Components
• • BACS•Quattro
• • 14•PIN•socket•(2•pcs)
• • Standard•nylon•cable•ties•(2•pcs)
If•an•item•is•missing,•ask•a•sales•representative•at•the•store•where•
it•was•purchased,•or•contact•us•by•visiting•www.crucialtrak.com.
Name of Each Part
Icon display
Iris camera
Face
camera
Iris light
• • The•front•ToF•sensor•(Time•of•Flight:•distance•imaging•sensor)•
can•measure•up•to•1•m•(3.2•ft).
• • The•fingerprint•ToF•sensor•can•measure•up•to•10•cm•(3.9•in).
BACSTM Quattro
N5A-18-06-01898-008
• • Mount•bracket•(Base•bracket,•
Lock-disk,•Cover•plate)
•
• Screw•(5•X•38•mm,•3•pcs)
• • Manual
Fingerprint
camera
Fingerprint light
Fingerprint
ToF sensor
Palm vein
sensor
Large ring
light
Front ToF
sensor
BQ-A001 Ι Quick User Guide
Read•this•quick•user•guide•and•use•the•product•correctly.
Refer•to•the•manual•for•detailed•information•of•the•product•usage•and•
precautions.
Using Product
You•can•identify•yourself•easily•with•the•biometrics•registered•in•
the•product.•The•data•that•is•not•registered•cannot•be•used•for•
authentication.
1.• The•large•ring•light•will•turn•white•and•rotate•left•and•right•as•
the•front•ToF•sensor•detects•you•when•you•walk•within•the•1•m•
(3.2•ft)•range•of•the•product.
2.• Use•your•biometric•data•(face,•iris,•fingerprints•and•palm•vein).
If•there•is•nothing•to•recognize•or•you•do•not•use•the•product•
for•a•certain•period•of•time,•the•large•ring•light•will•blink•and•the•
product•will•be•switched•to•its•standby•mode.
3.• Verify•whether•or•not•the•authentication•was•successful.
• • When•authenticated,•the•alarm•will•ring•and•the•mode•icon•will•
turn•blue.
• • When•authentication•has•failed,•the•alert•will•sound•and•
the•large•ring•light•will•be•turned•off.•The•product•will•be•
switched•to•its•standby•mode.
• • When•an•error•occurs,•the•mode•icon•will•blink.
• • When•there•is•a•communication•error•in•the•system,•the•
notification•icon•(•
(Crucial•Access•Management•System)•or•contact•the•
customer•service•center•for•how•to•fix•the•error.
Rev•2.0•Ⅰ••Aug.•2018
• )•will•turn•in•orange.•Refer•to•CRUAMS•
