Ecco Pulse II 7945 Series Installation And Operation Instructions

ECCO's 7945 & 7950 series LED beacons are designed to
meet SAE J845 Class II specifi cations (Amber and Clear
only). The 7945 & 7950 features 12-48 VDC operation, 3
bolt mounting fl ange, integrated 1" pipe mount, & optional
vacuum-magnet mount.
IMPORTANT!
Read all instructions before installing and using. Installer: This manual must be
delivered to the end user.
!
WARNING!
Failure to install or use this product according to manufacturers recommendations may result in property dam-
age, serious bodily/personal injury, and/or death to you and those you are seeking to protect!
Do not install and/or operate this safety product unless you have read and understand the
safety information contained in this manual.
1. Proper installation combined with operator training in the use, care, and maintenance of emergency warning devices
are essential to ensure the safety of you and those you are trying to protect.
2. Exercise caution when working with live electrical connections.
3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause
high current arcing, which can cause personal injury and/or severe vehicle damage, including fi re.
4. Proper placement and installation are vital to the performance of this warning device. Install this product so that out-
put performance of the system is maximized and the controls are placed within convenient reach of the operator so
that s/he can operate the system without losing eye contact with the roadway.
5. It is the responsibility of the vehicle operator to ensure during use that all features of this product work correctly. In
use, the vehicle operator should ensure the projection of the warning signal is not blocked by vehicle components
(i.e., open trunks or compartment doors), people, vehicles, or other obstructions.
6. The use of this or any other warning device does not ensure all drivers can or will observe or react to a warning sig-
nal. Never take the right-of-way for granted. It is your responsibility to be sure you can proceed safely before enter-
ing an intersection, driving against traffi c, responding at a high rate of speed, walking on or around traffi c lanes.
7. This equipment is intended for use by authorized personnel only. The user is responsible for understanding and
obeying all laws regarding warning signal devices. Therefore, the user should check all applicable city, state, and fed-
eral laws and regulations. The manufacturer assumes no liability for any loss resulting from the use of this warning
device.
920-0220-00 Rev. D
Installation and Operation Instructions
360° LED Beacon
Page 1 of 4
