PARTS LIST

Please see the parts list drawings for help with finding and identifying each part
along with corresponding part numbers.
RESISTORS:
Description
100Ω 1W
200Ω 5W
1kΩ 1W
1.5kΩ 1/2W
5.6kΩ 1/2W
6.8kΩ 1/2W
22kΩ 1W
100kΩ 1/2W
220kΩ 1/2W
220kΩ 1W
1MΩ 1/2W
TERMINAL STRIPS:
Description
st
5 lug terminal strip (1
rd
5 lug terminal strip (3
st
7 lug terminal strip (1
nd
2 lug terminal strip (2
TRANSFORMERS:
Description
Power Transformer 369EX
Output Transformer P-T31
CAPACITORS:
Description
250pF 500V
.022µF 400V
.047µF 400V
.1µF 400V
22µF 50V
22µF 350V
47µF 350V
100µF 100V
Quantity
1
1
1
2
1
1
1
3
1
1
1
Quantity
lug common) 3
lug common) 1
th
& 7 lug common) 1
lug common) 1
Quantity
1
1
Quantity
1
1
1
1
2
2
1
1
HARDWARE:
Description
#8 self-tap screws
#6 screws
#6 hex nuts
#6 lock washers
#4 screws
#4 hex nut
#10 screws
#10 hex nuts
#10 lock washers
TUBES:
Description
12AX7/ECC83
6BQ5/EL84
MISCELLANEOUS PARTS:
Description
Solid state diode 1N4007
250kΩ audio pot
1MΩ audio pot
knobs
Input jack (switched)
output jack
9 pin miniature tube socket
preamp tube shield
EL84 tube retainer
Rubber Grommet (3/8" center)
Rubber Grommet (1/4" center)
violet jewel
Power switch (SPST)
1A fuse
Fuse holder
Light bulb
Lamp holder
Handle with mounting hardware
Rubber bumpers
Steel chassis box and cover
Labels
Green 20 AWG wire
White 20 AWG wire
4
Quantity
4
9
9
2
4
4
4
4
4
Quantity
1
1
Quantity
2
2
1
3
1
1
2
1
1
4
1
1
1
1
1
1
1
2
4
1/each
1 set
4 feet
6 feet
