Aspire Comfimotion LUXE KS Quick Setup Manual

QUICK SETUP GUIDE
ASPIRE COMFIMOTION BED COLLECTION
This guide is intended to explain the correct set up procedures for the Aspire Comfimotion Bed Collection
upon installation. For further installation and operating instructions, refer to the product User Manual.

1. ADJUSTABLE BEDS

2. HEADBOARDS

ASSEMBLY OF COMFIMOTION BED (CARE AND LUXE)

Remove bed from carton and position on flat surface or a Bed Moving Trolley for easy setup. Ensure the bed is
1.1
placed TOP DOWN, so all components (hand control, retainers, castors & power cord) can be removed easily
from the underside of bed.
1.2
Using a box cutter, unhook all components from the base of the bed (retainers, power cord, hand control and castors).
Retainers
Install castors onto all 4 x corners of bed, securing in place with a 12mm spanner.
1.3
NOTE: 75mm Castors shown. When fitting larger castors, the process is the same.
1.4
Connect hand control into control box port (CARE bed only).
LUXE (KS) BEB046710
CARE (LS) BEB046720
CARE (KS) BEB046730
ALLURE (LS) BEA830120
ALLURE (KS) BEA830130
CHESTERFIELD (LS) BEA830100
CHESTERFIELD (KS) BEA830110
When opening the carton, ensure it
is done in a safe and careful manner.
DO NOT USE a box cutter or sharp
implement as this may damage the
product.
Hand Control
NOTE: LUXE Bed has a wireless Hand Control,
no need to connect to Control Box.
Castors Power Cord
