2 in 1 Hedge Trimmer
Please read and retain these instructions for future reference
Technical Data
Factory Code:
Voltage/Frequency:
Input Power:
No Load Speed (Hedge Trimmer)
Maximum Overall Length with 35mm Aluminium
Telescopic Pole
Minimum Overall Length with Telescopic Pole
Length of Cutter Blade:
Maximum Diameter Cut of the reciprocating
Hedge Trimmer Blade
Minimum reach of Hedge Trimmer with
pole/without pole:
Net weight:
Gross weight:
Length of Power Cable:
Noise Level:
Vibration Level:
Main Body Casing Material:
Trimmer Head Adjustment:
Switch Type:
Page No. 1
G339
Instructions for Use
M1E-10ET-460
230V-240V/50Hz, IP20
550W
1600/rpm
2.45m
1.85m
460mm (cutting Length)
16mm
2.21m/1.05m
4.25kg
4.5kg
10m
96dB
2
3m/s
ABS Material
Trimmer head can be adjusted from -67.5° to
+45° vertically in 6 positions.
Double safety switch
v001: 15/10/19
Advertisement
Table of Contents
Related Manuals for Coopers of Stortford G339
Summary of Contents for Coopers of Stortford G339
-
Page 1: Technical Data
2 in 1 Hedge Trimmer G339 Instructions for Use Please read and retain these instructions for future reference v001: 15/10/19 Technical Data Factory Code: M1E-10ET-460 Voltage/Frequency: 230V-240V/50Hz, IP20 Input Power: 550W No Load Speed (Hedge Trimmer) 1600/rpm Maximum Overall Length with 35mm Aluminium 2.45m... -
Page 2: Table Of Contents
2 in 1 Hedge Trimmer G339 Instructions for Use Please read and retain these instructions for future reference v001: 15/10/19 Contents: Technical Data ............................1 Intended Use ............................2 Explanation of symbols on your product ....................2 Safety instructions ..........................3 Part Identification .......................... -
Page 3: Safety Instructions
2 in 1 Hedge Trimmer G339 Instructions for Use Please read and retain these instructions for future reference v001: 15/10/19 Do not expose to rain. Do not leave the product outdoors while it is raining. The use of eye protection is recommended. - Page 4 2 in 1 Hedge Trimmer G339 Instructions for Use Please read and retain these instructions for future reference v001: 15/10/19 Electrical safety: a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adaptor plugs with earthed power tools.
- Page 5 2 in 1 Hedge Trimmer G339 Instructions for Use Please read and retain these instructions for future reference v001: 15/10/19 d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
- Page 6 2 in 1 Hedge Trimmer G339 Instructions for Use Please read and retain these instructions for future reference v001: 15/10/19 Your electric cable must be untangled. Tangled cables can overheat and reduce the efficiency of your product. Always switch off at the mains before disconnecting any plug, cable connector or extension cable.
-
Page 7: Part Identification
2 in 1 Hedge Trimmer G339 Instructions for Use Please read and retain these instructions for future reference v001: 15/10/19 MAINTENANCE AND STORAGE: RISK OF INJURY! Do not touch blades. When finishing or interrupting work fit protective cover. -
Page 8: Assembly
2 in 1 Hedge Trimmer G339 Instructions for Use Please read and retain these instructions for future reference v001: 15/10/19 ASSEMBLY Unpacking This product requires assembly. Carefully remove the product from the box. Inspect the product carefully to make sure no breakage or damage has occurred during shipping. - Page 9 2 in 1 Hedge Trimmer G339 Instructions for Use Please read and retain these instructions for future reference v001: 15/10/19 Tighten with locking knob. Make sure that connection is secured tightly. (see Fig. 2). 3. Insert the guard (8) into the socket as illustrated in Fig. 3, and use the two screws to fix the guard in place (see Fig.
-
Page 10: Application Range
2 in 1 Hedge Trimmer G339 Instructions for Use Please read and retain these instructions for future reference v001: 15/10/19 Tighten with locking knob. Make sure that connection is secured tightly (see Fig. 5) 6. Tighten with locking knob. Make sure that connection is secured tightly (see Fig. 6). -
Page 11: Operation
2 in 1 Hedge Trimmer G339 Instructions for Use Please read and retain these instructions for future reference v001: 15/10/19 OPERATION: WARNING: Do not allow familiarity with this product to make you careless. Remember that a careless fraction of a second is sufficient to inflict serious injury. - Page 12 2 in 1 Hedge Trimmer G339 Instructions for Use Please read and retain these instructions for future reference v001: 15/10/19 Adjusting the Telescopic Extension Handle length The hedge trimmer has a telescopic handle that will extend from 1.85m (fully retracted) to 2.45m (fully extended).
-
Page 13: Maintenance And Servicing
2 in 1 Hedge Trimmer G339 Instructions for Use Please read and retain these instructions for future reference v001: 15/10/19 5. Use both hands to grip the trimmer. Use designated grip areas and strap when operating the trimmer (see Fig. 10). Use a firm grip. Thumbs and fingers must wrap around trimmer handle and the extension handle. - Page 14 2 in 1 Hedge Trimmer G339 Instructions for Use Please read and retain these instructions for future reference v001: 15/10/19 PLUG WIRING (UK & IRELAND) This appliance is fitted with a BS 1363 13-amp plug. If you have to replace the fuse, only those that are ASTA or BSI approved to BS1362 and with a rated current of 13-amps should be used.
-
Page 15: Declaration Of Conformity
Please read and retain these instructions for future reference v001: 15/10/19 DECLARATION OF CONFORMITY Coopers of Stortford that the 2 in 1 Hedge Trimmer G339 (Model No. M1E-10ET-460) Conforms to the following European Directives and standards: Machinery Directive 2006/42/EC ...
