Installation Overview - Napoleon Ascent Linear Series Installation Manual

general information
EN
1.3

installation overview

1
9 4 2 5
10 6 3
8 7
Recommended installation steps:
1. Determine venting requirements before deciding the fi nal location of the appliance.
2. Install rough framing (refer to "rough framing" section).
3. Place the appliance in its fi nal position.
4. Install nailing tabs (refer to "nailing tab installation" section).
5. Install appliance venting (refer to "venting installation" section).
6. Install all electrical wirings (refer to "electrical information" section).
7. Install gas lines (refer to "gas installation" section).
8. Test appliance.
9. Complete framing (refer to "fi nish framing" section).
10. Finishing (refer to "fi nishing" section).
7
W415-2757 / B / 01.09.20
