VIA Technologies Mobile360 M810 User Manual

Fanless ultra-compact in-vehicle solution for flexible 360 svs, adas and dms configurations
Hide thumbs Also See for Mobile360 M810:
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
VIA Mobile360 M810
Fanless ultra-compact in-vehicle
solution for flexible 360° SVS,
ADAS and DMS configurations
1.00-04162020-111700

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mobile360 M810 and is the answer not in the manual?

Questions and answers

Related Manuals for VIA Technologies Mobile360 M810

Summary of Contents for VIA Technologies Mobile360 M810

  • Page 1 USER MANUAL VIA Mobile360 M810 Fanless ultra-compact in-vehicle solution for flexible 360° SVS, ADAS and DMS configurations 1.00-04162020-111700...
  • Page 2 VIA Technologies, Inc. reserves the right the make changes to the products described in this manual at any time without prior notice.
  • Page 3 Battery Recycling and Disposal • Only use the appropriate battery specified for this product. • Do not re-use, recharge, or reheat an old battery. • Do not attempt to force open the battery. • Do not discard used batteries with regular trash. •...
  • Page 4 VIA Moblie360 M810 User Manual Box Contents • 1 x VIA Moblie360 M810 system • 2 x Phoenix plug to DC jacks (DC-in & DC-out) • 1 x COM cable (for debugging) • 1 x GPS antenna • 2 x Wi-Fi/BT antennas Ordering Information Part Number Description...

  • Page 5: Table Of Contents

    VIA Mobile360 M810 User Manual Table of Contents 1. Product Overview ......................1 Key Features ............................1 1.1.1 High-Performance .......................... 1 1.1.2 Fanless, Compact, Ruggedized Chassis ..................1 1.1.3 Optimized Integration with Multiple I/O Access ................1 1.1.4 Multiple Camera Support ......................1 1.1.5 Support for a Wide Range of Power Sources ................1 1.1.6...
  • Page 6 VIA Mobile360 M810 User Manual List of Figures Figure 1: Front panel I/O layout .......................... 5 Figure 2: Back panel I/O layout (default) ......................5 Figure 3: Back panel I/O layout (factory option) ....................5 Figure 4: Dimensions of the VIA Mobile360 M810 (front view) ................. 6 Figure 5: Dimensions of the VIA Mobile360 M810 (side view) ................6 Figure 6: Dimensions of the VIA Mobile360 M810 (bottom view)..............6 Figure 7: HDMI port diagram ..........................7 Figure 8: USB 3.0 port diagram .......................... 7 Figure 9: Micro USB 2.0 port diagram ......................... 8 Figure 10: Micro SD card slot diagram ........................
  • Page 7 VIA Mobile360 M810 User Manual List of Tables Table 1: HDMI port pinouts ..........................7 Table 2: USB 3.0 port pinouts ........................... 7 Table 3: Micro USB 2.0 port pinouts ........................8 Table 4: Micro SD card slot pinouts ........................8 Table 5: SIM card slot pinouts ........................... 8 Table 6: Gigabit Ethernet port pinouts ......................9 Table 7: Gigabit Ethernet port LED color definition ................... 9 Table 8: CAN bus ports pinouts ......................... 9 Table 9: DIO port pinouts ..........................

  • Page 8: Product Overview

    VIA Mobile360 M810 User Manual 1. Product Overview The VIA Mobile360 M810 is a fanless ultra-compact in-vehicle solution for flexible 360° SVS, ADAS, and DMS configurations. With suppport for up to six automotive-grade camera streams, it delivers real-time in-vehicle 360° video monitoring and recording, combined with additional ADAS and DMS features. Its ruggedized design has been optimized for the most demanding on-road and off-road conditions, the VIA Mobile360 M810 provides a flexible, high-performance solution for a wide variety of applications including Freight Transportation, Delivery, Construction, Industrial, Mining, Agriculture and Forestry, as well as Refuse Collection, Armored Cars, Secure Freight Shipping, Buses and Coaches. The VIA Mobile360 M810 is powered by the Qualcomm® APQ8096A Embedded Processor, which features two high-performance Kryo™ cores at up to 2.054GHz, and two low-power Kryo cores at up to 1.593GHz. It combines advanced computing, graphics and AI processing performance, rich connectivity options, and I/O peripheral integration capabilities in an ultra-compact fanless system. Measuring just 236.7mm (W) x 46mm (H) x 180mm (D), the system integrates a rich set of I/O features through the front and back panels of its ultra-compact chassis. These include a HDMI port, two USB 3.0 ports, Gigabit Ethernet, two CAN bus ports, six FAKRA connectors for camera-in, and a Micro SD card slot. Other features include 4GB LPDDR4 SDRAM, 16GB eMMC flash memory, a SIM card slot, DIO, COM, and a headphone and mic-in ports. The VIA Mobile360 M810 combines high-performance computing with low power consumption, and has a built-in power management system that protects from power surges – guarding against damage from transient vehicle power delivery.

  • Page 9: Storage Expansion

    VIA Mobile360 M810 User Manual 1.1.6 Storage Expansion The VIA Mobile360 M810 has 16GB of eMMC flash storage onboard, and features a Micro SD card slot supporting an additional 32GB. 1.1.7 Networking Support The VIA Mobile360 M810 is equipped with Wi-Fi/BT, GPS, 4G (factory option), and an RJ-45 port that provides high-speed Gigabit Ethernet. 1.1.8 Multiple Mounting Solutions The VIA Mobile360 M810 supports multiple methods for secure chassis mounting. The rugged VIA Mobile360 M810 can be mounted on the side-panel of a car, floor bed, or any flat surface. 1.1.9 Embedded Operating System Ready The VIA Mobile360 M810 features a complete software evaluation image based on Yocto 2.3.

  • Page 10: Product Specifications

    VIA Mobile360 M810 User Manual Product Specifications Processor • Qualcomm APQ8096A Embedded Processor ® ◦ Two high-performance Kryo cores up to 2.054GHz ◦ Two low power Kryo cores up to 1.593GHz System Memory • 4GB LPDDR4 SDRAM Storage • 16GB eMMC flash memory • 2 x M.2 SATA slots Graphics • Qualcomm Adreno 530 GPU ® ™ ◦ 3D graphics accelerator with 64-bit addressing 624MHz ◦ Graphics engine supporting OpenGL ES 3.1/GEP, GL4.4, DX11.3/4, OpenCL 2.0, Renderscript-Next ◦ Supports H.264, VP8, HEVC 8/10-bit, VP9 video decoding up to: 4K@60fps, 1080p@240fps,...
  • Page 11 VIA Mobile360 M810 User Manual Back Panel I/O • 1 x HDMI port • 1 x DIO port • 1 x COM port • 2 x CAN bus ports (supports up to five CAN bus) • 1 x Gigabit Ethernet port • 6 x FAKRA connectors for camera-in • 1 x Headphone/Mic-in port • 3 x Antenna connectors for Wi-Fi/BT, GPS, and 4G (factory option) • 1 x 4-pole Phoenix 9~36V DC-in • 1 x 2-pole Phoenix 12V DC-out Power Supply • 9~36V DC-in with IGN Operating System • Yocto 2.3 Operating Temperature • -20°C ~ 70°C Storage Temperature •...

  • Page 12: Layout Diagram

    VIA Mobile360 M810 User Manual Layout Diagram Figure 1: Front panel I/O layout Figure 2: Back panel I/O layout (default) Figure 3: Back panel I/O layout (factory option)

  • Page 13: Product Dimensions

    VIA Mobile360 M810 User Manual Product Dimensions Figure 4: Dimensions of the VIA Mobile360 M810 (front view) Figure 5: Dimensions of the VIA Mobile360 M810 (side view) Figure 6: Dimensions of the VIA Mobile360 M810 (bottom view)

  • Page 14: 2. External I/O Pin Descriptions And Functionality

    VIA Mobile360 M810 User Manual 2. External I/O Pin Descriptions and Functionality The VIA Mobile360 M810 has a wide selection of interfaces, and includes a selection of frequently-used ports as part of the external I/O coastline. HDMI Port ® The VIA Mobile360 M810 is equipped with one HDMI port on the back panel. A HDMI port Type A receptacle connector provides connection to High Definition video and digital audio using a single cable. The pinouts of the HDMI port are shown below. Signal Signal CLK- Figure 7: HDMI port diagram DDC_CLK DDC_DATA HDMI_5V PLUG_DET CLK+ Table 1: HDMI port pinouts USB 3.0 Ports The VIA Mobile360 M810 is equipped with two USB 3.0 ports on the front panel. Each USB 3.0 port has a maximum data transfer rate of up to 5Gbps and is backwards compatible with the USB 2.0 specification. The USB ports provides complete Plug and Play and hot swap capabilities for external devices. The pinouts of the USB 3.0 ports are shown below Signal VBUS Figure 8: USB 3.0 port diagram...

  • Page 15: Micro Usb 2.0 Port

    VIA Mobile360 M810 User Manual Micro USB 2.0 Port The VIA Mobile360 M810 is equipped with one Micro USB 2.0 port located on the front panel. The Micro USB 2.0 port supports OTG (On-The-Go) for debugging. The pinouts of the Micro USB 2.0 port are shown below. Signal VBUS Figure 9: Micro USB 2.0 port diagram Table 3: Micro USB 2.0 port pinouts Micro SD Card Slot The VIA Mobile360 M810 comes with a Micro SD card slot located on the front panel with support for a maximum storage capacity of 32GB. The pinouts of the Micro SD card slot are shown below. Signal SD_DAT2 SD_DAT3 SD_CMD Figure 10: Micro SD card slot diagram SD_CLK SD_DAT0 SD_DAT1 SD_CD- Table 4: Micro SD card slot pinouts SIM Card Slot The VIA Mobile360 M810 comes with an optional SIM card slot located on the front panel that supports 4G SIM cards. SIM card usage on the VIA Mobile360 M810 requires that a 4G module is installed in the miniPCIe slot, enabling the 4G functionality, otherwise the SIM card slot will be disabled. The SIM card slot is designed for use with 4G modules that do not support built-in SIM card slots. The pinouts of the SIM card slot are shown below. Signal VSIM_VCC VSIM_RST VSIM_VCC...

  • Page 16: Gigabit Ethernet Port

    VIA Mobile360 M810 User Manual Gigabit Ethernet Port The VIA Mobile360 M810 comes with one Gigabit Ethernet port on the back panel which uses an 8 Position and 8 Contact (8P8C) receptacle connector commonly known as RJ-45. It is fully compliant with the IEEE 802.3 (10BASE-T), 802.3u (100BASE-TX), and 802.3ab (1000BASE-T) standards. The pinouts of the Gigabit Ethernet port are shown below. Signal TX1+ TX1- TX2+ TX2- TX3+ TX3- Figure 12: Gigabit Ethernet port diagram TX4+ TX4- Table 6: Gigabit Ethernet port pinouts The Gigabit Ethernet port (RJ-45) is equipped with two LED indicators on the front side to show its Active/Link status and Speed status. Active LED Link LED (Left LED on RJ-45 port) (Right LED on RJ-45 port)

  • Page 17: Dio Port

    VIA Mobile360 M810 User Manual DIO Port The VIA Mobile360 M810 is equipped with a DIO port located on the back panel. The DIO port offers a Digital I/O communication interface to support 8-bit GPIO. The pinouts of the DIO port are shown below. Signal GPO0 GPO1 GPO2 GPO3 GPI0 GPI1 GPI2 Figure 14: DIO port diagram DIO_GND Table 9: DIO port pinouts Headphone and Mic-in Port The VIA Mobile360 M810 is equipped with a Headphone and Mic-in port located on the back panel. The Headphone and Mic-in port is for connecting external speakers such as a headphone or a microphone. The pinouts of the Headphone and Mic-in port are shown below. Signal MIC1 Jack_det HPH_GND_SENSE_CONN CDC_HPH_R_CONN CDC_HPH_L_CONN Table 10: Headphone and Mic-in port pinouts Figure 15: Headphone and Mic-in port diagram 2.10 COM Port The VIA Mobile360 M810 is equipped with a COM port located on the back panel which supports TX/RX for debugging. The pinouts of the COM port are shown below.

  • Page 18: 2.11 Fakra Connectors

    VIA Mobile360 M810 User Manual 2.11 FAKRA Connectors The VIA Mobile360 M810 is equipped with six FAKRA connectors located on the back panel. The FAKRA connectors are for FOV-40 and FOV-190 automative-grade cameras. The pinouts of the FAKRA connector are shown below. Signal RIN_P Table 12: FAKRA connector pinouts Figure 17: FAKRA connector diagram 2.12 Power Button The VIA Mobile360 M810 comes with a power button that supports two functions: System Suspend/Resume and Power On/Off. The diagram of the power button is shown below. Figure 18: Power button diagram Power button behavior Suspend/Resume System Quickly press the power button once to suspend. While in suspend mode quickly press once to resume. Power On/Off Occurs when the power button is pressed for longer than 3 seconds. Table 13: Power button behavior description 2.13 DC-in Jack The VIA Mobile360 M810 integrates a 4-pole Phoenix DC-in jack that carries 9~36V DC external power input.

  • Page 19: 2.14 Dc-Out Jack

    VIA Mobile360 M810 User Manual 2.14 DC-out Jack The VIA Mobile360 M810 integrates a 2-pole Phoenix DC-out jack that provides 12V DC power output. The pinouts of the 2-pole Phoenix DC-out jack are shown below. Signal DC_OUT 12V/2A DC-IN Table 15: DC-out jack pinouts Figure 20: DC-out jack diagram 2.15 Antenna Connectors The VIA Mobile360 M810 is equipped with three antenna connectors located on the back panel. Two antenna connectors are used for Wi-Fi/BT and 4G (optional) antennas, while a third antenna connector can be used as a GPS antenna. The Wi-Fi/BT, 4G and GPS antenna connectors diagrams are shown below. Figure 21: WiFi/BT/4G antenna connector diagram Figure 22: GPS antenna connector diagram Note: 4G functionality is factory option. When the 4G function is enabled, one of the two antenna connectors for the Wi-Fi/BT will be used for the 4G antenna.

  • Page 20: 3. Hardware Installation

    VIA Mobile360 M810 User Manual 3. Hardware Installation This chapter provides information about the hardware installation procedures. Installing the Wi-Fi/BT Antennas Step 1 Locate the two Wi-Fi/BT antenna connectors on the back panel of the VIA Mobile360 M810. Step 2 Install the two provided Wi-Fi/BT antennas. Figure 23: Installing the Wi-Fi/BT antennas...

  • Page 21: Installing The Gps Antenna

    VIA Mobile360 M810 User Manual Installing the GPS Antenna Step 1 Locate the GPS antenna connector on the back panel of the VIA Mobile360 M810. Step 2 Install the provided GPS antenna. Figure 24: Installing the GPS antenna...

  • Page 22: Installing The Fov Cameras And Fakra Cables

    VIA Mobile360 M810 User Manual Installing the FOV Cameras and FAKRA Cables Step 1 Align the FOV camera's connector with the FAKRA cable's connector. Then insert the camera connector until the locking clips lock the connector in place. Figure 25: Connecting the FOV camera to the FAKRA cable Step 2 Connect the FAKRA cable to the FAKRA connector for camera-in on the VIA Mobile360 M810. Figure 26: Connecting the FAKRA cable to the FAKRA connector...

  • Page 23: Unplugging The Fakra Cable

    VIA Mobile360 M810 User Manual Unplugging the FAKRA Cable Step 1 Firmly press and hold the locking clip on the FAKRA cable's connector. Step 2 Then pull the FAKRA cable's connector to unplug it. Figure 27: Uplugging the FAKRA cable...

  • Page 24: Connecting The Via Mobile360 M810 To The Vehicle's Ignition (Ign)

    VIA Mobile360 M810 User Manual Connecting the VIA Mobile360 M810 to the Vehicle's Ignition (IGN) Step 1 Locate pin no. 8 on the DIO port located on the back panel I/O. Figure 28: DIO port's pin 8 Step 2 Connect a wire on the pin no. 8 on DIO port. Then connect the other end of the wire into the Ignition (IGN) signal of the vehicle. For details where to find the IGN on your vehicle, please refer to your car manufacturer. Figure 29: VIA Mobile360 M810 and IGN connection method diagram...

  • Page 25: Installing The Phoenix Plug To Dc Jack

    VIA Mobile360 M810 User Manual Installing the Phoenix Plug to DC Jack Step 1 Install four wires to the Phoenix plug to DC jack from the vehicle's battery. To install the wire, first loosen the respective screws on the Phoenix plug to DC jack before inserting each wire. Figure 30: Connecting the battery cables onto the Phoenix plug to DC jack Step 2 Connect the Phoenix plug to DC jack into the DC-in jack on the VIA Mobile360 M810, and then secure it with its two screws. Figure 31: Connecting the Phoenix plug to DC jack...

  • Page 26: 4. Software And Technical Support

    VIA Mobile360 M810 User Manual 4. Software and Technical Support Yocto Support The VIA Mobile360 M810 features a complete software evaluation image featuring the Yocto 2.3 operating system. Technical Support and Assistance • For technical support and additional assistance, contact your local sales representative or board distributor, https://www.viatech.com/en/support/driver-support-fag/technical-support/ or go to for technical support. • For OEM clients and system integrators developing a product for long term production, other code and resources may also be made available. Please visit our website at https://www.viatech.com/en/ about/contact/ to submit a request.

  • Page 27: Appendix A. I Nstalling Fov Automotive-Grade Cameras To The Camera Brackets

    VIA Mobile360 M810 User Manual Appendix A. Installing FOV Automotive-grade Cameras to the Camera Brackets This chapter provides information on how to install the FOV-190 and FOV-40 automotive-grade cameras to the camera bracket for SVS/DMS/BSD/FCW. A.1. Installing the FOV-190 Automotive-grade Camera to the Camera Bracket Step 1 Attach the internal bracket to the external bracket, and then secure it with the four screws (M3x6) provided. Figure 32: Attaching the internal bracket to the external bracket Step 2 Install the double-sided adhesive tape on the external bracket as shown in the figure below. Figure 33: Installing the double-sided adhesive tape on the camera bracket...

  • Page 28: Figure 34: Installing The Fov-190 Camera On The Camera Bracket

    VIA Mobile360 M810 User Manual Step 3 Prepare your FOV-190 camera. Position the camera with the text label facing upward. Install the FOV-190 camera on the internal bracket, and then secure it with the two screws (M3x8) provided. Figure 34: Installing the FOV-190 camera on the camera bracket Step 4 Remove the protective cover of the double-sided adhesive tape. Figure 35: Removing the double-sided adhesive tape protective cover...

  • Page 29: Figure 36: Installing The Camera Bracket With Fov-190 Camera On Your Vehicle

    VIA Mobile360 M810 User Manual Step 5 Install the camera bracket on the appropriate location of your vehicle. Figure 36: Installing the camera bracket with FOV-190 camera on your vehicle Caution: Once the camera bracket has been installed, it cannot be removed. Forcibly removing it could damage the double- sided adhesive tape. Step 6 Slightly loosen the four screws (M3x6) of the internal bracket to allow movement. Then adjust the internal bracket to the preferred angle of your FOV-190 camera. Once the camera angle has been positioned, tighten the four screws to firmly secure the camera. Figure 37: Adjusting the FOV-190 camera angle...

  • Page 30: Installing The Fov-40 Automotive-Grade Camera To The Camera Bracket

    VIA Mobile360 M810 User Manual A.2. Installing the FOV-40 Automotive-grade Camera to the Camera Bracket Step 1 Attach the internal bracket to the external bracket, and then secure it with the four screws (M3x6) provided. Figure 38: Attaching the internal bracket to the external bracket Step 2 Install the double-sided adhesive tape on the external bracket as shown in the figure below. Figure 39: Installing the double-sided adhesive tape on the camera bracket...

  • Page 31: Figure 40: Preparing The Fov-40 Camera

    VIA Mobile360 M810 User Manual Step 3 Prepare your FOV-40 camera. Position the camera with the text label facing downward before installing it on the internal bracket. Figure 40: Preparing the FOV-40 camera...

  • Page 32: Figure 41: Installing The Fov-40 Camera On The Camera Bracket

    VIA Mobile360 M810 User Manual Step 4 Install the FOV-40 camera on the internal bracket, and then secure it with the two screws (M3x8) provided. Figure 41: Installing the FOV-40 camera on the camera bracket Step 5 Remove the protective cover of the double-sided adhesive tape. Figure 42: Removing the double-sided adhesive tape protective cover...

  • Page 33: Figure 43: Installing The Camera Bracket With Fov-40 Camera On Your Vehicle

    VIA Mobile360 M810 User Manual Step 6 Install the camera bracket on the appropriate location of your vehicle. Figure 43: Installing the camera bracket with FOV-40 camera on your vehicle Caution: Once the camera bracket has been installed, it cannot be removed. Forcibly removing it could damage the double- sided adhesive tape.

  • Page 34: Figure 44: Adjusting The Fov-40 Camera Angle

    VIA Mobile360 M810 User Manual Step 7 Loosen a bit the four screws (M3x6) of the internal bracket. Then adjust the internal bracket to find your preferred angle position for your FOV-40 camera. Once the camera angle has been positioned, tighten back the four screws. Figure 44: Adjusting the FOV-40 camera angle...
