm Width: 1015 mm Height: 1265 mm Weight: 574 kg D D i i s s m m o o u u n n t t e e d d o o n n r r o o l l l l e e r r s s t t a a n n d d : : Side view Length: 1175 mm...

  • Page 8: Instructions For Use

    2. INSTRUCTIONS FOR USE 2.1 Assembly of the roller stand On delivery, you will find the roller stand collapsed. Before use the roller stand is to be assembled as follows: A) Unpack and unfold the roller stand. B) Assemble the roller stand with the two bolts included and it is ready for use.

  • Page 9: Start-Up

    2. INSTRUCTIONS FOR USE G) Make sure that the locking handle is left in locked position - the Salt and Sand Spreader is locked in place. (Picture 1). Pull the Salt and Sand Spreader to test a correct fit - it must not move. H) Connect the hydraulic hoses: If mounted, disconnect the snap couplings of the rear lifter.

  • Page 10: Adjustment

    2. INSTRUCTIONS FOR USE 2.4 Adjustment A A m m o o u u n n t t s s p p r r e e a a d d : : To adjust the amount spread, turn the front knob on the left-hand side of the spreader.

  • Page 11: Assembly/Disassembly Of The Stirrer System

    2. INSTRUCTIONS FOR USE 2.5 Assembly/disassembly of the stirrer system The stirrer system is necessary when spreading wet sand and is recommended for spreading sand and salt. We do not recommend the stirrer system when spreading grit or gravel as this material can be too heavy for the stirrer system.

  • Page 12: Important

    2.7 Field of application The Salt and Sand Spreader is only to be used with the Egholm Powerflex or the Egholm 2100. Do not use the Salt and Sand spreader as a lime or fertilizer spreader.

  • Page 13: Service And Maintenance

    3. SERVICE AND MAINTENANCE 3.1 Cleaning Daily cleaning will extend the life of the Salt and Sand Spreader significantly and ensure correctly functioning parts. D D a a i i l l y y c c l l e e a a n n i i n n g g : : A) Remove and clean the snap couplings.
  • Page 14 3. SERVICE AND MAINTENANCE P P e e r r i i o o d d i i c c / / I I n n - - d d e e p p t t h h c c l l e e a a n n i i n n g g : : At the end of the season or when storing the spreader for a longer period of time, corrosion prevention is essential.

  • Page 15: Conditions

    Maskiner A/S has no control. The scope of warranty: 1) The Egholm warranty is only valid on presen- tation of the original receipt supplied with model description, serial number and date of purchase.

  • Page 16: Conditions Of Complaint

    We wish you many years of safe and satisfied use of your machine. Best regards Egholm Maskiner A/S - Transportvej 27 - DK -7620 Lemvig, telephone: +45 97 81 12 05, fax: 97811210 4.3 Disposal When —...

  • Page 17: Ec Declaration Of Conformity For Machinery

    - has been manufactured in conformity with- the provisions of the Machinery Directive, Directive 98/37/EU The Egholm 2100 fitted with the cab FH 2100 (ROPS approved) - has been tested at the Danish Institute of Agricultural Sciences at Bygholm in conformity with directive 86/298/EEC concerning rear mounted, roll-over pro- tection structures of narrow-track wheeled agricultural and forestry tractors.
  • Page 18 4. NOTES...
  • Page 19 4. NOTES...
  • Page 20 Egholm Maskiner A/S . Transportvej 27 . DK - 7620 Lemvig Tel.: (+45) 97 81 12 05 . Fax (+45) 97 81 12 10...
