- Page 1 TigerO™ User Manual (Version 2019) Ecozone Technologies Ltd.
-
Page 2: Table Of Contents
TigerO User Manual Table of Contents Table of Contents…………………………………..……….…………2 Unpacking…………………………………………………….…….……3 General Information………………………………………………….….4 Schematics………………………………………………………….…..5 Safety Precautions & Warnings……………………………….…………6 Control Panel…………………………………………………………….7 Operation Instructions…………………………………………….……..8 Maintenance and Service……………………………………….…….9-10 Trouble Shooting…………………………………………………….….11 Electrical Schematics……………………………………….….………..12 Declaration of Conformity………………………………………..…….13 Warranty……………………………………………………………...…14 Contact Information…………………………………….…………...…..15... -
Page 3: Unpacking
The TigerO Mobile Ozone Generator for Professionals Unpacking Open the top flaps of the carton and remove the inner supporting walls. Lift the unit up and gently place it on its wheels. Install the handle on both sides of the machine... -
Page 4: General Information
General Information The TigerO is a compact but yet a very powerful ozone generator which makes use of the advanced technology of Ecozone's unique Singlet PentaRod core units. The TigerO was specially designed for the professional cleaning market. It is build at high standards which imply, among others, a very long operative life time and high reliability. -
Page 5: Schematics
Schematics Ecozone Technologies has a policy of continuous product improvement and reserves the right to modify or change this specification at any time without notice. -
Page 6: Safety Precautions & Warnings
Safety Precautions & Warnings Read this manual carefully before operating the unit. Do not expose this unit to rain or moisture. Should any liquid come into contact with the machine, unplug it and have it serviced by qualified personnel before operating it further. Unplug the power plug when the machine is not in use. -
Page 7: Control Panel
Control Panel Features from left to right: • Time Counter (Hours). • Start / Stop Button with light indicator: Power ON. • Key Switch – Normal / Remote: Ozone Generator On / Off. • Red Light Indicator – Standby: Ozone Generator is OFF (or Operation Fault). •... -
Page 8: Operation Instructions
Operation in Local mode: 1. Plug the electrical cable cord in the TigerO socket and then connect it to the electricity mains. 2. Turn the Key-Switch to its Normal position (left side). - Page 9 Operation in Remote mode: 8. Plug the electrical cable cord in the TigerO socket and then connect it to the electricity mains through a Remote control Timer. The Input voltage should be: 230V; 50Hz. 9. Turn the Key-Switch to its Remote position (right side).
-
Page 10: Maintenance And Service
Maintenance and Service In order to keep the unit in good operation conditions, periodic maintenance should be performed. Maintenance includes the following two main issues: (1) Cleaning or replacing the air filter and (2) Cleaning the Singlet core units. (1) Cleaning / replacing the air filter: Deposits of dust and dirt on the air filter may result in lowering the performances of the ozone generation. - Page 11 (2) Cleaning the Singlet core units (SCUs): After every 200-250 hours of operation the 2 Singlet core units (SCUs) should be washed and cleaned. For cleaning the Singlet core units (SCU), please follow the instructions: 1. Remove the dust filter housing (Fig.1) by releasing two screws on its top side. 2.
-
Page 12: Trouble Shooting
Trouble Shooting Inside the machine there are two Differential Pressure Switch (DPS) units. These DPS units are designated as PS1 and PS2 and they are set at the factory as follows: PS1 = 20Pa; PS2 = 50Pa. Do not change these settings! Air-flow fault: In case that ozone is not being generated or in case the Orange light is not... -
Page 13: Declaration Of Conformity
ECOZONE and will be free from defects in materials and workmanship under normal use and conditions for the applicable warranty period indicated below. This warranty does not extend to TigerO units which have been subject to misuse, accident, exposure to corrosive substances, tampering or use in a manner not approved by ECOZONE in writing. -
Page 14: Contact Information
Contact Information Ecozone Technologies, Ltd. Hasharon Industrial Park Kadima 60920, Israel . Phone: + 972 98 91 24 41 Fax: + 972 98 91 24 45 info@ecozone technologies.com www.ecozone technologies.com...
