- Page 1 User’s Manual Full Size PICMG 3308130 Version 1.0,...
- Page 2 Copyrights This manual is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer. In general, the manufacturer will not be liable for any direct, indirect, special, incidental or consequential damages arising from the use of inability to use the product or documentation, even if advised of the possibility of such...
-
Page 3: Table Of Contents
Table of Contents Introduction ............5 Product Description ............5 Checklist................6 Specifications..............7 Board Dimensions.............8 Installations ............9 Installing the CPU............10 ATX Power Installation ...........11 Installing the Memory ............11 Setting the Jumpers............13 Connectors on 3308130 ...........17 3308130 User’ s Manual... - Page 4 This page is intentionally left blank. 3308130 User’ s Manual...
-
Page 5: Introduction
INTRODUCTION Introduction Product Description The 3308130 Intel Xeon full size CPU card is based on the Intel ET7500/ET7501 chipset. With two 184-pin DDR memory sockets, up to 4GB of memory is supported. A dual-channel DDR-200/266 memory interface provides a maximum memory bandwidth of 3.2 GB/s through a 144-bit wide, 200/266 MHz Double Data Rate SDRAM memory interface with densities up to 512 megabits is supported. -
Page 6: Checklist
INTRODUCTION Checklist Your 3308130 package should include the items listed below. • The 3308130 Industrial CPU Card • This User’s Manual • 2 IDE Ribbon Cable • 1 Floppy Ribbon Connector • 2 Serial Port Ribbon Cable and 1 Parallel Port Attached to a Mounting Bracket •... -
Page 7: Specifications
Keyboard and PS/2 type connectors Mouse ISA High Drive Winbond W83628, W83629 PCI to ISA Bridge Chip Power Connector ATX 12V power connector Form Factor Full Size CPU Card Dimensions 338mm x 122mm (13.3” x 4.8”) 3308130 User’ s Manual... -
Page 8: Board Dimensions
INTRODUCTION Board Dimensions 3308130 User’ s Manual... -
Page 9: Installations
INTRODUCTION Installations This section provides information on how to use the jumpers and connectors on the 3308130 in order to set up a workable system. The topics covered are: Installing the CPU................10 ATX Power Installation..............11 Installing the Memory..............11 Setting the Jumpers ................. -
Page 10: Installing The Cpu
INTRODUCTION Installing the CPU The 3308130 CPU Card supports a CPU socket for Intel Xeon processors. This socket comes with a lever to secure the processor. Raise this lever to about a 90° angle to allow the insertion of the processor. Place the processor into the socket by making sure the notch on the corner of the CPU corresponds with the notch on the inside of the socket. -
Page 11: Atx Power Installation
INTRODUCTION ATX Power Installation The system power is provided to the 3308130 CPU card with the J2 and J15 ATX power connectors. Please note that the J15 external ATX power connector should be connected to the backplane for 3308130 to function. - Page 12 INTRODUCTION 3. To remove the DDR module, press the clips with both hands. 3308130 User’ s Manual...
-
Page 13: Setting The Jumpers
INTRODUCTION Setting the Jumpers Jumpers are used on 3308130 to select various settings and features according to your needs and applications. Contact your supplier if you have doubts about the best configuration for your needs. The following lists the connectors on 3308130 and their respective functions. -
Page 14: Jumper Locations On 3308130
INTRODUCTION Jumper Locations on 3308130 3308130 User’ s Manual... -
Page 15: Configuring The Cpu Frequency
INTRODUCTION Configuring the CPU Frequency The 3308130 CPU card does not provide DIP switches to configure the processor speed (CPU frequency). SW1: LVDS Resolution Select The table below shows the switch settings for the LVDS resolution. Resolution SW1(1-4) Resolution SW1(1-4) -
Page 16: Jp1, Jp2, Jp3: Rs232/422/485 (Com2) Selection
Use JP5, a 3-pin header, to clear the CMOS contents. Note that the ATX-power connector should be disconnected from the CPU card before clearing CMOS. Setting Function Pin 1-2 Normal Short/Closed Pin 2-3 Clear CMOS Short/Closed 3308130 User’ s Manual... -
Page 17: Connectors On 3308130
INTRODUCTION Connectors on 3308130 The connectors on 3308130 allows you to connect external devices such as keyboard, floppy disk drives, hard disk drives, printers, etc. The following table lists the connectors on 3308130 and their respective functions. Connector Locations on 3308130............ 18 IDE1, IDE2: EIDE Connectors............ -
Page 18: Connector Locations On 3308130
INTRODUCTION Connector Locations on 3308130 3308130 User’ s Manual... -
Page 19: Ide1, Ide2: Eide Connectors
Ground Protect pin DRQ1 Ground Host IOW Ground Host IOR Ground IOCHRDY Host ALE DACK1 Ground IRQ15 No connect IDE2 Address 1 No connect Address 0 Address 2 Chip select 0 Chip select 1 Activity Ground 3308130 User’ s Manual... -
Page 20: Fdd1: Floppy Drive Connector
Pin # Signal Name Ground +12V Rotation detection FAN3: System Fan Power Connector FAN3 is a 3-pin header for the system fan. The fan must be a 12V fan. Pin # Signal Name Ground +12V Rotation detection 3308130 User’ s Manual... -
Page 21: Fan1: Auxiliary Fan Power Connector
Orientation is not required when making a connection to this header. HDD LED: Pins 8, 16 (HDD Active, 5V) This connector connects to the hard drive activity LED on control panel. This LED will flash when the HDD is being accessed. 3308130 User’ s Manual... -
Page 22: J2: Atx 12V/+12V Power Connector
PD2, parallel data 2 Select PD3, parallel data 3 Ground PD4, parallel data 4 Ground PD5, parallel data 5 Ground PD6, parallel data 6 Ground PD7, parallel data 7 Ground ACK, acknowledge Ground Busy Ground Paper empty Ground Select 3308130 User’ s Manual... -
Page 23: J4, J5: Com1 And Com2 Serial Ports Connector
The following table shows the pin outs of the USB pin headers connectors. Overall, the two pin headers support four USB ports. Signal Name Signal Name Ground USB0- USB1+ USB0+ USB1- Ground Signal Name Signal Name Ground USB2- USB3+ USB2+ USB3- Ground 3308130 User’ s Manual... -
Page 24: J10, J9: Lvds Connectors (1St Channel, 2Nd Channel)
N.C. N.C. HSYNC VSYNC J12: PS/2 Keyboard and Mouse Connector J12 uses a Y-cable with for a PS/2 keyboard and a PS/2 mouse. Pin # Signal Name Mouse data Keyboard data Ground Mouse Clock Keyboard Clock 3308130 User’ s Manual... -
Page 25: J13, J14: External Ps/2 Keyboard And Mouse Connector
Ground N.C. Ground Mouse clock J15: External ATX Power Connector Pin # Signal Name Ground PS-ON (soft on/off) 5VSB (Standby +5V) J16, J17: Gigabit LAN RJ45 Connectors J16 and J17 are the Gigabit LAN RJ45 connectors. 3308130 User’ s Manual... - Page 26 Any advice or comments about our products and service, or anything we can help you with please don’t hesitate to contact us. We will do our best to support your products, projects and business. Address: Global American, Inc. 17 Hampshire Drive Hudson, NH 03051 Telephone: Toll Free (U.S. Only) 800-833-8999...
