CrucialTrak BACS Quattro Installation & User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BACS™ Installation & User Guide
Quattro
BACS
Installation & User Guide
Revision 1.3
June 2017
© 2017 CrucialTrak Inc. All right reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BACS Quattro and is the answer not in the manual?

Questions and answers

Related Manuals for CrucialTrak BACS Quattro

Summary of Contents for CrucialTrak BACS Quattro

  • Page 1 BACS™ Installation & User Guide Quattro BACS Installation & User Guide Revision 1.3 June 2017 © 2017 CrucialTrak Inc. All right reserved.
  • Page 2 COPYRIGHT© 2017 CrucialTrak Inc. All rights reserved. This guide is provided to the Customer as a reference and training aid for the CrucialTrak product purchased by the Customer. This guide may be distributed to employees and agents of the Customer for purposes of reference and internal training.
  • Page 3 Ordering Information Please contact your local representative (CBCA: http://www.cbcamerica.com) or visit us on the web at http://www.crucialtrak.com for information about ordering and product information Feedback CrucialTrak appreciates your comments about this manual. Please contact us at info@crucialtrak.com...

  • Page 4: Table Of Contents

    Reader ............................13 4. BACS Startup ................18 4.1. Basic System Check-up after Installation .................. 18 4.2. Verify Process Through Graphical User Interface ..............20 4.3. How to Use................................23 © 2017 CrucialTrak Inc. All right reserved. Page | 3...
  • Page 5 Wiegand Out Figure 12 BACS Wiegand In Figure 13 BACS Sensor Connection Figure 14 BACS Relay Connection Figure 15 Granted Authentications: (a) Fingerprint (b) Face (c) Iris (d) Palm vein © 2017 CrucialTrak Inc. All right reserved. Page | 4...

  • Page 6: Notice

    1. Notice 1.1. Installer Installers participating in the construction of this access control system shall meet the following conditions: 1.1.1. Be a person who has experience in configuring the system and operating normally. 1.1.2. Demonstrate that the installer, support personnel, and services needed to configure the system are available and a single product supplier will provide hardware, software, training, system installation, related certification, and maintenance service.

  • Page 7: System Integration

    1.5.2. When working with other companies and users, they should work well together. 1.5.3. All of the involved systems and subsystems should be integrated into the system. © 2017 CrucialTrak Inc. All right reserved Page | 6...

  • Page 8: Introduction

    2. Introduction Parts 1 – BACS Quattro Reader - Mounting Bracket - Quick Installation guide - 5 mm x 38 mm drywall screw - 30p male socket - cable tie Recommended • DC power supply (12VDC, 5A) • Cat 5E ethernet cable (Belden 1624P. AWG24 or equivalent) – Ethernet •...

  • Page 9: Overview Of Bacs ™ Reader

    Figure 1 and Figure 2 show exploded and component diagrams of BACSTM Reader, respectively. Figure 1 Exploded diagram of BACS Reader © 2017 CrucialTrak Inc. All right reserved. Page | 8...
  • Page 10 30p male socket X 1 Standard nylon Quick Installation Guide X 1 Cable tie x 2 * For missing parts, please contact with www.crucialtrak.com Preparation & Tools (Not included in package) DC 12V, 3A power supply Grounded AC Power cord...
  • Page 11 Figure 2 Component Diagram of BACS Reader © 2017 CrucialTrak Inc. All right reserved. Page | 10...
  • Page 12 When unlocking, twist Quattro in clock wise direction. If you want to adjust default panning angle, twist Quattro in locked status. (* Do not twist Quattro too hard, pin can be broken) © 2017 CrucialTrak Inc. All right reserved. Page | 11...
  • Page 13 Height Adjustment & Default Pan Tilt position Base Plate For the best performance of recognition, install BACS Quattro at proper height. Based on regional property, recommended heights of base plate are as below, 110 cm : European 100 cm : North America 90 cm : Asian After installation, please set default ‘Y’...

  • Page 14: Overview Of Bacs ™ Reader Network System (Rs-485/ Lan/ Wan)

    3 shows a systemic diagram for network configuration. Figure 4 and Figure 5 show diagrams of systemic networks for BACS Readers by using RS-485 & WAN. Figure 3 Systemic diagram of BACS Networking © 2017 CrucialTrak Inc. All right reserved. Page | 13...
  • Page 15 • Other Quattros can be slave devices and have to referring toward ‘Master’. (Please read ‘Network configuration’ in this guide) • Strongly recommended to use ‘Enroll Station e4’ for registration. © 2017 CrucialTrak Inc. All right reserved. Page | 14...
  • Page 16 Figure 4 Diagram of Networking by Using RS-485 Figure 5 Diagram of RS-485 connection © 2017 CrucialTrak Inc. All right reserved. Page | 15...
  • Page 17 Figure 6 Diagram of Networking by Using WAN Figure 7 Diagram of LAN Connection © 2017 CrucialTrak Inc. All right reserved. Page | 16...

  • Page 18: Bacs ™ Reader: Multi-Biometric Access Control Reader

    (b) Icon LED: Displays the fingerprint, face, iris and palm vein icon according to biometric authentication. (8) This access control reader shall have the following power specification. (a) Current: 6A © 2017 CrucialTrak Inc. All right reserved. Page | 17...
  • Page 19 (14) This access control reader shall be connected in the following manner. (a) Power (b) TCP / IP (c) RS485 (d) WIEGAND OUT (e) RF card reader Sensor (g) Relays © 2017 CrucialTrak Inc. All right reserved. Page | 18...

  • Page 20: Installation

    3. Installation 3.1. BACS Reader Figure 6 and Figure 7 show the overview of the interface for the installation. Figure 6 Terminal Block Pin-Map Figure 7 BACS Interface © 2017 CrucialTrak Inc. All right reserved. Page | 19...
  • Page 21 (connect with other devices, enroll station, CRUAMS server, other DUO, Quattro etc.) Monitor Keyboard / Mouse etc.  Before starting connection, please read carefully next 3.1.x section of this guide. © 2017 CrucialTrak Inc. All right reserved. Page | 20...
  • Page 22 RJ45 connector and connect the other side of the RJ45 cable to this product. (For the IP setting method, please refer to the guide by asking the product supplier for the detailed manual.) Figure 9 shows TCP/IP connection. Figure 9 BACS TCP/IP Connection © 2017 CrucialTrak Inc. All right reserved. Page | 21...
  • Page 23 "Wiegand Out" terminal. Connect the pin 16 or 18 of the "terminal block" of this product to the "card reader connector" of the main controller. Figure 11 shows the configuration of the Wiegand out. Figure 11 BACS Wiegand out © 2017 CrucialTrak Inc. All right reserved. Page | 22...
  • Page 24 Sensor: The figure below shows how this product controls sliding automatic doors and related devices. Connect cables from the door contact, door sensor, exit button, and infrared sensor as shown below. Figure 13 BACS Sensor connection © 2017 CrucialTrak Inc. All right reserved. Page | 23...
  • Page 25 3.1.9. RF Card Reader: When connecting the BACS access control system with RF card reader, connect the wire with the card reader to the 'terminal block' of the main unit. © 2017 CrucialTrak Inc. All right reserved. Page | 24...
  • Page 26 Confirm compatibility and max current with lock devices, EM-LOCK, Dead Bolt and Striker • Max current of Quattro relay circuit is 2.5A. Please keep under 2.0A Relay 1 or 2 Relay 1 or 2 © 2017 CrucialTrak Inc. All right reserved. Page | 25...

  • Page 27: Bacs Tm Startup

    After the operation of the face module, if the IR LED red light source is turned on in the middle of the pan/tilt module, the iris module operates. If you have © 2017 CrucialTrak Inc. All right reserved. Page | 26...
  • Page 28 BACS System. Detailed error logs can be found in the Monitoring function of CRUAMS. 4.1.8. Each module authentication icon is displayed when authentication succeeds. When the problem is found in each module, the problemed icon continuously flickers in 1-second increments © 2017 CrucialTrak Inc. All right reserved. Page | 27...
  • Page 29 Ref. How to change mode Once Quattro is turned on, Enroll mode or Verification mode will be shown as bellow. You can change operating mode by clicking Tasks in task bar of desktop screen © 2017 CrucialTrak Inc. All right reserved. Page | 28...
  • Page 30 You can sync. all User DB with in same network.  If you close any applications (BACS Quattro, Enroll & BACS Manager) by clicking ‘x’ of upper left window, then applications will be automatically re- executed.

  • Page 31: Verify Process Through Graphical User Interface

    4.2. Verify Process Through Graphical User Interface Default screen 4.2.1. Front TOF sensor is detected 4.2.2. © 2017 CrucialTrak Inc. All right reserved. Page | 30...
  • Page 32 Face authentication is completed 4.2.3. Face/Iris authentication is completed 4.2.4. © 2017 CrucialTrak Inc. All right reserved. Page | 31...
  • Page 33 ID, Name, and photo will be appeared on the screen. The final authentication success condition can be adjusted from one to four conditions depends on your preferred combinations. regarding enroll process, refer to appendix of this guide. 4.2.7 © 2017 CrucialTrak Inc. All right reserved. Page | 32...

  • Page 34: How To Use

    FACE authentication 4.3.1. IRIS authentication 4.3.2. For iris recognition, please look at the infra-red light and hold for 1 to 3 seconds. Iris tracking system will scan your iris automatically. © 2017 CrucialTrak Inc. All right reserved. Page | 33...
  • Page 35 For fingerprint recognition, place your fingers directly above the Finger Print Camera then, slowly approach to the camera. Do not touch and keep distance from the camera. (Your hand may be far from cameras than you see) © 2017 CrucialTrak Inc. All right reserved. Page | 34...
  • Page 36 Perpendicularly place your palm in Align center of your palm with 35~70mm distance from palm vein sensor. center of square palm vein sensor You can find best position as yo-yo playing © 2017 CrucialTrak Inc. All right reserved. Page | 35...
  • Page 37 Value SETUP : Configuration Open CrucialTrak configuration page on web browser by typing 192.168.0.194:3000 in URL • address box. Quattro and console (PC, laptop or portable devices) should be connected in same network • ip address of itself ip address of Master For being Master(Enroll Station) at one system, IP address might be same with Server IP •...
  • Page 38 4. frr ( 0.99 = 99 %) : similarity compared with registered face image ( for preventing mismatch, do not set lower than 0.98) Without full understanding about Quattro facial recognition, recommend to use • default value. © 2017 CrucialTrak Inc. All right reserved. Page | 37...
  • Page 39 Card type of RFID reader which is connected with Wiegand in port Wiegand out high signal length Wiegand out low signal length Relay operation time value (Door opening time) Relay operation time value (Door opening time) © 2017 CrucialTrak Inc. All right reserved. Page | 38...
  • Page 40 25) Number of fps for enrollment 26) Technical value 27) Good Image Quality criteria for enroll 28) Good Image Quality criteria for identification 29) Template max. size each person 30) Hand detect max distance © 2017 CrucialTrak Inc. All right reserved. Page | 39...
  • Page 41 12) Technical value 13) Zoom speed for identification 14) Zoom speed for enrollment 15) Zoom range 16) IR light strength For more information about Configuration, please contact with CrucialTrak Technical Team. • © 2017 CrucialTrak Inc. All right reserved. Page | 40...
  • Page 42 Clean dust on ventilation fans occasionally. • • Do not hang anything on Quattro installed on the wall. For more information, please contact CrucialTrak customer support or technical team. Customer Support: CS@crucialtrak.com Technical Team: RND@crucialtrak.com © 2017 CrucialTrak Inc. All right reserved.
  • Page 43 Appendix Enroll Station e4 Installation & User guide Enroll Station © 2017 CrucialTrak Inc. All right reserved. Page | 42...
  • Page 44 AC 110V / 220V  E4 does not support free voltage, please confirm 110/220V prior to supply AC power  Do block rear cooling FAN  Avoid cable bending © 2017 CrucialTrak Inc. All right reserved. Page | 43...
  • Page 45 1) Turn on Enroll station, enroll screen will be shown as below then click Enrollment button to start 2) Type User Name and RFID no. ID will be generated automatically © 2017 CrucialTrak Inc. All right reserved. Page | 44...
  • Page 46 3) Introduction screen will be appeared, click Next button to start enrollment. 4) Step 1. Face enrollment: Place your face 50~60cm away from the device. Click Capture button when ellipse is appeared on your face image. © 2017 CrucialTrak Inc. All right reserved. Page | 45...
  • Page 47 6) Step 2. Iris enrollment: Press Capture button to start Iris enrollment. Try hold the position from the face enrollment, keep your eyes open fully and loot at the camera inside. The iris recognition camera should scan your both irises. © 2017 CrucialTrak Inc. All right reserved. Page | 46...
  • Page 48 For better image or when only one iris is saned, adjust your position, and click Try Again for re-registration. 8) Step 3. Fingerprint enrollment: Click Capture button to start. Green lights will be turned © 2017 CrucialTrak Inc. All right reserved. Page | 47...
  • Page 49 9) Slowly approach your fingers over the green lights(camera). 5~6cm distance rage is recommended. The device captures 10 images of your fingers then It will stat counting when the object is detected correctly. © 2017 CrucialTrak Inc. All right reserved. Page | 48...
  • Page 50 For better images or failed case, Click Try Again. 11) Step 4. Palm vein enrollment: Click Capture to start. stretch thumb finger to make flat palm pasture, place palm over the Palm vein sensor. © 2017 CrucialTrak Inc. All right reserved. Page | 49...
  • Page 51 13) Click Finish to save your biometric templates and finish the enrollment. ※ For improved performance, It is recommended to enroll at Quattro and Duo in addition to Enroll station. © 2017 CrucialTrak Inc. All right reserved. Page | 50...
  • Page 52  Make sure user ID is correct. Supervisor needs to double check by comparing with separately managed user lists.  If user already linked RFID card # with biometric info., then you must type card #. Do not leave it blank. © 2017 CrucialTrak Inc. All right reserved. Page | 51...
  • Page 53 16) In order to return to Desktop, please drag down Enroll GUI screen. If you closed any BACS applications (Enroll, BACS Manager) by clicking ‘x’  of upper left window, then applications will be automatically re-executed. © 2017 CrucialTrak Inc. All right reserved. Page | 52...
  • Page 54 For additional offices around the world, see www.crucialtrak.com corporate offices. CrucialTrak Customer Support: www.crucialtrak.com/support CrucialTrak Inc. All right reserved by CrucialTrak, CrucialTrak logo, BACS are trademarks or registerd trademarks of CrucialTrak Inc. in US or other conturies. © 2017 CrucialTrak Inc. All right reserved.
