- Page 1 User Manual P726T0002, valid for P-726.1CD CBo, 6/10/2020 P-726.1CD PIFOC High-Load Objective Scanner Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws...
-
Page 2: Table Of Contents
Ambient Conditions and Classifications ......................14 Dimensions ................................ 15 Pin Assignment ..............................16 Old Equipment Disposal Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 2 / 17 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws... -
Page 3: About This Document
5. Click the desired manual and fill out the inquiry form. The download link will then be sent to the email address entered. Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 3 / 17 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws,... -
Page 4: Safety
It is only possible to use the P-726 as intended in a completely assembled and connected state. The P-726 must be operated with a suitable controller that is available from PI. The controller must provide the required operating voltages. To ensure proper performance of the servo- control system, the controller must also be able to read out and process the signals from the position sensors. - Page 5 Set the piezo voltage to 0 V on the controller. Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 5 / 17 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws,...
-
Page 6: Product Description
1 Turret ring of the QuickLock adapter (to be ordered separately) 2 Knurled ring 3 Base body 4 Connecting cable Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 6 / 17 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws... -
Page 7: Scope Of Delivery
LEMO connectors (1 × voltage, 2 × sensor). To order, contact our customer service department (p. 12). Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 7 / 17 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws,... -
Page 8: Installation
Only moderate torque is required to fix the objective ring in the PIFOC body. Use the key tool supplied for tightening the objective ring. Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 8 / 17 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws,... - Page 9 PIFOC. Fig. 7: Screwing the knurled ring onto the PIFOC Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 9 / 17 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws,...
-
Page 10: Startup And Operation
Loosen any screws only when instructed in this manual. Do not open the P-726. Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 10 / 17 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws,... -
Page 11: Cleaning The P-726
(not shown). Grip the tool by hand only. Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 11 / 17 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws,... -
Page 12: Customer Service
Fig. 11: Objective ring with recesses inside PIFOC can be loosened with key tool Customer Service For inquiries and orders, contact your PI sales engineer or send us an email (service@pi.de). If you have any questions concerning your system, provide the following information: −... -
Page 13: Technical Data
All specifications based on room temperature (22 °C ±3 °C). Ask about customized versions. Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 13 / 17 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws,... -
Page 14: Maximum Ratings
Degree of pollution Degree of protection IP20 according to IEC 60529 Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 14 / 17 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws... -
Page 15: Dimensions
CBo, 6/10/2020 Dimensions Dimensions in mm. Figure 12: Dimensions of the P-726.1CD Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 15 / 17 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws... -
Page 16: Pin Assignment
(movable part of the capacitive sensor) The cable shield is connected to the connector shell. Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 16 / 17 Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws,... -
Page 17: Old Equipment Disposal
Dispose of your old equipment according to international, national, and local rules and regulations. In order to fulfil its responsibility as the product manufacturer, Physik Instrumente (PI) GmbH & Co. KG undertakes environmentally correct disposal of all old PI equipment made available on the market after 13 August 2005 without charge.
