Hardware Installation - EZCast Mini Box Quick Start Manual

1
Install EZCast Mini Box
(a)MiniBox to power: Connect the DC port to power (5V/2A).
(b)Mini Box to TV: Connect to the HDMI port of your TV.
(c)Connect to network: Connect to network wirelessly or via
LAN port.
5V/2A
a
Router
2
Select source
Set your TV's source/ input selection to HDMI port that
connected to the EZCast dongle
3
Connect successfully
Your TV screen shall display the instructions once EZCast is
connected successfully. Please follow the instructions to
complete setup.
3

Hardware Installation

MiniBox
c
or
LAN port
USB
PC
HDMI1
HDMI2
HDMI3
HDMI
b
4
2
