Electric Pole Hedge Trimmer
Please read and retain these instructions for future reference
Voltage/Frequency
Input Power
Tooth gap of cutter blade
Strokes
Noise emission value LWA
Hand / arm vibration a vhw
Total Length
Length of cutter blade
Weight
Product Identification:
Page No. 1
10597
230V-240V a.c./ 50Hz
450W
16mm
1,600/min
100 dB(A)
< 2.5 m /s2
1.9m-2.5m (M1E-8ET-410)
M1E-8ET-460
460mm
M1E-8ET-460
4.5Kg
Instructions for Use
v001: 01/11/16
CONTENTS:
1. Protect Cover
2. Cutter Blade
3. Protect Bar
4. Power Head
5. Adjust Button
6. Link Handle
7. Locking Knob
8. Former Pole
9. Locking Knob
10. Collet
11. Under Pole
12. Grip Area
13. Grip Area
14. Buckle
15. Switch Lockout
16. Trigger
17. Handle
18. Plug
Advertisement
Table of Contents
Related Manuals for Coopers of Stortford 10597
Summary of Contents for Coopers of Stortford 10597
- Page 1 Electric Pole Hedge Trimmer Instructions for Use 10597 Please read and retain these instructions for future reference v001: 01/11/16 Voltage/Frequency 230V-240V a.c./ 50Hz Input Power 450W Tooth gap of cutter blade 16mm Strokes 1,600/min Noise emission value LWA 100 dB(A) Hand / arm vibration a vhw <...
-
Page 2: Table Of Contents
Electric Pole Hedge Trimmer Instructions for Use 10597 Please read and retain these instructions for future reference v001: 01/11/16 Please read these operating instructions carefully and observe the notes given. Use these operating instructions to familiarise yourself with the pole hedge trimmer, its proper use and the notes on safety. -
Page 3: Instructions For Use
Electric Pole Hedge Trimmer Instructions for Use 10597 Please read and retain these instructions for future reference v001: 01/11/16 The operator is responsible for following the warnings and instructions in this manual and on the product. Never use the product unless the guards provided by the manufacturer are in the correct position. - Page 4 Electric Pole Hedge Trimmer Instructions for Use 10597 Please read and retain these instructions for future reference v001: 01/11/16 c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control. 2) Electrical safety a) Power tool plugs must match the outlet.
-
Page 5: Db(A
Electric Pole Hedge Trimmer Instructions for Use 10597 Please read and retain these instructions for future reference v001: 01/11/16 e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. -
Page 6: Cutter Blade
Electric Pole Hedge Trimmer Instructions for Use 10597 Please read and retain these instructions for future reference v001: 01/11/16 Pole hedge trimmer safety warnings: Keep all parts of the body away from the cutter blade. Do not remove cut material or hold material to be cut when blades are moving. - Page 7 Electric Pole Hedge Trimmer Instructions for Use 10597 Please read and retain these instructions for future reference v001: 01/11/16 Switch off, remove plug from mains and examine electric supply cable for damage or ageing before winding cable for storage. Do not repair a damaged cable, replace it with a new one.
-
Page 8: Component Assembly
Electric Pole Hedge Trimmer Instructions for Use 10597 Please read and retain these instructions for future reference v001: 01/11/16 Maintenance and storage RISK OF INJURY ! Do not touch blades. When finishing or interrupting work, push up protection cover. Keep all nuts, bolts and screws secure to be sure the pole hedge trimmer is in safe working condition. -
Page 9: Operation
Electric Pole Hedge Trimmer Instructions for Use 10597 Please read and retain these instructions for future reference v001: 01/11/16 4. Operation Adjusting Power Head Angle: 1. The angle of power head can be set to 8 different working positions. 2. Push the Adjust button (there is a "PUSH" on it) with one hand and turn round the power head to suitable position. -
Page 10: Grip Area
Electric Pole Hedge Trimmer Instructions for Use 10597 Please read and retain these instructions for future reference v001: 01/11/16 Starting the Pole Hedge Trimmer: 1. Remove the protective cover from blade (See Figure 6) . 2. Adjust the power head and the pole length to suitable position. -
Page 11: Maintenance
Electric Pole Hedge Trimmer Instructions for Use 10597 Please read and retain these instructions for future reference v001: 01/11/16 7. When starting a cut, place moving trimmer against branch. Hold pole trimmer firmly in place . 8. Remove pole trimmer from a cut with running at full speed. Stop pole saw by releasing trigger. -
Page 12: Plug
Electric Pole Hedge Trimmer Instructions for Use 10597 Please read and retain these instructions for future reference v001: 01/11/16 • TO PROTECT AGAINST ELECTRIC SHOCK, DO NOT IMMERSE CORD, PLUG OR APPLIANCE IN WATER OR ANY OTHER LIQUID. • UNPLUG FROM OUTLET WHEN NOT IN USE AND BEFORE CLEANING. - Page 13 Electric Pole Hedge Trimmer Instructions for Use 10597 Please read and retain these instructions for future reference v001: 01/11/16 Disposal • Dispose of all packaging, paper, cartons and plastic, plastic bags in accordance with your local recycling regulations. • At the end of the product’s lifespan please dispose of it at an authorised household WEEE waste recycling centre.
