DMT LS-120 User Manual

Hide thumbs Also See for LS-120:
Table of Contents

Advertisement

Quick Links

LS-120 Video Processor
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LS-120 and is the answer not in the manual?

Questions and answers

Related Manuals for DMT LS-120

Summary of Contents for DMT LS-120

  • Page 1 LS-120 Video Processor User Manual...
  • Page 2 CONTACT US Address:Vestastraat 26468 EX Kerkrade The Netherlands Phone: +31 45-5667723 Fax: +31 45-5667724 Email: aftersales@highlite.nl Revision Format Time ECO# Description Principal 2011-06-10 0000 Release Bing 2011-12-21 Change output connector: previous VGA connector has been replaced by DVI connector.(Reuse with VGA output )

  • Page 3: Table Of Contents

    CONTENT     1.0 Safety ................... 1 2.0 Specification .................. 2 3.0 Parameters ..................2 4.0 Connectors and cables ..............4 4.1 LS 120 connectors and signals ............ 4 4.2 LS 120 size and installation ............6 5.0 Front Panel Keyboard Operation ............7 5.1 LS 120 Operator Guideline ............

  • Page 4: Safety

    It is forbid to pour liquid, metal fragment or anything else inside this device to avoid fire and other accident. Once that happens, must remove power cord and try to make it clean before power on again. LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...

  • Page 5: Specification

    2.0 Specification DMT series video processors are designed by the latest high performance image processing technology. LS 120 can handle following video without limit, include CVBS（Composite）、S-Video (YC)、YCbCr、YPbPr、RGBHV（VGA）、 DVI-D、HDMI、SDI（SD-SDI、HD-SDI） and USB. 3.0 Parameters Composite BNC Input Number of Inputs Supported PAL/NTSC...
  • Page 6 Support yearly, monthly, weekly and daily schedule Schedule function without PC runs to control in real time Extras Communication RS232 USB TCP/IP Power Supply 85-264V 2A IEC-3 Working 0°C~45°C Environment Stored 10% to 90% Environment Product Warranty 1 year LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...

  • Page 7: Connectors And Cables

    Such as USB disk, Portable Hard Disk 16: DVI input interface. Input the video signal from computer, DVI signal generator. Connect to the DVI 1 interface on LS 120（This Connection does not comment hot-plugging）; LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 8 19. Via adapter, can connect with DVI-based or VGA-based equipment, and via DVI to VGA adapter, can output VGA only. 20,21: Switch and power. It must use IEC-3 power line. Always ground to avoid electric shock. LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...

  • Page 9: Ls 120 Size And Installation

    4.2 LS 120 Size and installation LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...

  • Page 10: Front Panel Keyboard Operation

    FS： Switch to select full screen or zoom view,just for single picture mode; SAVE1： Switch to use the user-defined mode1; SAVE2： Switch to use the user-defined mode2; SAVE3： Switch to use the user-defined mode3; SCALE: Push to go to between Hsize Vsize HPOS VPOS; LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...

  • Page 11: Ls 120 Video Processor Menu

    Sel key to enter it. The first line shows LS 120.Select Dev Info, it shows current input signals. If there is a composite input to CV1, the NO INPUT will show as the input composite format, such as 720*576i. As shown; INPUT: CV1 NO INPUT LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 12 Software Version Push UP/DOWN to check current Video Processor serial number to get more available service and support; DMT DUTCH MEDIA TOOLS > SN：J0004 Push UP/DOWN direction, select RECALL to recall factory reset.after successful factory reset you will see the menu as shown;...
  • Page 13 Push UP/DOWN direction to live time set-up. it shows * signal, the current revised will flash; Time *00:00:20 Push SEL to set Calendar, the left side shows calendar, right side shows the English Abbreviation of the day of the week. LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 14 Touch UP / DOWN, find Advance in the 【MENU】 to do advanced split screen set; >LS 120 Scale *Advanve Click on SEL to enter into Advanced settings, Touch UP / DOWN to set the coordinate, width and height, as following pictures: LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 15 Push OUT to enter output format menu; push UP/DOWN to choose different output formats, and SEL the needed output format. Output Format: >1920x1080x60 Push SAVE menu, it turns SAVE1/SAVE2/SAVE3 Save Setting To: Press ESC To Exit LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 16 Save successfully and push SAVE1 to call SAVE1 user config mode;Push SAVE2 and SAVE3 to call another two seperately. added SAVE notice function; when push SAVE, all SAVE1/SAVE2/SAVE3 will light on,users should push SAVE1/SAVE2/SAVE3 to save successfully. LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...

  • Page 17: Communication Software Guideline

    User can also customize with schedule function. 6.1 Install Software Dual click DMT.exe to run install, select Chinese or English version for end user，and click “select ” to go on. Please read carefully the license of agreement before installing LS 120 console software, select the "Agree"...
  • Page 18 After agree to the agreement, user can select install directory in the next dialog, and click next to install software to default directory “C:\Program Files” directly. Click “next ”to go on. Click “next ”to go on. LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 19 Click “next ”to go on. LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 20 Click “finish” and ready to run LS 120 console. LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...

  • Page 21: Run Ls 120 Console

    6.2 Run LS 120 Console First run software will auto detect device in serial or networks by Comm port and pro-define IP address. The software as following: LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 22 Hardware Device Manager in the system attributes dialog. The COM in red in the picture is the COM user can make choice. Then click to open COM. will display after success to connect the COM. LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 23 How to use Operator can check parameters by software. ：Save script. Save current user config parameters as script. ：Open script. User can open saved script. ：Import template. There are six templates for user. LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 24 If user choose open device when start, user can use last run config, use script file or none when user start. User can click to choose which script user want to open. If user choose execute schedule when start, the next dialogue will display when software run. LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 25 : Open COM. : Close COM. : Set COM. : Search Device Device ：Synchronization; Click the button to synchronize setting parameters on device and PC software, as well as data for EPROM splitting mode. ：Save to flash LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 26 ：Advance, for administrator control.This is only open to Technical Engineer, please contact us to get password if needed. : VGA Adjust: push this button to set auto adjustment for VGA inputs Help ：Help. Click to open helps file. LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 27 Aspect Ratio: user can push pull down menu and select to switch between 4：3, 16：9 and normal； Input: the white area displays the name of input interface when the mouse is over the interface picture on the left. The orange pane means current selected interface. LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 28 Output: user can customize the brightness and the contrast. Media player menu: click the files in the list can play the media files directly, and can also select the files need to play, LS 120 will run the files LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 29 (images) in this area. This process can sync to the parameters in images toolbars. As following，There are 1~3 user Mode for you to recall. Log: user can save or delete the operate log file LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 30 Additional functions Device IP Users can set equipment IP, Usually used under the condition of one computer control or remote control several computers. LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 31 4. Set the play time for each file (which work by play index); 5. Set the repeat time for each file, which can be control from pull down menu or input times directly; 6. Set the input source control in Play Source position; LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 32 Remember to set the Device Date Time to the same to the local time, and after set, can check also on the front panel LCD module. After factory reset, all schedule function need to set again. LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...

  • Page 33: Faq

    2）check DVI input resolution is not of LS 120 Console support list , as following the biggest input resolution is 1024*768*60Hz 3）Check LS 120 work in DVI input mode 4）Check the connection between LS 120 and DVI source is correct. Restart DVI sourse and check output LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...

  • Page 34: User Settings Can Not Save

    1 otherwise,”SAVE1”will be over write. 3）Recognized in the implementation of the save operation, the user is not saved for other operations again Any requirement , please feel free to contact our customer service engneer LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...

  • Page 35: How To Control Processor With Console Softwore By Usb

    120,for the first time to use USB , the PC will remind finding the new hardware and ask to install the driver for this new driver Install from the list or specified location ,press “NEXT” Press “browser” to find the driver, and press “NEXT” LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 36 When the installation finish,can go to check the installed COM port inside the device mangement ,as following picture show” LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 37 2.Install the console software, and run after install,shows the interface of the console as following ： Set the RS232 as installed just now, and set the LS 120 Boud Rate to be :115200 LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 38 ,and you can use the software to control the device now ; If power off during communication,should close the port by first , and plug in out of the USB and do communication again LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...

  • Page 39: Appendix

    First, users can choose the right serial port ,set the baud rate to 9600, choose LPC2368, and to load the aim document(hex.document )of Ipboard upgrading secondly , confirm the two option box by tick. Finally,click the “start”button LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
  • Page 40 After download , exit the program ,turn off the power ,tack the two coding switch back ,as below restart the equipment power ,check if the equipment work normally . Go to the link to download flash magic toolset. http://www.flashmagictool.com/download.html&d=FlashM agic.exe LS-120 User Manual Doc. No：RGB-RD-UM-V112E001...
