  • Page 1 User’s Manual 3304280...

  • Page 2: Table Of Contents

    Fast Ethernet Connectors ............20 LAN Port ......................20 LAN LED Indicator on RJ-45 connector ............20 Power Connector ..............21 Switches and Indicators ............22 Interface Connectors HDD, FDD ..........24 Floppy Disk Drive Connector ......................24 Enhanced IDE Connector ............25 3304280 User's Manual...
  • Page 3 BIOS Features Setup ..................43 Chipset Features Setup ...................46 Power Management Setup ................48 PnP/PCI Configuration..................49 Integrated Peripherals ..................50 POST Codes ................52 Howto : Flash the BIOS ............59 What if things go wrong ..................60 Warranty ................61 3304280 User's Manual...

  • Page 4: Introduction

    386-based or 486-based to 586-level without some additional worries, because a NS Geode GX1-300 processor and 64MB SDRAM are mounted on 3304280 . No longer worry about the CPU installation , don’t need t o set any jumpers of speed or voltage of processor .

  • Page 5: Specifications

    • Keyboard and Mouse Connectors : external PS/2 KB/Mouse port (2-in- 1 mini DIN) and onboard AT Keyboard port (6-pin box header) • Audio Chipset: NS CS5530A, AC97 2.0 compliant, Multistream Direct Sound and Direct Sound 3D acceleration. (Line-in, CD Audio in, MIC in, Speaker out) 3304280 User's Manual...

  • Page 6: Network Interface Controller

    (CS5530A) TFT LCD TV-Out (3304280VL including) • Connectors : external DB15 for CRT on-board • Resolution: >3304280/VLC CRT resolutions up to 1280x1024 @ 256 colors or 1204x768 @ 16bit or 800x600 @ 24bit . Panel resolutions up to 1280x1024 @ 8bpp or 1024x768 @ 16bpp or 800x600 @ 24bpp.
  • Page 7 3. Use a grounded wrist strap when handling computer components. 4. Place components on a grounded antistatic pad or on the bag that came with the Single Board Computer, whenever components are separated from the system 3304280 User's Manual...

  • Page 8: Ordering Codes

    PACKING LIST 3304280 1 x CD-ROM (driver) 3304280 Quick Installation Before up and running, please make sure the package contains all of above accessories. If any of the above items is damaged or missing, contact your vendor immediately. Ordering Codes 3304280A 3.5"...

  • Page 9: Board Image

    Board Image 3304280 User's Manual...

  • Page 10: Board Layout

    Board Layout IDE1 AUDIO LCD3 LCD2 FDD1 LAN1 INV1 1 2 3 4 USB1 LPT1 PLED1 VGA1 RES1 ATX1 HLED1 KBM2 Geode SIR1 GX1- 300B-55 KBM1 COM1 DiskOnChip 2000 COM2 PWR1 JFRT1 PC104 3304280 User's Manual...

  • Page 11: Jumper/Connector Quick Reference

    Jumper/Connector Quick Reference Jumpers Label Function Clear CMOS DOC Address Select COM2 RS-232C / 422 / 485 Select ion INV1 (INVERTER LCD type selection RS422/ 485 connect or 3304280 User's Manual...

  • Page 12: Jumper/Connector Quick Reference

    PWR1 Small 4P Power Connector ATX1 ATX Power Connector DOC 2000 Disk On Chip 2000 RES1 Reset Switch PC104 ISA PC-104 Interface PLED1 Power LED HLED1 HDD LE D JFRT1 Front Panel Connector SODIM1 SODIMM Sock et 3304280 User's Manual...

  • Page 13: Cmos Jumper Settings

    CMOS Jumper Settings CMOS Operation (J1) Type : J1: onboard 3-pin header If the 3304280 refuses to boot due to inappropriate CMOS settings here is how to proceed to clear (reset) the CMOS to its default values. CMOS Setup (J1)

  • Page 14: Doc Address Select

    DOC Address Select DOC Address Select (J2) Type : J2: onboard 4-pin(2*2) header Port Address D800h D000h Disable default setting D800h 1 2 3 4 Geode GX1- 300B-55 DiskOnCh ip 2000 3304280 User's Manual...

  • Page 15: Serial Port Selection (Rs232C/422/485)

    Pin Defined: RS-232C RS-422 RS-485 Pin1 : RTx+ Pin2 : RTx- Pin8 : Pin9 : J5 Selection RS-232C RS-422 RS-485 default setting RS-232C 1 2 3 4 Geode GX1- 300B-55 2 4 6 1 3 5 DiskOnChip 2000 3304280 User's Manual...

  • Page 16: Lcd Inverter

    RS485- RS-422 RS485+ RS485- RS422+ RS422- LCD Inverter Connector : INV1 Type : Onboard 5-pin mini boxheader Descrip tion Descriptio n +12 V PPEN VEEP Default setting: 3.3V J V 9 Geode GX1- 300B-55 DiskOnCh ip 2000 3304280 User's Manual...

  • Page 17: Watchdog Timer

    Look subsequntly at the program example how to pass the value to the watchdog timer. Timeout Table Level Value Seconds Level Value Seconds Level Value Seconds 3304280 User's Manual...
  • Page 18 3304280 User's Manual...
  • Page 19 DX mov DX,WDT_DIS ; Disable Timer in AX,DX pop DX ; Restore DX,AX pop AX WT_Disable push AX ; save AX,DX push DX mov DX,WDT_DIS ; Disable Timer in AX,DX pop DX ; restore DX,AX pop AX 3304280 User's Manual...

  • Page 20: Fast Ethernet Connectors

    Fast Ethernet Connectors LAN Port Connector : LAN1, LAN2 Type : external RJ-45 on bracket Desciption LAN LED Indicator on RJ-45 connector LAN 1 & L AN 2 1 2 3 4 Geode GX1- 300B-55 DiskOnChip 2000 3304280 User's Manual...

  • Page 21: Power Connector

    1 2 3 Geode GX1- 300B-55 DiskOnCh ip 200 0 PWR1 1 2 3 4 Power Connector : ATX1 Connector : ATX1 (for ATX function only, optional) Type : onboard small 4P connector Description Description +5VSB PSON 3304280 User's Manual...

  • Page 22: Switches And Indicators

    Type : onboard 8-pin(2*4) header Ju mp er Description PSON ATX soft power switch Reset function External SMI SPEAKER Speaker 1 2 3 4 Geode GX1- 300B-55 DiskOnCh ip 2000 Power Switch PSON Reset Switch ESMI Speaker SPEAKER+ SPEAKER- 3304280 User's Manual...
  • Page 23 Descrip tion Connector : HLED1 Type : onboard 2-pin header Descrip tion HLED1+ Connector : PLED1 Type : onboard 2-pin header Descrip tion PLED1+ 1 2 3 4 PLED1 Geode HLED1 GX1- 300B-55 DiskOnCh ip 2000 RES1 3304280 User's Manual...

  • Page 24: Interface Connectors Hdd, Fdd

    #DRIVER SELE CT B #DRIVER SELE CT A #MOT OR E NABL E B #DIRECTION #STEP #WRITE DATA #WRITE GATE #TRA CK 0 #WRITE PROTECT #READ DATA #HEAD SELECT #DISK CHANGE 1 2 3 4 Geode GX1- 300B-55 DiskOnChip 2000 3304280 User's Manual...

  • Page 25: Enhanced Ide Connector

    Type : onboard 40-pin box headers Descr iption Descrip tion #RESET #IOW #IOR #IORDY IDESEL #DACK ADDR1 CBLID ADDR0 ADDR2 #CS0 #CS1(#HD SELET1) #ACT 1 2 3 4 Geode GX 1- 3 0 0 B - 5 5 DiskOnChip 2000 3304280 User's Manual...

  • Page 26: Peripheral Port

    Description #STROBE #AUTO FEED DATA0 #ERROR DATA1 #INITIALIZE DATA2 #SELECT INPUT DATA3 DATA4 DATA5 DATA6 DATA7 #ACKNOWLEDGE BUSY PAPER EMPTY SELECT 2 6 1 4 1 2 3 4 Geode GX1- 300B-55 1 3 1 DiskOnChip 2000 3304280 User's Manual...

  • Page 27: Usb Ports

    Descrip tion Description DATA- DATA+ Connector : SIR Type : onboard 5-pin header Description Description IRRX IRTX 1 2 3 4 P a r t 1 P a r t 0 Geode GX1- 300B-55 DiskOnChip 2000 SI R 3304280 User's Manual...

  • Page 28: Crt Svga

    Descrip tion Description KB-DATA MS-DATA KB-CLK MS-CLK Note: KB1 supports PS/2 keyboard direc tly, and PS/2 m ouse suppoted with the additional PS2 1-to-2 cable in the standard packing. VGA1 Geode GX1- 300B-55 KBM1 DiskOnChip 2000 KBM2 3304280 User's Manual...

  • Page 29: Com1 & Com2 For Rs-232C Port

    Connector : COM1 & COM2 Type : onboard 15-pin D-sub male connector (COM1) and 10-pin box header(COM2) Description Description RT S 1 2 3 4 C OM1 Geode GX1- 300B-55 DiskOnCh ip 2000 C O M 2 3304280 User's Manual...

  • Page 30: Compact Flash Connector

    44 +5V 28 DATA12 45 DASP 29 DATA13 46 DIAG 30 DATA14 47 DATA8 31 DATA15 48 DATA9 32 CS#3 49 DATA10 33 GND 50 GND 34 IO READ 1 2 3 4 Geode GX1- 300B-55 DiskOnChip 2000 3304280 User's Manual...

  • Page 31: Compact Flash Disk

    For more information on Compact Flash disk, visit Pretec Web site at http:// www.pretec.com where you can find the utilities manual, data sheets and application notes. In addition, you can find the latest Compact Flash disk utilities. 3304280 User's Manual...

  • Page 32: Audio Connector

    Audio Connector Connector : AUDIO Type :Onboard 10-pin box header Descrip tion Descrip tion LINE-L_IN LINE-R_IN MIC_IN LINE-L_OUT LINE-R_OUT AU DI O 1 2 3 4 Geode GX1- 300B-55 DiskOnCh ip 2000 3304280 User's Manual...

  • Page 33: System Resources

    Direct memory access controller 008F - 0091 Direct memory access controller 00A0 - 00A1 Programmable interrupt controller 00C0 - 00DF Motherboard Resources 00F0 - 00FF Nuneric data processor 0170 - 0177 Cyrix 5530 Bus Master PCI to Dual IDE Controller 3304280 User's Manual...
  • Page 34 F000 - F00F Primary Cx5530 Bus Master IDE Controller F000 - F00F Cyrix 5530 Bus Master PCI to Dual IDE Controller F000 - F007 Primary Cx5530 Bus Master IDE Controller F008 - F00F Seoncdary Cx5530 Bus Master IDE Controller 3304280 User's Manual...

  • Page 35: Flat Panel Vga

    Groun d Ground 3. 3V 3.3V VEEP Ground LPD0 LPD1 LPD2 LPD3 LPD4 LPD5 LPD6 LPD7 LPD8 LPD9 LPD10 LPD11 LPD12 LPD13 LPD14 LPD15 LPD16 LPD17 LPD18 LPD19 LPD20 LPD21 LPD22 LPD23 Groun d Ground FPSCLK FPVDDEN VBIASEN 3304280 User's Manual...

  • Page 36: Flat Panel Vga

    Flat Panel VGA Flat Panel VGA (LCD) : LCD3 Description Description Ground Ground LPD24 LPD25 LPD26 LPD27 LPD28 LPD29 LPD30 LPD31 LPD32 LPD33 LPD34 LPD35 Ground Ground DOTCLK(NC) LCD3 LCD2 1 2 3 4 Geode GX1- 300B-55 DiskOnChip 2000 3304280 User's Manual...

  • Page 37: Flat Panel Vga

    Flat Panel VGA (LCD): LCD2 Description Description Groun d Ground 3. 3V 3.3V VEEP Ground LPD0 LPD1 LPD2 LPD3 LPD4 LPD5 LPD6 LPD7 LPD8 LPD9 LPD10 LPD11 LPD12 LPD13 LPD14 LPD15 LPD16 Groun d Ground FPSCLK FPVDDEN VBIASEN 3304280 User's Manual...

  • Page 38: Lcd Type Selection

    12 x 2 bit TFT Analog TFT 18 x 2 bit TFT VMD15 16 bit DSTN 24 bit DSTN NOTES: (1) MD pins have internal pull-up resistors (2) 0 = Switch is SHORTED; 1 = Switch is OPEN 3304280 User's Manual...

  • Page 39: Award Bios Setup

    Use this menu for basic system configuration. BIOS FEATURES SETUP Use this menu to set the Advanced Features available on your system. CHIPSET FEATURES SETUP Use this menu to change the values in the chipset registers and optimize your system's performance. 3304280 User's Manual...
  • Page 40 IDE HDD AUTO DETECTION System will detect the HDD plugged and recognizes what type it is. SAVE & EXIT SETUP Save CMOS value changes to CMOS and exit setup. EXIT WITHOUT SAVE Abandon all CMOS value changes and exit setup. 3304280 User's Manual...

  • Page 41: Standard Cmos Setup

    5.25 in 5-1/4 inch PC-type standard drive 1.2M ; 5.25 in 5-1/4 inch AT-type high-density drive 720K ; 3.5 in 3-1/2 inch double-sided drive 1.44M ; 3.5 in 3-1/2 inch double-sided drive 2.88M ; 3.5 in 3-1/2 inch double-sided drive 3304280 User's Manual...
  • Page 42 All, But Diskette POST does not stop for diskette drive errors, but stops for all other errors. All, But Disk/Key POST does not stop for a keyboard or disk error, but stops for all other errors. 3304280 User's Manual...

  • Page 43: Bios Features Setup

    This feature allows you to run LAN Boot function. Select "Disnabled" not to access this function. Boot Sequence The BIOS attempts to load the operating system from the devices in the sequence selected in these items. The choices are : Floppy, HDD, CDROM, Disabled. 3304280 User's Manual...
  • Page 44 Enabled should correct this problem. If this field set Enabled, any I/O access on the ISA bus to the VGA card's palette registers will be reflected on the PCI bus. This will allow overlay cards to adapt to the changing palette colors. 3304280 User's Manual...
  • Page 45 'Mem ory'. This will tell you what segm ents (if any) are being shadowed For DOS you can use MSD.EXE to see what segments are claimed. CC000-CFFFF - D0000-D3FFF - D4000-D7FFF - D8000-DBFFF and DC000-DFFFF - Same as above. 3304280 User's Manual...

  • Page 46: Chipset Features Setup

    CPU must be delayed to allow for the completion of the I/O This item allows to you to derermine the recovery time allowed for 16-bit I/O. Choices are from 1 to 8 CPU Clocks. 3304280 User's Manual...
  • Page 47 USB Legacy Support This item lets you enable or disable the USB devices within the onboard BIOS. Built in CPU Audio Configuration options: Enabled and Disabled. When Enabled, select additional settings for SoundBlaster Compatibillity and MPU-401 functionallity 3304280 User's Manual...

  • Page 48: Power Management Setup

    After the selected period of HDD inactivity, the HDD will be shut down . Modem Use IRQ Name the interrupt request (IRQ) assigned to the modem (if any) on your system. Activity of the select ed IRQ always awakens the system. 3304280 User's Manual...

  • Page 49: Pnp/Pci Configuration

    Normally, you leave this field Disabled. Select Enabled to reset ESCD (Extend- ed System Configuration Date) when you exit Setup if you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the operating system cannot boot. 3304280 User's Manual...

  • Page 50: Integrated Peripherals

    When set to "Auto" mode, the system will detect if the hard drive supports Ultra DMA mode. KBC input clock This item will set the frequence of Keyboard controller. Onboad FDC Controller Configuration options: Enabled and Disabled.Enable the Floppy Disk Controller. The default setting is "Enabled". 3304280 User's Manual...
  • Page 51 Select a DMA channel if parallel Mode is set as ECP, ECP/EPP. EPP Mode Select Select a EPP Type if parallel Port is set as EPP, ECP/EPP. Onboard LAN Select "Enabled" if your system contains a LAN port. 3304280 User's Manual...

  • Page 52: Post Codes

    2. Enable keyboard interface. Reserved 1. Disable PS/2 mouse interface (optional). 2. Auto detect ports for keyboard & mouse followed by a port & interface swap (optional). 3. Reset keyboard for Winbond 977 series Super I/O chips. Reserved Reserved 3304280 User's Manual...
  • Page 53 RTC minute. 2. Load CMOS settings into BIOS stack. If CMOS checksum fails, use default value instead. Prepare BIOS resource map for PCI & PnP use. If ESCD is valid, take into consideration of the ESCD's legacy information. 3304280 User's Manual...
  • Page 54 Reserved Reserved Reserved Reset keyboard if Early_Reset_KB is defined e.g. Winbond 977 series Super I/O chips. See also POST 63h. Reserved Test DMA Channel 0 Reserved Test DMA Channel 1. Reserved Test DMA page registers. Reserved Reserved 3304280 User's Manual...
  • Page 55 CPU are not identical. Reserved Initialize USB Keyboard & Mouse. Reserved Test all memory (clear all extended memory to 0) Clear password according to H/W jumper (Optional) Reserved Display number of processors (multi-processor platform) Reserved 3304280 User's Manual...
  • Page 56 1. Assign resources to all ISA PnP devices. 2. Auto assign ports to onboard COM ports if the corresponding item in Setup is set to "AUTO". Reserved 1. Initialize floppy controller 2. Set up floppy related fields in 40:hardware. Reserved 3304280 User's Manual...
  • Page 57 3. If password is set, ask for password. Save all data in stack back to CMOS Initialize ISA PnP boot devices 1. USB final Initialization 2. Switch screen back to text mode Reserved NET PC: Build SYSID Structure. Reserved 3304280 User's Manual...
  • Page 58 Update keyboard LED & typematic rate 1. Build MP table 2. Build & update ESCD 3. Set CMOS century to 20h or 19h 4. Load CMOS time into DOS timer tick 5. Build MSIRQ routing table. Boot attempt (INT 19h) 3304280 User's Manual...

  • Page 59: Howto : Flash The Bios

    1. In CMOS Chipset Features Setup, Disable Video Bios Cacheable. 2. Hit Esc, F10, Save and exit. 3. Flash the BIOS and reboot 4. Enter CMOS Chipset Features Setup,and Enable Video Bios Cacheable, hit Esc, F10, Save and reboot. 3304280 User's Manual...

  • Page 60: What If Things Go Wrong

    BIOS not written for your motherboard they usually don't work. The MR Flash utilities communicate directly with your Flash Rom and always work. In most cases they flash a non-MRBIOS to your BIOS chip without problems. 3304280 User's Manual...

  • Page 61: Warranty

    Return authorization must be obtained from the vendor before returned merchandise will be accepted. Authorization can be obtained by calling or faxing the vendor and requesting a Return Merchandise Authorization (RMA) number. Returned goods should always be accompanied by a clear problem description. 3304280 User's Manual...
  • Page 62 Any advice or comments about our products and service, or anything we can help you with please don’t hesitate to contact with us. We will do our best to support you for your products, projects and business Global American Inc. Address: 17 Hampshire Drive...
