User's Manual
PICMG 1.3 SBC 3308290
Versionx1.0
Page i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3308290 and is the answer not in the manual?

Questions and answers

Related Manuals for Global American 3308290

Summary of Contents for Global American 3308290

  • Page 1 User’s Manual PICMG 1.3 SBC 3308290 Versionx1.0 Page i...
  • Page 2 Copyrights This manual is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer.
  • Page 3 Packing List The items listed below should all be included in the 3308290 package. 1 x 3308290 Single Board Computer 3 x SATA cable 1 x SATA power cable 1 x Dual RS-232 cable 1 x USB cable 1 x Mini jumper pack...

  • Page 4: Table Of Contents

    Table of Contents INTRODUCTION....................13 1.1 I ......................14 NTRODUCTION 1.2 B ......................... 14 ENEFITS 1.3 F ......................... 15 EATURES 1.4 O ........................ 15 VERVIEW 1.5 P ..............16 ERIPHERAL ONNECTORS AND UMPERS 1.6 T ..................17 ECHNICAL PECIFICATIONS DETAILED SPECIFICATIONS ................19 2.1 B ....................
  • Page 5 2.6.10 USB Controller ....................32 2.7 LPC B ................... 33 OMPONENTS 2.7.1 iTE IT8712F Super I/O chipset................ 33 2.7.2 TPM Module ....................34 2.8 PCI ..................34 OMPONENTS 2.8.1 PCIe x16 Expansion..................35 2.8.2 PCIe x1 Expansion................... 35 2.8.3 Intel® PC82573L PCIe Gigabit Ethernet (GbE) Controller ......35 2.9 PCI B ....................
  • Page 6 4.2.13 Mouse Connector ................... 63 4.2.14 Parallel Port Connector ................64 4.2.15 SDVO Connector.................... 66 4.2.16 SATA Drive Connectors ................. 67 4.2.17 Serial Port Connectors .................. 68 4.2.18 Trusted Platform Module (TPM) Connector..........69 4.2.19 TV Out Connector ..................71 4.2.20 USB Connectors (Internal) ................
  • Page 7 5.7 I ............95 NTERNAL ERIPHERAL EVICE ONNECTIONS 5.7.1 Peripheral Device Cables ................95 5.7.2 7.1 Channel Audio Kit Installation ..............96 5.7.3 Dual RS-232 Cable with Slot Bracket.............. 97 5.7.4 USB Cable (Dual Port) with Slot Bracket ............98 5.7.5 SATA Drive Connection .................
  • Page 8 List of Figures Figure 1-1: 3308290........................14 Figure 1-2: Overview ........................15 Figure 2-1: Dimensions (mm) ......................20 Figure 2-2: External Interface Panel Dimensions (mm) ............21 Figure 2-3: Data Flow Diagram....................22 Figure 2-4: CPU..........................23 Figure 2-5: Intel® GME965 ......................23 Figure 2-6: Front Side Bus (FSB) ....................24 Figure 2-7: 240-pin DDR2 DIMM Sockets ...................25...
  • Page 9 Figure 4-19: TPM Connector Pinout Locations .................70 Figure 4-20: TV Connector Pinout Locations ................72 Figure 4-21: USB Connector Pinout Locations .................73 Figure 4-22: 3308290 External Peripheral Interface Connector ..........74 Figure 4-23: RJ-45 Ethernet Connector..................75 Figure 4-24: VGA Connector .......................76 Figure 5-1: Make sure the CPU socket retention screw is unlocked ........82 Figure 5-2: Lock the CPU Socket Retention Screw..............83...
  • Page 10 Figure 5-21: USB Device Connection ..................103 Figure 5-22: VGA Connector ....................104 Page x...
  • Page 11 List of Tables Table 1-1: Technical Specifications....................18 Table 2-1: Supported HDD Specifications..................30 Table 3-1: Packing List Items ......................42 Table 3-2: Optional Items......................43 Table 4-1: Peripheral Interface Connectors ................46 Table 4-2: Rear Panel Connectors ....................47 Table 4-3: Audio Connector Pinouts (9-pin) ................48 Table 4-4: Panel Backlight Connector Pinouts................49 Table 4-5: CF Card Socket Pinouts.....................51 Table 4-6: DIO Connector Pinouts ....................52...
  • Page 12 Table 5-1: Jumpers ........................87 Table 5-2: Clear CMOS Jumper Settings..................88 Table 5-3: CF Card Setup Jumper Settings ................89 Table 5-4: Serial Port IR Mode Selection Jumper Settings ............91 Table 5-5: LVDS Voltage Selection Jumper Settings..............92 Table 5-6: LVDS Screen Resolution Selection Jumper Settings ..........93 Table 5-7: PCIe / SDVO Selection Jumper Settings ..............94 Page xii...

  • Page 13: Introduction

    Chapter Introduction Page 13...

  • Page 14: Introduction

    The 3308290 PCIMG 1.3 CPU card is a Socket P Intel® Core™2 Duo Mobile processor platform. The 3308290 has a front side bus (FSB) frequency of 533 MHz or 800 MHz and supports up to two 240-pin 2 GB (max.) 533 MHz or 667 MHz dual-channel DDR2 SDRAM DIMMs (system max.

  • Page 15: Features

    RoHS compliant 1.4 Overview The 3308290 has a wide variety of internal and external peripheral connectors. The peripheral connectors are connected to devices including storage devices, display devices and parallel communications devices. A labeled photo of the peripheral connectors on the 3308290 is shown below.

  • Page 16: Peripheral Connectors And Jumpers

    2 x Serial port connector 1 x TPM connector 1 x TV out connector 2 x USB connectors (for 4 USB devices) The 3308290 has the following connectors on the rear panel: 2 x Ethernet ports 2 x USB ports 1 x VGA connector...

  • Page 17: Technical Specifications

    LVDS voltage selection LVDS screen resolution selection PCIe x16 and SDVO card selection jumpers 1.6 Technical Specifications The technical specifications of the 3308290 are listed in the table below. Detailed descriptions can be found in Chapter 2. 3308290 Specification PICMG 1.3 Form Factor Intel®...

  • Page 18: Table 1-1: Technical Specifications

    3308290 Specification Two internal keyboard/mouse connectors Keyboard/mouse Software programmable 1-255 sec. by super I/O Watchdog Timer 3.3 V @ 0.13 A, 5 V @ 5.3 A, 12 V @ 1.3 A (3DMark® 2001, Intel® Core™2 Duo T7300 processor and 1 GB of...

  • Page 19: Detailed Specifications

    Chapter Detailed Specifications Page 19...

  • Page 20: Board Dimensions

    This chapter describes the specifications and on-board features of the 3308290 in detail. 2.1 Board Dimensions The dimensions of the board are listed and shown below. 338 mm Length: 126 mm Width: Figure 2-1: Dimensions (mm) Page 20...

  • Page 21: External Interface Panel Dimensions

    2.2 External Interface Panel Dimensions The external peripheral interface connector panel dimensions are shown below. Figure 2-2: External Interface Panel Dimensions (mm) Page 21...

  • Page 22: Data Flow

    2.3 Data Flow The figure below shows the data flow between the on-board chipsets and other components installed on the motherboard and described in the following sections of this chapter. Figure 2-3: Data Flow Diagram Page 22...

  • Page 23: Compatible Processors

    2.4 Compatible Processors Figure 2-4: CPU The 3308290 comes with a Socket P CPU socket. The 3308290 supports Socket P Intel® Core™2 Duo Mobile processors with a maximum 800 MHz front side bus (FSB). ® 2.5 Intel GME965 Northbridge Figure 2-5: Intel® GME965 The Intel®...

  • Page 24: Memory Support

    Only DDR2 memory module can be installed on the 3308290. Do not install DDR memory modules. If a DDR memory module is installed, the 3308290 may be irreparably damaged. The Intel® GME965 GMCH on the 3308290 supports two 240-pin DDR2 DIMMs with the following features: Two 240-pin DIMMs...

  • Page 25: Integrated Graphics

    Figure 2-7: 240-pin DDR2 DIMM Sockets 2.5.3 Integrated Graphics The Intel® GME965 GMCH has an mobile Intel® Graphics Media Accelerator X3100 integrated graphics engine that supports the following display devices: Analog CRT LVDS Analog TV-Out Figure 2-8: Integrated Graphics Interfaces 2.5.3.1 Analog CRT Support A DB-15 VGA connector on the external peripheral interface connector panel is interfaced to the Intel®...

  • Page 26: Tv Out Support

    18-bit/24-bit 25 MHz to 112 MHz single-channel or dual-channel LVDS screens TFT panel type supported Panel Fitting, Panning and Center mode supported SPWG v3.5 specification compliant 2.5.3.3 TV Out Support An internal 6-pin header TV output connector is interfaced to the Intel® GME965 graphics engine.

  • Page 27: Intel ® Ich8M-E I/O Controller Hub

    Integrated SATA host controller with DMA operations and RAID 0 and RAID 1 interfaced to three SATA connectors on the 3308290 Supports the eight USB 2.0 devices on the 3308290 with four UHCI controllers and one EHCI controller Complies with System Management Bus (SMBus) Specification, Version 2.0 Supports Intel®...

  • Page 28: Ethernet Controller

    Figure 2-10: HD Audio Codec The HD audio controller is connected to the external peripheral interface controllers through the integrated ALC883 HD Audio Codec. High Definition Audio supports up to eight audio channels at 192 KHz/32-bit quality and dual channel audio, allowing two different audio streams simultaneously.

  • Page 29: Ide Interface

    Can operate at half-duplex at 10 Mbps and 100 Mbps Adheres to the IEEE 802.3x Flow Control Specification. Configurable LED operation for customization of LED display. 64-bit address master support for system using more than 4 GB of physical memory. Configurable receive and transmit data FIFO, programmable in 1 KB increments.

  • Page 30: Low Pin Count (Lpc) Interface

    Specification Ultra ATA/100 Ultra ATA/66 Ultra ATA/33 PIO Max Transfer Rate 16.6 MB/s 16.6 MB/s 16.6 MB/s DMA/UDMA designation UDMA 5 UDMA 4 UDMA 2 DMA/UDMA Max Transfer 100 MB/s 66 MB/s 33 MB/s Controller Interface Table 2-1: Supported HDD Specifications Figure 2-12: IDE Interface 2.6.4 Low Pin Count (LPC) Interface The ICH8M-E LPC interface complies with the LPC 1.1 specifications.

  • Page 31: Pcie X1 Bus

    The PCI bus on the 3308290 supports PCI expansion cards via a compatible backplane. Figure 2-13: PCI Interface 2.6.6 PCIe x1 Bus The Intel® ICH8M-E GMCH has six PCIe x1 lanes. Two PCIe x1 lanes are connected to Intel® 82573L GbE controllers.

  • Page 32: Serial Peripheral Interface (Spi) Bios

    2.6.10 USB Controller Up to ten high-speed, full-speed or low-speed USB devices are supported by the ICH8M-E on the 3308290. High-speed USB 2.0, with data transfers of up to 480 MB/s, is enabled with the ICH8M-E integrated Enhanced Host Controller Interface (EHCI) compliant host controller.

  • Page 33: Lpc Bus Components

    Two USB ports are on the back panel, four USB ports are interfaced through pin headers and four are interfaced through the edge connector. Figure 2-16: Onboard USB Implementation 2.7 LPC Bus Components The LPC bus is connected to components listed below: Super I/O chipset TPM module chipset 2.7.1 iTE IT8712F Super I/O chipset...

  • Page 34: Tpm Module

    Figure 2-17: iTE IT8712F Super I/O Chipset 2.7.2 TPM Module A TPM connector on the 3308290 is interfaced to the Southbridge through the LPC bus. The Southbridge supports TPM version 1.1 and TPM version 1.2 devices for enhanced security. The two TPMs available for the 3308290 are listed below:...

  • Page 35: Pcie X16 Expansion

    PCIe lanes are interfaced from the Intel® ICH8M-E Southbridge. 2.8.3 Intel® PC82573L PCIe Gigabit Ethernet (GbE) Controller There is one Intel® PC82573L PCIe GbE controller installed on the 3308290. The Intel® PC82573L is interfaced through a PCIe x1 channel to the Intel® ICH8M-E. The Intel®...

  • Page 36: Pci Bus Components

    Wide, pipelined internal data path architecture Optimized transmit (Tx) and receive (Rx) queues 32 KB configurable Rx and Tx first-in/first-out (FIFO) IEEE 802.3x*-compliant flow-control support with software controllable pause times and threshold values Programmable host memory Rx buffers (256 B-16 KB) Descriptor ring management hardware for Tx and Rx Mechanism for reducing interrupts from Tx/Rx operations Integrated PHY for 10/100/1000 Mbps (full- and half-duplex)
  • Page 37 Page 37...
  • Page 38 Page 38...
  • Page 39 Page 39...

  • Page 40: Unpacking

    Chapter Unpacking Page 40...

  • Page 41: Anti-Static Precautions

    When the 3308290 is unpacked, please do the following: Follow the anti-static precautions outline in Section 3.1. Make sure the packing box if facing upwards so the 3308290 does not fall out of the box. Make sure all of the components shown in Section 3.3.1 are present.

  • Page 42: Unpacking Checklist

    Image 3308290 SATA cable SATA power cable Dual RS-232 cable Dual USB cable (w bracket) Utility CD Mini jumper pack (2.0mm) Table 3-1: Packing List Items 3.3.2 Optional Components The following optional components are available for the 3308290. Page 42...

  • Page 43: Table 3-2: Optional Items

    Item and Part Number Image Winbond TPM module (P/N: 1007810) Infineon TPM module (P/N: 1007790) Audio kit_ 7.1 Channel (P/N: 1007760) CPU cooler (P/N: 2107703) FDD cable (P/N:1207764) PS2 cable for KB and MS (P/N: 1207794) Table 3-2: Optional Items Page 43...

  • Page 44: Connector Pinouts

    Chapter Connector Pinouts Page 44...

  • Page 45: Peripheral Interface Connectors

    Figure 4-1 shows the on-board peripheral connectors, rear panel peripheral connectors and on-board jumpers. Figure 4-1: Connector and Jumper Locations 4.1.2 Peripheral Interface Connectors Table 4-1 shows a list of the peripheral interface connectors on the 3308290. Connector Type Label...

  • Page 46: External Interface Panel Connectors

    USB connectors 8-pin header USB1 USB connectors 8-pin header USB2 Table 4-1: Peripheral Interface Connectors 4.1.3 External Interface Panel Connectors Table 4-2 lists the rear panel connectors on the 3308290. Connector Type Label Ethernet connector RJ-45 LAN1 Ethernet connector RJ-45...

  • Page 47: Internal Peripheral Connectors

    See Figure 4-2 CN Location: See Table 4-3 CN Pinouts: The 9-pin audio connector is connected to a High Definition Audio kit. The audio kit, with an embedded HD Audio codec enables sound input and output to the 3308290 Page 47...

  • Page 48: Backlight Inverter Connector

    Figure 4-2: Audio Connector Location (9-pin) PIN NO. DESCRIPTION PIN NO. DESCRIPTION SYNC BITCLK SDOUT PCBEEP SDIN RST# +12V Table 4-3: Audio Connector Pinouts (9-pin) 4.2.2 Backlight Inverter Connector CN Label: INVERTER1 5-pin wafer (1x5) CN Type: See Figure 4-3 CN Location: See Table 4-4 CN Pinouts:...

  • Page 49: Compactflash® Slot

    The backlight inverter connector provides the backlight on the LCD display connected to the 3308290 with +12V of power. Figure 4-3: Panel Backlight Connector Pinout Locations PIN NO. DESCRIPTION BRIGHTNESS BL_EN Table 4-4: Panel Backlight Connector Pinouts 4.2.3 CompactFlash® Slot...

  • Page 50: Figure 4-4: Cf Card Socket Location

    CN Location: See Table 4-5 CN Pinouts: A CF Type I or Type II memory card is inserted to the CF socket on the solder side of the 3308290. Figure 4-4: CF Card Socket Location PIN NO. DESCRIPTION PIN NO.

  • Page 51: Digital Input/Output Connector

    PIN NO. DESCRIPTION PIN NO. DESCRIPTION IOW# VCC1 VCC2 CSEL# VS2# RESET# WAIT# INPACK# REG# BVD2 DATA 0 BVD1 DATA 1 DATA 8 DATA 2 DATA 9 IOCS16# DATA 10 CD2# GROUND Table 4-5: CF Card Socket Pinouts 4.2.4 Digital Input/Output Connector CN Label: DIO1 10-pin header (2x5)

  • Page 52: Fan Connector (Cpu)

    Figure 4-5: DIO Connector Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION Output 3 Output 2 Output 1 Output 0 Input 3 Input 2 Input 1 Input 0 Table 4-6: DIO Connector Pinouts 4.2.5 Fan Connector (CPU) CN Label: CPU_FAN1 4-pin header CN Type: See Figure 4-6 CN Location:...

  • Page 53: Fan Connector (System)

    The cooling fan connector provides a 12V, 500mA current to a CPU cooling fan. The connector has a "rotation" pin to get rotation signals from fans and notify the system so the system BIOS can recognize the fan speed. Please note that only specified fans can issue the rotation signals.

  • Page 54: Figure 4-7: +12V Fan Connector Location

    See Figure 4-7 CN Location: See Table 4-8 CN Pinouts: The cooling fan connector provides a 12V, 500mA current to a system cooling fan. The connector has a "rotation" pin to get rotation signals from fans and notify the system so the system BIOS can recognize the fan speed.

  • Page 55: Floppy Disk Connector

    4.2.7 Floppy Disk Connector CN Label: FDD1 34-pin header (2x17) CN Type: See Figure 4-8 CN Location: See Table 4-9 CN Pinouts: The floppy disk connector is connected to a floppy disk drive. Figure 4-8: FDD Connector Location PIN NO. DESCRIPTION PIN NO.

  • Page 56: Front Panel Connector

    PIN NO. DESCRIPTION PIN NO. DESCRIPTION MOTOR ENABLE A# DRIVE SELECT B# DRIVE SELECT A# MOTOR ENABLE B# DIRECTION# STEP# WRITE DATA# WRITE GATE# TRACK 0# WRITE PROTECT# READ DATA# SIDE 1 SELECT# DISK CHANGE# Table 4-9: FDD Connector Pinouts 4.2.8 Front Panel Connector CN Label: F_PANEL1...

  • Page 57: Ide Connector

    Figure 4-9: Front Panel Connector Location FUNCTION DESCRIPTION FUNCTION DESCRIPTION Power LED Speaker Ground Power Button PWRBTN+ Speaker PWRBTN- Reset HDD LED Reset- HDDLED- Table 4-10: Front Panel Connector Pinouts 4.2.9 IDE Connector CN Label: PIDE1 40-pin header (2x20) CN Type: See Figure 4-10 CN Location: Page 57...

  • Page 58: Figure 4-10: Ide Device Connector Locations

    See Table 4-11 CN Pinouts: One 40-pin IDE device connector on the 3308290 supports connectivity to two hard disk drives. Figure 4-10: IDE Device Connector Locations Page 58...

  • Page 59: Infrared Connector

    PIN NO. DESCRIPTION PIN NO. DESCRIPTION RESET# GROUND DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14 DATA 0 DATA 15 GROUND IDE DRQ GROUND...

  • Page 60: Keyboard Connector

    Figure 4-11: Infrared Connector Pinout Locations PIN NO. DESCRIPTION IR-RX IR-TX Table 4-12: Infrared Connector Pinouts 4.2.11 Keyboard Connector CN Label: 5-pin header (1x5) CN Type: See Figure 4-12 CN Location: See Table 4-13 CN Pinouts: Page 60...

  • Page 61: Figure 4-12: Keyboard Connector Location

    The keyboard connector can be connected to a standard PS/2 cable or PS/2 cable to add keyboard and mouse functionality to the system. Figure 4-12: Keyboard Connector Location PIN NO. DESCRIPTION KEYBOARD CLOCK KEYBOARD DATA GROUND Table 4-13: Keyboard Connector Pinouts Page 61...

  • Page 62: Lvds Connector

    4.2.12 LVDS Connector CN Label: LVDS1 30-pin crimp (2x15) CN Type: See Figure 4-13 CN Location: See Table 4-14 CN Pinouts: The 30-pin LVDS LCD connector can be connected to single channel or dual channel, 18-bit or 36-bit LVDS panel. Figure 4-13: LVDS LCD Connector Pinout Locations PIN NO.

  • Page 63: Mouse Connector

    PIN NO. DESCRIPTION PIN NO. DESCRIPTION GROUND GROUND LVDSB_DATA0 LVDSB_DATA0# LVDSB_DATA1 LVDSB_DATA1# LVDSB_DATA2 LVDSB_DATA2# LVDSB_CLK LVDSB_CLK# LVDSB_DATA3 LVDSB_DATA3# GROUND GROUND VCC/VCC3 VCC/VCC3 VCC/VCC3 VCC/VCC3 Table 4-14: LVDS LCD Port Connector Pinouts 4.2.13 Mouse Connector CN Label: 5-pin header (1x5) CN Type: See Figure 4-14 CN Location: See Table 4-15...

  • Page 64: Parallel Port Connector

    Figure 4-14: Mouse Connector Location PIN NO. DESCRIPTION MOUSE CLOCK MOUSE DATA GROUND Table 4-15: Mouse Connector Pinouts 4.2.14 Parallel Port Connector CN Label: LPT1 26-pin box header CN Type: See Figure 4-15 CN Location: See Table 4-16 CN Pinouts: Page 64...

  • Page 65: Figure 4-15: Parallel Port Connector Location

    The 26-pin parallel port connector connects to a parallel port connector interface or some other parallel port device such as a printer. Figure 4-15: Parallel Port Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION STROBE# DATA 0 DATA 1 DATA 2 DATA 3 DATA 4 DATA 5...

  • Page 66: Sdvo Connector

    PIN NO. DESCRIPTION PIN NO. DESCRIPTION GROUND Table 4-16: Parallel Port Connector Pinouts 4.2.15 SDVO Connector CN Label: SDVO1 3-pin header CN Type: See Figure 4-15 CN Location: See Table 4-16 CN Pinouts: The 3-pin SDVO connector connects to a compatible SDVO video card. SDVO video cards enable dual video by utilizing a direct connection to the SDVO connection to the GMCH.

  • Page 67: Sata Drive Connectors

    PIN NO. DESCRIPTION SDVO_CTRLCLK SDVO_CTRLDATA Table 4-17: SDVO Connector Pinouts 4.2.16 SATA Drive Connectors S_ATA1, S_ATA2 and S_ATA3 CN Label: 7-pin SATA drive connectors CN Type: See Figure 4-17 CN Location: See Table 4-18 CN Pinouts: The SATA drive connectors are each connected to second generation SATA drives. Second generation SATA drives transfer data at speeds as high as 3.0 Gb/s.

  • Page 68: Serial Port Connectors

    PIN NO. DESCRIPTION Table 4-18: SATA Drive Connector Pinouts 4.2.17 Serial Port Connectors COM1 and COM2 CN Label: 10-pin header (2x5) CN Type: See Figure 4-18 CN Location: See Table 4-19 CN Pinouts: The 10-pin serial port connectors provide RS-232 serial communications channels. The serial port connector can be connected to external RS-232 serial port devices.

  • Page 69: Trusted Platform Module (Tpm) Connector

    Figure 4-18: COM Connector Pinout Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION Data Carrier Direct (DCD) Data Set Ready (DSR) Receive Data (RXD) Request To Send (RTS) Transmit Data (TXD) Clear To Send (CTS) Data Terminal Ready (DTR) Ring Indicator (RI) Ground (GND) Table 4-19: COM Connector Pinouts 4.2.18 Trusted Platform Module (TPM) Connector...

  • Page 70: Figure 4-19: Tpm Connector Pinout Locations

    Figure 4-19: TPM Connector Pinout Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION FWHPCLK GND2 LFRAME# PCIRST# Page 70...

  • Page 71: Tv Out Connector

    PIN NO. DESCRIPTION PIN NO. DESCRIPTION LAD3 LAD2 VCC3 LAD1 LAD0 SMBCLK SMBDATA 3VDUAL SERIRQ CLKRUN# LPCPD# LDRQ# Table 4-20: TPM Connector Pinouts 4.2.19 TV Out Connector CN Label: 6-pin header (2x3) CN Type: See Figure 4-20 CN Location: See Table 4-21 CN Pinouts: The 2x3 pin TV out connector connects to a TV output by using an S-Video or RCA connector.

  • Page 72: Usb Connectors (Internal)

    Figure 4-20: TV Connector Pinout Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION S-Video Connector AGREEN_Y ARED_C RCA Connector (only video signal) ABLUE_CVBS Table 4-21: TV Port Connector Pinouts 4.2.20 USB Connectors (Internal) USB1 and USB2 CN Label: 8-pin header (2x4) CN Type: See Figure 4-21 CN Location:...

  • Page 73: External Peripheral Interface Connector Panel

    DATA+ DATA- Table 4-22: USB Port Connector Pinouts 4.3 External Peripheral Interface Connector Panel Figure 4-22 shows the 3308290 external peripheral interface connector (EPIC) panel. The 3308290 EPIC panel consists of the following: 2 x RJ-45 LAN connectors Page 73...

  • Page 74: Lan Connectors

    See Table 4-23 CN Pinouts: The 3308290 is equipped with two built-in RJ-45 Ethernet controllers. The controllers can connect to the LAN through two RJ-45 LAN connectors. There are two LEDs on the connector indicating the status of LAN. The pin assignments are listed in the following...

  • Page 75: Usb Connector

    CN Type: See Figure 4-22 CN Location: See Table 4-25 CN Pinouts: The 3308290 has four external USB 2.0 ports. The ports connect to both USB 2.0 and USB 1.1 devices. PIN NO. DESCRIPTION PIN NO. DESCRIPTION USBV3L 5V USBV3L 5V...

  • Page 76: Vga Connector

    CN Label: 15-pin Female CN Type: See Figure 4-22 CN Location: See Figure 4-24 and Table 4-26 CN Pinouts: The 3308290 has a single 15-pin female connector for connectivity to standard display devices. Figure 4-24: VGA Connector DESCRIPTION DESCRIPTION GREEN BLUE...

  • Page 77: Installation

    Chapter Installation Page 77...

  • Page 78: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the 3308290. Dry climates are particularly susceptible to ESD. It is therefore critical that whenever the 3308290 or any other electronic component is handled, the...

  • Page 79: Installation Notices

    Before and during the installation of the 3308290 DO NOT do the following: DO NOT remove any of the stickers on the PCB board. These stickers are required for warranty validation.

  • Page 80: Unpacking

    When the 3308290 is unpacked, please do the following: Follow the anti-static precautions outlined above. Make sure the packing box is facing upwards so the 3308290 does not fall out of the box. Make sure all the components in the checklist shown in Chapter 3 are present.

  • Page 81: Cpu, Cooling Kit And Dimm Installation

    Running a CPU without a cooling kit may also result in injury to the user. The CPU, CPU cooling kit and DIMM are the most critical components of the 3308290. If one of these component is not installed the 3308290 cannot run.

  • Page 82: Figure 5-1: Make Sure The Cpu Socket Retention Screw Is Unlocked

    Unlock the CPU retention screw. When shipped, the retention screw of the Step 1: CPU socket should be in the unlocked position. If it is not in the unlocked position, use a screwdriver to unlock the screw. Figure 5-1: Make sure the CPU socket retention screw is unlocked Inspect the CPU socket.

  • Page 83: Cooling Kit Installation

    Lock the retention screw. Rotate the retention screw clockwise into the locked Step 7: position. Step 0: Figure 5-2: Lock the CPU Socket Retention Screw 5.4.2 Cooling Kit Installation Figure 5-3: Cooling Kit cooling kits can be purchased separately. The cooling kits comprise a CPU heat sink and a cooling fan.

  • Page 84: Figure 5-4: Cooling Kit Support Bracket

    WARNING: Do not wipe off (accidentally or otherwise) the pre-sprayed layer of thermal paste on the bottom of the heat sink. The thermal paste between the CPU and the heat sink is important for optimum heat dissipation. To install the cooling kit, please follow the steps below. Align the support bracket.

  • Page 85: Figure 5-5: Securing The Cooling Kit

    Figure 5-5: Securing the Cooling Kit Tighten the screws. Use a screwdriver to tighten the four screws. Tighten each Step 4: nut a few turns at a time and do not over-tighten the screws. Over tightening can cause damage to the CPU. Connect the fan cable.

  • Page 86: Dimm Installation

    5.4.3 DIMM Installation WARNING: Using incorrectly specified DIMM may cause permanently damage the 3308290. Please make sure the purchased DIMM complies with the memory specifications of the 3308290. DIMM specifications compliant with the 3308290 are listed in Chapter 2. To install a DIMM into a DIMM socket, please follow the steps below.

  • Page 87: Jumper Settings

    OPEN a jumper means removing the plastic clip from a jumper. Figure 5-8: Jumper Locations Before the 3308290 is installed in the system, the jumpers must be set in accordance with the desired configuration. The jumpers on the 3308290 are listed below. Description...

  • Page 88: Clear Cmos Jumper

    See Figure 5-9 Jumper Location: If the 3308290 fails to boot due to improper BIOS settings, the clear CMOS jumper clears the CMOS data and resets the system BIOS information. To do this, use the jumper cap to close pins 2 and 3 for a few seconds then reinstall the jumper clip back to pins 1 and 2.

  • Page 89: Cf Card Setup

    Figure 5-9: Clear CMOS Jumper 5.5.2 CF Card Setup Jumper Label: JCF1 2-pin header Jumper Type: See Table 5-3 Jumper Settings: See Figure 5-10 Jumper Location: The CF Card Setup jumper sets the CF Type I card or CF Type II cards as either the slave device or the master device.

  • Page 90: Serial Port Ir Mode Selection

    Figure 5-10: CF Card Setup Jumper Location 5.5.3 Serial Port IR Mode Selection Jumper Label: 10-pin header Jumper Type: See Table 5-4 Jumper Settings: See Figure 5-11 Jumper Location: The Serial Port IR Mode Selection jumper configures pin 9 on COM 1 and COM 2 as either a +5 V or +12 V power source or as a ring-in (RI) line.

  • Page 91: Lvds Voltage Selection

    Figure 5-11: Serial Port IR Mode Selection Jumper Location 5.5.4 LVDS Voltage Selection WARNING: Permanent damage to the screen and 3308290 may occur if the wrong voltage is selected with this jumper. Please refer to the user guide that cam with the monitor to select the correct voltage.

  • Page 92: Lvds Screen Resolution Selection

    3-pin header Jumper Type: See Table 5-5 Jumper Settings: See Figure 5-12 Jumper Location: The LVDS Voltage Selection jumper allows the LVDS screen voltage to be set. The LVDS Voltage Selection jumper settings are shown in Table 5-5. LVDS Voltage Select Description Short 1-2 +3.3V LVDS...

  • Page 93: Pcie / Sdvo Selection Jumper

    See Figure 5-12 Jumper Location: The LVDS Screen Resolution Selection jumper allows the LVDS screen voltage to be set. The LVDS Screen Resolution Selection jumper settings are shown in Table 5-5. LVDS Resolution Select Description Open 640 x 480 (18-bit) Default Short 1-2 800 x 600 (18-bit)

  • Page 94: Figure 5-14: Pcie / Sdvo Selection Jumper

    2-pin headers Jumper Type: See Table 5-5 Jumper Settings: See Figure 5-12 Jumper Location: The PCIe / SDVO Selection Jumper allows the LVDS screen voltage to be set. The PCIe / SDVO Selection Jumper settings are shown in Table 5-5. JSDVO1 Description Short 1-2...

  • Page 95: Chassis Installation

    The 3308290 must be installed in a chassis with ventilation holes on the sides allowing airflow to travel through the heat sink surface. In a system with an individual power supply unit, the cooling fan of a power supply can also help generate airflow through the board surface.

  • Page 96: Channel Audio Kit Installation

    The optional 7.1 channel audio kit connects to the 9-pin audio connector on the 3308290. The audio kit consists of five audio jacks. One audio jack, Mic In, connects to a microphone. The remaining four audio jacks, Line-In, Front-Out, Rear-Out, and Center Subwoofer, connect to speakers.

  • Page 97: Dual Rs-232 Cable With Slot Bracket

    Mount the audio kit onto the chassis. Once the audio kit is connected to the Step 4: 3308290, secure the audio kit bracket to the system chassis. Connect the audio devices. Connect one speaker to the line-in audio jack, one Step 5: speaker to the line-out audio jack and a microphone to the mic-in audio jack.

  • Page 98: Usb Cable (Dual Port) With Slot Bracket

    0: 5.7.4 USB Cable (Dual Port) with Slot Bracket The 3308290 is shipped with a dual port USB 2.0 cable. To connect the USB cable connector, please follow the steps below. Locate the connectors. The locations of the USB connectors are shown in Step 1: Chapter 3.

  • Page 99: Figure 5-17: Dual Usb Cable Connection

    Step 3: Insert the cable connectors. with the USB connectors on the 3308290, connect the cable connectors to the onboard connectors. Figure 5-17: Dual USB Cable Connection Attach the bracket to the chassis. The USB 2.0 connectors are attached to a Step 4: bracket.

  • Page 100: Sata Drive Connection

    5.7.5 SATA Drive Connection The 3308290 is shipped with two SATA drive cables and one SATA drive power cable. To connect the SATA drives to the connectors, please follow the steps below. Locate the connectors. The locations of the SATA drive connectors are shown Step 1: in Chapter 3.

  • Page 101: External Peripheral Interface Connection

    USB devices VGA monitors To install these devices, connect the corresponding cable connector from the actual device to the corresponding 3308290 external peripheral interface connector making sure the pins are properly aligned. 5.8.1 LAN Connection There are two external RJ-45 LAN connectors. The RJ-45 connectors enable connection to an external network.

  • Page 102: Usb Device Connection

    5.8.2 USB Device Connection There are two external USB 2.0 connectors. Both connectors are perpendicular to the 3308290. To connect a USB 2.0 or USB 1.1 device, please follow the instructions below. Located the USB connectors. The locations of the USB connectors are shown Step 1: in Chapter 4.

  • Page 103: Vga Monitor Connection

    Step 0: 5.8.3 VGA Monitor Connection The 3308290 has a single female DB-15 connector on the external peripheral interface panel. The DB-15 connector is connected to a CRT or VGA monitor. To connect a monitor to the 3308290, please follow the instructions below.
  • Page 104 Figure 5-21: VGA Connector Secure the connector. Secure the DB-15 VGA connector from the VGA monitor Step 4: to the external interface by tightening the two retention screws on either side of the connector. Step 0: Appendix Appendix Page 104...
  • Page 105 We will do our best to support your products, projects and business. Address: Global American, Inc. 17 Hampshire Drive Hudson, NH 03051 Telephone: Toll Free U.S. Only (800) 833-8999 (603) 886-3900 FAX: (603) 886-4545 Website: http://www.globalamericaninc.com Support: Technical Support at Global American Page 105...
