Configuration • Operation • Troubleshooting
User Manual 3015-5678
Revision 6, May 2020
Product Leadership • Training • Service • Reliability

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H25-IR PRO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bacharach H25-IR PRO

Summary of Contents for Bacharach H25-IR PRO

  • Page 1 Configuration • Operation • Troubleshooting User Manual 3015-5678 Revision 6, May 2020 Product Leadership • Training • Service • Reliability...
  • Page 2 Seller at the factory of manufacture and shown to Bacharach Inc.'s reasonable satisfaction to have been defective; provided that written notice of the defect shall have been given by Buyer to Bacharach Inc. within two (2) years after the date of delivery of this Product by Bacharach, Inc.

  • Page 3: Table Of Contents

    H25-IR PRO Instruction Manual Table of Contents CHAPTER 1: INTRODUCTION ............................... 1 1.1. Product Overview ..............................1 1.2. Conventions Used in This Manual ..........................1 1.3. Safety Precautions ..............................2 1.4. Features and Capabilities ............................3 1.5. Functional Overview ..............................3 1.5.1.
  • Page 4 H25-IR PRO Instruction Manual CHAPTER 5: OPERATION ..............................34 5.1. Introduction ................................34 5.2. Turning on the H25-IR PRO ............................36 5.3. Search Mode Screen ..............................36 5.3.1. Overview ..............................36 5.3.2. Display Styles (Graphic vs. Numeric) ......................36 5.3.3.
  • Page 5 H25-IR PRO Instruction Manual APPENDIX C: SUPPORTED GAS TYPES..........................106 C.1. Basic Gas Types ..............................106 C.2. Factory Gas Types ..............................108 APPENDIX D: DECLARATION OF CONFORMITY ..............ERROR! BOOKMARK NOT DEFINED. INDEX ....................................111 Ñ Ñ Ñ P/N: 3015-5678 Rev 6...
  • Page 6 H25-IR PRO Instruction Manual P/N: 3015-5678 Rev 6...
  • Page 7 Figure 6-1. Location of Fuse Holder ............................ 89 Figure 6-2. Probe Filter and “O” Ring Locations ........................90 Figure 6-3. Back Panel of the H25-IR Pro Showing Proper Orientation of the External Filter ..........91 Figure 6-4. Removing the Top Cover ..........................92 Figure 6-5.
  • Page 8 H25-IR PRO Instruction Manual viii P/N: 3015-5678 Rev 6...
  • Page 9 Table 5-35. Accessing the Sensor Data Screen ........................79 Table 5-36. Sensor Data Parameters and Sample Values ....................80 Table 5-37. Adjusting the H25-IR PRO to a Known External Leak Source ................81 Table 5-38. Configuring the H25-IR PRO to use a Factory Gas Type ..................84 Table 6-1.
  • Page 10 H25-IR PRO Instruction Manual Table 6-4. Probe Tip Filter Replacement Procedure ......................89 Table 6-5. Items Required for “O” Ring Replacement ......................90 Table 6-6. Probe “O” Ring Replacement Procedure ......................90 Table 6-7. Items Required for External Filter Replacement ....................90 Table 6-8.

  • Page 11: Chapter 1: Introduction

    HCFCs, HFCs and halogen gas compounds including R600a. This instrument can be used to locate and then quantify gas leaks, as well as log and totalize a group of leaks in a system. Building on the success of the H25-IR, the H25-IR PRO adds new groundbreaking capabilities that ensure accurate and reliable operation.

  • Page 12: Safety Precautions

    Bacharach Service Center. WARNING: This device uses type “F” fuses rated at 1.0 A, 250 VAC. Replace ONLY with Bacharach-approved fuses (see Spare Parts and Accessories on page 95 for the part number).

  • Page 13: Features And Capabilities

    1.5.1. Key System Components The front panel of the H25-IR PRO contains 7 membrane push buttons, probe connector, and a 128x64 dot LCD (Liquid Crystal Display) that provides a bright, high-contrast display for easy viewing. The instrument is housed in an all-metal case with adjustable handle.

  • Page 14: Operation Modes: Search Vs. Measure

    Introduction H25-IR PRO Instruction Manual 1.5.2. Operation Modes: Search vs. Measure The instrument has two modes of operation: Search and Measure. • Search mode is used to locate the source of a leak. • Measure mode is used to quantify the size of the leak.

  • Page 15: Operational Functions/Features

    = Sample mass flow rate Gas Concentration = Concentration of gas in the sample (ppm) 1.5.3. Operational Functions/Features Table 1-1. H25-IR PRO Functions and Features Feature Description A leak measurement can be logged in memory with a time/date stamp. Up to 50 leaks can be logged.

  • Page 16: Advanced Leak Quantification (Alqä) Technology

    The H25-IR PRO responds to within ±5% of reading (absolute) at reference conditions and maintains this across the specified operating temperature range (see Figure 1-2 on page 7). Users who need to adjust the H25-IR PRO to their recognized leak standard may do so within a ±...

  • Page 17: Figure 1-2. H25-Ir Pro's Alqä Technology

    H25-IR PRO Instruction Manual Introduction Figure 1-2. H25-IR PRO’s ALQ ä Technology P/N: 3015-5678 Rev 6...

  • Page 18: Figure 1-3. Adjusting The H25-Ir Pro To A Recognized Leak Standard

    Introduction H25-IR PRO Instruction Manual Figure 1-3. Adjusting the H25-IR Pro to a Recognized Leak Standard P/N: 3015-5678 Rev 6...

  • Page 19: Specifications

    Response Time Less than 1 second, typical (dependent on probe-hose length) Sensitivity 0.03 oz/yr (0.9 g/yr) for all HFC refrigerants. For other gases, consult Bacharach. Resolution 0.1 leak units ±1 PPM ±10% of reading (or ±1% if recalibrated using a known concentration of refrigerant gas)
  • Page 20 Introduction H25-IR PRO Instruction Manual Category Description Speaker Audible indication of leak level Dimensions 4.00 in x 10.75 in x 15.50 in (101.6 mm x 273.1 mm x 393.7 mm) Weight 18 lb (8.2 kg) Operating: 32° to 122° F (0° to 50° C) Temperature -4°...

  • Page 21: Chapter 2: Hardware Overview

    AC Power Cord (as ordered) § § Instruction Manual If damage was found, immediately file a claim with the carrier. If an item is missing, please contact Bacharach’s Service Department for assistance. 2.2. External Components 2.2.1. Front Panel Front panel components are shown in Figure 2-1.

  • Page 22: Back Panel

    Figure 2-2. Back Panel Components of the H25-IR PRO 2.3. Probes and Hoses IMPORTANT: The H25-IR PRO is factory configured to use the probe with which it is purchased. This factory configuration includes internal wiring connections. If you plan to use a different probe than the type that was shipped with your H25-IR PRO, you must move an internal cable to a different connector.

  • Page 23: Standard Probe With Led And Push Button

    NOTE: When ordered with the instrument, the probe type is configured at the factory. If a standard probe is to be used as a Smart Probe replacement, additional internal changes are required. Table 2-1. H25-IR PRO Standard Probe Components Component Function/Notes •...

  • Page 24: Smart Probe

    Hardware Overview H25-IR PRO Instruction Manual NOTE: The function of the button on the standard probe is defined by the user. It can be programmed to zero the instrument or to toggle the instrument between search mode and measure mode.

  • Page 25: Connecting The Flexible Probe Tube

    Press the MODE and SETUP buttons simultaneously to toggle this feature. Refer to Figure 2-6. Figure 2-6. H25-IR PRO Smart Probe Key Lock Feature 2.3.4. Connecting the Flexible Probe Tube Table 2-4. Connecting the Flexible Probe Tube...

  • Page 26: Power Cord

    NOTE: The H25-IR PRO is supplied with a 6 foot grounded AC power cord. Make sure that a compatible AC power receptacle (socket) is available nearby. The H25-IR PRO uses a universal AC power supply that accepts inputs of 100 to 240 VAC, 50/60 Hz. Power consumption is approximately 16 Watts (maximum).

  • Page 27: Internal Components

    For information on replacing the NDIR sensor yourself, refer to Chapter 6: Maintenance (page 88) for more information. Alternatively, you can send your H25-IR PRO to the factory or service center to have the NDIR sensor replaced.

  • Page 28: Chapter 3: Menu System Overview

    The H25-IR PRO is used to locate and quantify gas leaks. Interfaces provide external information, configuration, operation, evaluation results, and even diagnostic information, among other things. Interfaces (i.e., the “borders” between the outside world and the H25-IR PRO) are those key boundaries where the information is exchanged. The main interfaces of the H25-IR PRO are: •...

  • Page 29: Table 3-1. Key Components Of The Menu Structure

    Menu System Overview Though all of these “interfaces” may be used during the operation of the H25-IR PRO, the front panel LCD and buttons provide an easy-to-use interface consisting of a robust suite of configuration, customization, operation, evaluation, and diagnostic functions.

  • Page 30: Menu Navigation

    3.2.1. Overview Navigating the H25-IR PRO menus is intuitive. Furthermore, it is likely that operators will spend only a proportionally small amount of time configuring the unit versus a greater amount of time at the search and measure screens (locating leaks and quantifying them once they are found).

  • Page 31: Figure 3-3. Menu Architecture Summary

    H25-IR PRO Instruction Manual Menu System Overview After pressing SETUP, select a menu item by first using the Up and Down Arrow buttons to highlight the desired item, and then pressing ENT to select that item and display its data screen. After an item has been selected, use the Left, Right, Up, and Down Arrow buttons to highlight or change data within a screen.

  • Page 32: Front Panel Buttons

    Menu System Overview H25-IR PRO Instruction Manual 3.2.2. Front Panel Buttons Table 3-1. Front Panel Buttons Button Function • Selects a highlighted menu item • Saves a selection or manually entered data (e.g. date and time) • Zeros the gas reading (in the Measure and Search screens) •...

  • Page 33: Configuration-Dependent Menu Items

    3.2.4. Configuration-Dependent Menu Items Not all menu items may be available on your H25-IR PRO. The device displays certain menu options based on your particular hardware. In particular, the choice of probe type that is ordered (standard or Smart probe) determines whether or not the PROBE BUTTON option is shown in the ADVANCED SETUP menu.

  • Page 34: Special Key Combinations

    Figure 3-7. Version Screen at Power Up NOTE: If your H25-IR PRO has the Smart Probe option, its LCD will also show a version number after startup. Note that the version shown on the Smart Probe is the version of the Smart Probe firmware, while the version displayed on the main LCD (Figure 3-7) refers to the firmware version of the H25-IR PRO unit.

  • Page 35: Setup Summary Screen (Warm-Up)

    NOTE: Unless otherwise changed (via the MODE button), the Search Mode screen is the default display of the H25-IR PRO. That is, inactivity timeouts will automatically return the display to the SEARCH MODE screen, as will successive presses of the ESC button.

  • Page 36: Measure Mode Screen

    Menu System Overview H25-IR PRO Instruction Manual 3.6. Measure Mode Screen After locating a gas leak using the SEARCH MODE screen, switch to the MEASURE MODE screen to measure the extent of that leak. Use the MODE button to toggle between the MEASURE MODE screen and the SEARCH MODE screen.

  • Page 37: Advanced Setup Screen

    The Advanced Setup screen contains configuration options that allow you to take advantage of some of the more complex or infrequently-used features of the H25-IR PRO. To access the Advanced Setup screen from the Search Mode screen or Measure Mode screen, press the SETUP button once to reach the Basic Setup menu, then press the SETUP button a second time (as the Right Arrow button).

  • Page 38: Diagnostics Screen

    Menu System Overview H25-IR PRO Instruction Manual NOTE: The right arrows in the header of the Advanced Setup screen indicate the existence of an additional “tabbed” menu to the right (and the key to press in order to access it). Similarly, the left arrows show how to return to the Basic Setup screen.
  • Page 39 H25-IR PRO Instruction Manual Menu System Overview P/N: 3015-5678 Rev 6...

  • Page 40: Chapter 4: Wiring

    RS-232 communications port to export leak data to a computer. NOTE: The external connections and optional hardware devices discussed in this section are NOT required for the operation of the H25-IR PRO. You may skip any sections that do not apply to your particular configuration of the H25-IR PRO.

  • Page 41: 4-20Ma Current Loop Connection

    4.3. 4-20mA Current Loop Connection An external 4-20 mA monitoring device (e.g., chart recorder) can be connected to the H25-IR PRO using a shielded-twisted- pair cable. Locate the 4-20 mA connector on the rear of the unit, and then remove the resistor or shorting wire from its terminals.

  • Page 42: Communications Connection

    4.4. RS-232 Communications Connection Leak rate data can be output as ASCII text via the 9-pin RS-232 connector on the back panel of the H25-IR PRO. Using a standard RS-232 cable, connect the H25-IR PRO to a computer. To export ASCII formatted live data to a computer, you need: •...

  • Page 43: Figure 4-3. Front Panel Printed Circuit Board Containing Probe Connectors J2 And J7

    H25-IR PRO Instruction Manual Wiring Table 4-2. Procedure to Change Factory-Set Probe Configuration Step Description Remove power cord from back panel. Remove both the front and rear bezels by first disengaging the plastic tabs on the right and left sides of the bezel, and then pulling the bezel straight out.

  • Page 44: Chapter 5: Operation

    You wired optional external devices to the relays, current output, and/or RS-232 computer connector as desired. For basic applications, your H25-IR PRO is ready to use after you turn it on. If your application takes advantage of one or more of the optional features, you should review the settings to ensure that any customizations you desire are properly configured.

  • Page 45: Table 5-1. Function Reference

    Use a leak rate unit not shown in the Unit Display menu Leak Rate Conversion Chart ......48 Alarm Setpoint ..........49 Configure the H25-IR PRO to sound an alarm when the Changing the Volume Setting ......38 leak rate exceeds a certain value Unit Display .............

  • Page 46: Turning On The H25-Ir Pro

    NOTE: Unless otherwise changed (via the MODE button), the Search Mode screen is the default display of the H25-IR PRO. That is, inactivity timeouts will automatically return the display to the Search Mode screen, as will successive presses of the ESC button.

  • Page 47: Mode Button

    In Figure 5-2, notice the differences between the Search Mode screen and the Measure Mode screen. The H25-IR PRO in Figure 5-2 is configured for graphic display style. The H25-IR PRO in Figure 5-3 is configured for numeric display style. Refer to Display Style on page 51 for additional information.

  • Page 48: Volume Button

    When the detected gas level increases (an audible tone whose frequency increases as the detected level of gas increases). The audible tones emanate from either the speaker (at the back of the H25-IR PRO unit) or from headphones (or an amplified speaker) connected to the headphones jack on the back panel of the unit.

  • Page 49: Setup (And Right Arrow) Button

    H25-IR PRO Instruction Manual Operation GAS TYPE = R134A GAS TYPE = R134A 40.0 60.0 ALARM >= 20.0 G/YR ALARM >= 20.0 G/YR SEARCH {---------} SEARCH {---------} 2X RANGE (DEFAULT DISPLAY) 3X RANGE GAS TYPE = R134A GAS TYPE = R134A 80.0...

  • Page 50: Table 5-4. Accessing The Main Menu Screens Using The Setup Button

    Operation H25-IR PRO Instruction Manual NOTE: From any point in the menu structure, press the ESC button until you return to the SEARCH MODE screen or the MEASURE MODE screen. Table 5-4. Accessing the Main Menu Screens Using the Setup Button...

  • Page 51: Zero (Ent) Button

    H25-IR PRO in a refrigerant-free clean-air environment. NOTE: In Search Mode, the H25-IR PRO performs an auto zero process to remove the effects of background refrigerant in the air. Measure Mode does not automatically zero.

  • Page 52: Measure Mode Screen

    NOTE: With the exception of the LOG button (discussed in the next section), most of the front panel buttons on the H25-IR PRO behave similarly in the Measure Mode screen as they do in the Search Mode screen. For addition information on the ENT (ZERO), Information (i), VOL, SETUP, RANGE, and MODE buttons, refer to the corresponding subsections in the Search Mode Screen section starting on page 36.

  • Page 53: Log (Esc) Button

    20 grams/yr. The H25-IR PRO can be configured to measure all 50 points, quantify each leak rate, calculate the total of all 50 leak rates, and activate an alert device (light, buzzer, alarm) via one or more of the output relays based on a programmable Log Limit value.

  • Page 54: Table 5-5. Logging Data

    NOTE: With the exception of the LOG button (discussed in the next section), most of the front panel buttons on the H25-IR PRO behave similarly in the Measure Mode screen as they do in the SEARCH MODE screen. For additional information on the ENT (ZERO), Information (i), VOL, SETUP, RANGE, and MODE buttons, refer to the corresponding subsections in the Search Mode Screen section starting on page 36.

  • Page 55: Basic Setup Screen

    H25-IR PRO Instruction Manual Operation 5.5. Basic Setup Screen Table 5-6. Accessing the BASIC SETUP Screen Step Button Description Sample Screen(s) From the main Search screen BASIC SETUP >> or Measure screen, press the GAS TYPE: R134A SETUP button once to access the Basic Setup screen.

  • Page 56: Gas Type

    Operation H25-IR PRO Instruction Manual 5.5.1. Gas Type Gas Type sets the gas to be detected by the H25-IR PRO. Table 5-7. Setting the Gas Type from the List of Standard Gases Step Button Description Sample Screen(s) See Table 5-6 on...

  • Page 57: Table 5-8. Gas Type Menus And Selection

    H25-IR PRO Instruction Manual Operation NOTE: After changing the gas type, the screen heading on the main Measure screen or Search Screen is changed to reflect the name of the newly selected menu option. NOTE: Configuration values are retained (even after power is cycled) in non-volatile memory.

  • Page 58: Unit Display

    5.5.2. Unit Display The unit display function sets the engineering units used in leak flow rate (and other related) calculations. Available display units are listed in Table 5-9. Table 5-9. Display Units Available in the H25-IR PRO Units Description oz/yr...

  • Page 59: Alarm Setpoint

    ± SELECT ESC=QUIT Press the ENTER button to BASIC SETUP >> configure the H25-IR PRO for the GAS TYPE: R404A selected unit display. Pressing ENT returns the user to UNIT DISPLAY: G/YR the previous screen with the ALARM SETPOINT: 10.0...

  • Page 60: Table 5-12. Changing The Alarm Setpoint

    20.0 PPM TO MOVE ± SAVE ESC=QUIT Press the ENT button to configure BASIC SETUP >> the H25-IR PRO to use the defined GAS TYPE: R404A setpoint. Pressing the ENT button returns UNIT DISPLAY: G/YR the user to the previous screen ALARM SETPOINT: 20.0...

  • Page 61: Display Style

    H25-IR PRO Instruction Manual Operation NOTE: If you set the alarm setpoint to a non-zero value, the alarm “beep” sounds only when the gas sample exceeds the alarm setpoint. If you set the alarm setpoint to zero, the alarm will sound for any detected gas, and will increase in frequency based on the concentration of the gas.

  • Page 62: Table 5-13. Changing The Display Style

    NUMERIC ± SELECT ESC=QUIT Press the ENT button to configure GAS TYPE = R134A the H25-IR PRO to use the selected Display Style. Pressing ENT returns the user to 20.0 the previous screen with the selected Display Style in place.

  • Page 63: Advanced Setup Screen

    H25-IR PRO Instruction Manual Operation 5.6. Advanced Setup Screen Table 5-14. Accessing the ADVANCED SETUP Screen Step Button Description Sample Screen(s) From the main Search screen BASIC SETUP >> or Measure screen, press the GAS TYPE: R134A SETUP button once to access the Basic Setup screen.

  • Page 64: User Setups 1-4

    5.6.1. User Setups 1-4 User Setups provide a method of customizing up to four distinct configurations of your H25-IR PRO. You can define up to four configurations once and then switch between them much quicker than re-configuring those settings. User Setups are most useful if you change gas types, alarm setpoints, and/or feedback modes frequently.

  • Page 65: Figure 5-11. Weighing Your Application Needs: When To Use User Setup 0 (Default) Vs. User Setups 1-4

    H25-IR PRO Instruction Manual Operation User User Setup 0 Setups 1-4 Figure 5-11. Weighing Your Application Needs: When to Use User Setup 0 (Default) vs. User Setups 1-4 Table 5-15. Accessing the USER SETUP Screens 1-4 Step Button Description Sample Screen(s)

  • Page 66: Table 5-16. Changing A User Setup Name

    Operation H25-IR PRO Instruction Manual Table 5-16. Changing a User Setup Name Step Button Description Sample Screen(s) When the desired User Setup << USER SETUP 2 >> screen displayed (see Table 5-15 on page 55), use the NAME SETUP2 NAME...

  • Page 67: Figure 5-12. Sample Search Screen (With User Setup Active) Showing User Name "Freezer 1

    H25-IR PRO Instruction Manual Operation Step Button Description Sample Screen(s) Press the ENT button to save << USER SETUP 2 >> the defined User Name and NAME FREEZER 1 return to the previous User Setup screen. GAS TYPE R134A ALARM SETPOINT...

  • Page 68: Table 5-18. Changing A User Setup Alarm Setpoint

    Operation H25-IR PRO Instruction Manual Step Button Description Sample Screen(s) Press ENT to select that item SETUP 2 GAS TYPE for editing. Note that the unit of measure follows the Basic Setup selection. It is not possible to set different units of measure for each User Setup.
  • Page 69 H25-IR PRO Instruction Manual Operation Step Button Description Sample Screen(s) Press ENT to select that item SETUP 2 ALARM SP for editing. TO CHANGE 05.0 PPM TO MOVE ± SAVE ESC=QUIT Press the Up Arrow and Down SETUP 2 ALARM SP Arrow buttons to select the desired Gas Type from the list.

  • Page 70: Table 5-19. Changing A User Setup Feedback Mode

    Operation H25-IR PRO Instruction Manual Table 5-19. Changing a User Setup Feedback Mode Step Button Description Sample Screen(s) When the desired User Setup << USER SETUP 2 >> screen displayed (see Table 5-15 on page 55), use the NAME SETUP2 NAME...

  • Page 71: Relay Settings Screen

    5.6.2. Relay Settings Screen The relay settings screen defines how each of the H25-IR Pro’s four relays function—specifically, when (if) they energize. NOTE: Be sure to read the Relay Connections section in Chapter 4, and properly wire your relay connection(s) for the desired results.
  • Page 72 Operation H25-IR PRO Instruction Manual Step Button Description Sample Screen(s) Press the ENT button to select CLOSE RELAY 1 that relay for editing (the Close Relay #1-4 screen). NEVER >= SETPOINT ± SELECT ESC=QUIT Press the Up Arrow and Down...

  • Page 73: Measurement Log

    The user can scroll through the available data by using the Up Arrow and Down Arrow buttons. For additional information on logging data, refer to Figure 5-8 on page43 and Table 5-5 on page 44. NOTE: Logging is only possible when the H25-IR PRO is in Measure mode. NOTE: Use the SETUP button to clear individual log points.

  • Page 74: Table 5-22. Accessing The Measurement Log

    Operation H25-IR PRO Instruction Manual Table 5-22. Accessing the Measurement Log Step Button Description Sample Screen(s) See Table 5-14 Follow the steps in Table 5-14 << ADVANCED SETUP >> on page 53. on page 53 to highlight the USER SETUPS 1-4 Measurement Log option.

  • Page 75: Date/Time Set

    H25-IR PRO Instruction Manual Operation 5.6.4. Date/Time Set Table 5-23. Setting the Date and Time Step Button Description Sample Screen(s) See Table 5-14 Follow the steps in Table 5-14 << ADVANCED SETUP >> on page 53. on page 53 to highlight the USER SETUPS 1-4 Date/Time Set option.

  • Page 76: Log Limit

    Operation H25-IR PRO Instruction Manual Step Button Description Sample Screen(s) Press the ENT button to save SET DATE & TIME the new date and time and TO CHANGE return to the previous User Setup screen. 12/09/11 09:30 TO MOVE ± SAVE ESC=QUIT NOTE: The Date and Time are used in the Log Point data of the Measurement Log.
  • Page 77 H25-IR PRO Instruction Manual Operation Step Button Description Sample Screen(s) Press ENT to view the Edit Log EDIT LOG LIMIT Limit screen. TO CHANGE Note that the unit of measure 099.0 PPM is set in the Basic Setup menu, and is not independently configurable.

  • Page 78: Loop Factor

    Operation H25-IR PRO Instruction Manual 5.6.6. Loop Factor NOTE: The Loop Factor setting configures the 4-20mA current output for the sample range. By default, the standard 4-20mA output is mapped linearly to the input reading range (for example, with “ppm” set as the unit of measure, and a range of 0 ppm to 1000 ppm, each of the 1000 ppm steps corresponds to the default 0.016 mA).
  • Page 79 H25-IR PRO Instruction Manual Operation Step Button Description Sample Screen(s) Press ENT to view the Current CURRENT LOOP FACTOR Loop Factor screen. The default is set to 0.016. TO CHANGE 00.016 TO MOVE ± SAVE ESC=QUIT Press the Up Arrow and Down...

  • Page 80: Serial Data

    5.6.7. Serial Data The Serial Data option provides an automated, high-speed data logging tool. When enabled, the H25-IR PRO sends leak rate data (in ASCII text format) to the RS-232 port 10 times per second. The Serial Data option defines the format of the text data: •...

  • Page 81: Probe Button (Optional)

    NONE TEXT PACKET TEXT ONLY ± SELECT ESC=QUIT 5.6.8. Probe Button (Optional) The H25-IR PRO supports three types of probes: • Standard Probe with Flex Tubing • Standard Probe with LED and Push Button • Smart Probe.

  • Page 82: Figure 5-13. Advanced Setup Screen Without (Left) And With (Right) A Detected Smart Probe

    Figure 5-13. Advanced Setup Screen Without (Left) and With (Right) a Detected Smart Probe IMPORTANT: The H25-IR PRO is factory configured to use the probe with which it is purchased. This factory configuration includes internal wiring connections. If you plan to use a different probe than was shipped with your H25-IR PRO, you must move an internal cable to a different connector.

  • Page 83: Table 5-30. Changing The Probe Button Setting

    H25-IR PRO Instruction Manual Operation Table 5-30. Changing the Probe Button Setting Step Button Description Sample Screen(s) See Table 5-14 Follow the steps in Table 5-14 << ADVANCED SETUP >> on page 53. on page 53 to access the ­...

  • Page 84: Diagnostics Screen

    Operation H25-IR PRO Instruction Manual 5.7. Diagnostics Screen Table 5-31. Accessing the Diagnostics Screen (Method #1) Step Button Description Sample Screen(s) Access the main Search or 0810: PRESSURE OUT OF RANGE Measure screen by pressing the ESC button. Check the header for a fault ALARM notification.

  • Page 85: Table 5-32. Accessing The Diagnostics Screen (Method #2)

    H25-IR PRO Instruction Manual Operation Step Button Description Sample Screen(s) Press the Up Arrow and Down << FAULT 0010 >> Arrow buttons scroll through the fault text if it is too ERROR 0010: 4-20 MA long to fit on one screen.
  • Page 86 Operation H25-IR PRO Instruction Manual Step Button Description Sample Screen(s) Press the Setup (Right Arrow) << ADVANCED SETUP >> button again to access the USER SETUPS 1-4 Advanced Setup screen. RELAY SETTINGS MEASUREMENT LOG DATE/TIME SET ¯ LOG LIMIT SELECT ±...

  • Page 87: Current Faults Screen

    H25-IR PRO Instruction Manual Operation NOTE: A fault code of 0000 indicates that there are no current faults. 5.7.1. Current Faults Screen Table 5-33. Accessing the Current Faults Screen Step Button Description Sample Screen See Table 5-32 Follow the steps in Table 5-32 <<...

  • Page 88: Table 5-34. Fault Codes

    Operation H25-IR PRO Instruction Manual Table 5-34. Fault Codes Fault Possible Solution(s) Fault Message Cause(s) Code or Next Step(s) 0002 Box temp UNIT TEMPERATURE IS HIGH: Temp >55 • Move unit away from sources of error MOVE UNIT AWAY FROM heat.

  • Page 89: Sensor Data Screen

    H25-IR PRO Instruction Manual Operation 5.7.2. Sensor Data Screen The sensor data screen is used in troubleshooting the instrument. Table 5-35. Accessing the Sensor Data Screen Step Button Description Sample Screen(s) See Table 5-32 Follow the steps in Table 5-32 <<...

  • Page 90: Table 5-36. Sensor Data Parameters And Sample Values

    Operation H25-IR PRO Instruction Manual Step Button Description Sample Screen(s) Press the ESC button to return << DIAGNOSTICS to the Diagnostics screen. CURRENT FAULTS 0810 SENSOR DATA SELECT ± EDIT Table 5-36. Sensor Data Parameters and Sample Values NEW H25-IR PRO On...

  • Page 91: Adjustment To A Known External Leak Source

    Operation 5.8. Adjustment to a Known External Leak Source NOTE: Before adjusting the H25-IR PRO to a known external leak source, refer to Using a Reference Leak Source on page 6. Table 5-37. Adjusting the H25-IR PRO to a Known External Leak Source...
  • Page 92 Operation H25-IR PRO Instruction Manual Step Button Description Sample Screen(s) Press ENT to select the desired R404A REFERENCE reference gas type. This displays the reference screen. At this point, hold the probe to the G/YR reference leak source. 1.000X The timeout for this screen is 5 minutes.

  • Page 93: Custom Gas Type Configuration

    For a custom gas type, select CUSTOM from the Basic Gas List (refer to Gas Type Menus and Selection on page 47), and configure the gas using the same procedure used to adjust the H25-IR PRO to a known external leak source that contains the custom gas.

  • Page 94: Factory Gas Type Configuration

    • • IMPORTANT: Configuring the H25-IR PRO for a sample factory gas type requires (a) an appropriate NDIR sensor installed in the instrument, and (b) gas type configuration in the Factory menu. Be sure you ordered an H25-IR PRO with an appropriate NDIR sensor for the corresponding gas you wish to detect.
  • Page 95 H25-IR PRO Instruction Manual Operation Step Button Description Sample Screen(s) The Setup Summary screen is SETUP SUMMARY displayed automatically after the GAS TYPE: R134A Firmware Version screen. This screen displays key setup UNIT DISPLAY: G/YR information and a 60-second ALARM SETPOINT: 10.0...
  • Page 96 Operation H25-IR PRO Instruction Manual Step Button Description Sample Screen(s) Press the SETUP (Right Arrow) << DIAGNOSTICS >> button again to access the CURRENT FAULTS 0800 Diagnostics screen. (Notice the right arrows in the SENSOR DATA header, indicating an additional menu.)
  • Page 97 R113 ± SELECT ESC=QUIT Press the ENT button to configure << FACTORY SETUP the H25-IR PRO for the selected ­ DETECTOR ADJ gas. Pressing the ESC button returns MASS FLOW the user to the previous screen...

  • Page 98: Chapter 6: Maintenance

    H25-IR PRO Instruction Manual Maintenance CHAPTER 6: MAINTENANCE IN THIS SECTION • Fuse Replacement ............ 88 • Probe Tip Filter Replacement ........89 • Probe “O” Ring Replacement ........90 • External Filter Replacement ........90 • IR Sensor Replacement ..........92 •...

  • Page 99: Probe Tip Filter Replacement

    Table 6-3. Items Required for Probe Tip Filter Replacement Item Description Probe Tip Filter (diameter: 0.287 in. [7.2 mm]) (Available in bags of 50 from Bacharach. Refer to Probe Tip Filter Replacement on page 89) Pin or tweezers Table 6-4. Probe Tip Filter Replacement Procedure...

  • Page 100: Probe "O" Ring Replacement

    Maintenance H25-IR PRO Instruction Manual Figure 6-2. Probe Filter and “O” Ring Locations 6.3. Probe “O” Ring Replacement Table 6-5. Items Required for “O” Ring Replacement Item Description Probe Tube “O” Rings (2) Table 6-6. Probe “O” Ring Replacement Procedure...

  • Page 101: Figure 6-3. Back Panel Of The H25-Ir Pro Showing Proper Orientation Of The External Filter

    H25-IR PRO Instruction Manual Maintenance Figure 6-3. Back Panel of the H25-IR Pro Showing Proper Orientation of the External Filter Step Description Repeat for the lower tubing. Dispose of the used filter. Install the filter in the opposite manner to removal. Start with the filter at an angle, with the lower part pressed into the clip.

  • Page 102: Ndir Sensor Replacement

    H25-IR PRO Instruction Manual 6.5. NDIR Sensor Replacement These instructions describe how to replace the NDIR sensor in the H25-IR PRO Infrared Gas Leak Detector. It is assumed that the user is familiar with the operation and menu system of the H25-IR PRO.

  • Page 103: Figure 6-5. Ndir Sensor Showing Three Cable Ties Removed

    H25-IR PRO Instruction Manual Maintenance Step Description instrument. Figure 6-5. NDIR Sensor Showing Three Cable Ties Removed Carefully remove tubing and electrical connectors from old NDIR sensor. NOTE: The connection at the back of the NDIR sensor includes a reusable tubing clamp. The clamp is opened by gently prying the ratcheting jaws away from each other (side to side).
  • Page 104 450 mW is acceptable. If higher power is required, it may indicate a contaminated bench. In this case, contact Bacharach Technical Support for guidance. Press ESC two times to return to the User Display screen. Confirm that no faults are indicated (top of display).

  • Page 105: Ndir Sensor Adjustment

    NDIR Sensor Replacement procedure found in the previous section. NOTE: “DigiPot” is a shortened version of digital potentiometer. The H25-IR PRO uses DigiPots to simplify certain configuration processes by integrating the manual tweaking process of an internal potentiometer into the user interface.

  • Page 106: Firmware Upgrade Procedure

    Maintenance H25-IR PRO Instruction Manual 6.8. Firmware Upgrade Procedure As updates to the instrument’s firmware become available, the instrument can be upgraded by using the procedure below. NOTE: The firmware upgrade procedure is sometimes referred to as flashing memory. Table 6-13. Items Required for Upgrading Firmware...
  • Page 107 H25-IR PRO Instruction Manual Maintenance Step Description From the C:\RFU folder, run the flash memory program by double clicking the file rfu.exe. Select Setup > Communications. Under “Serial Options”, select Use Serial Connection. Then set the Baud Rate to 115200, and select Enable Processor Detection.
  • Page 108 Maintenance H25-IR PRO Instruction Manual Step Description A progress-dialog box will appear during the flashing process, and will disappear when the flashing process is complete. When flashing is complete: • Exit the flash program • Turn OFF the instrument •...
  • Page 109 H25-IR PRO Instruction Manual Maintenance P/N: 3015-5678 Rev 6...

  • Page 110: Chapter 7: Troubleshooting

    • Be sure Smart Probe is fully plugged in to the H25-IR PRO Smart Probe keys • Be sure the H25-IR PRO is configured for Smart Probe use (i.e., you should NOT see the “Probe Button" function in the Setup menu •...

  • Page 111: System Faults

    H25-IR PRO Instruction Manual Troubleshooting 7.3. System Faults Table 7-2. Fault Codes Fault Possible Solution(s) Fault Message Cause(s) Code or Next Step(s) 0002 Box temp UNIT TEMPERATURE IS HIGH: Temp >55 • Move unit away from sources of error MOVE UNIT AWAY FROM heat.

  • Page 112: Appendix A: Glossary Of Terms

    Refer to Loop Factor on page 68 for additional information. Measure mode is one of two main operating modes of the H25-IR PRO. It is used to quantify a measure mode leak rate and is typically use after using search mode to locate a leak.
  • Page 113 Menu options permit the clearing of individual data points or the entire measurement log. Search mode is one of two main operating modes of the H25-IR PRO. It is used to locate a leak search mode and is typically use before using measure mode.

  • Page 114: Appendix B: Acronyms And Abbreviations

    H25-IR PRO Instruction Manual Acronyms and Abbreviations APPENDIX B: ACRONYMS AND ABBREVIATIONS Table B-1. Acronyms and Abbreviations Acronym Meaning ‘ feet “ Inches ° degrees ¿ enter Amperes, Amps analog/digital Alternating current Advanced Leak Quantification ALQä ASCII American Standard Code for Information Interchange...
  • Page 115 H25-IR PRO Instruction Manual Acronyms and Abbreviations Acronym Meaning pound liquid crystal display light emitting diode lower explosive limit line feed locked meter milliamp, milliampere milliliter millimeter, month normally closed NDIR Non-dispersive Infrared NIST National Institute of Standards and Technology...

  • Page 116: Appendix C: Supported Gas Types

    Factory Gas Types ........... 108 C.1. Basic Gas Types NOTE: Basic gas types are those listed in the H25-IR PRO’s GAS TYPE menu item, when equipped with the halogen NDIR sensor, unless overridden by selecting a factory gas option. Table C-1. Basic (Primary) Gas Types...
  • Page 117 H25-IR PRO Instruction Manual Supported Gas Types Gas Abbr Formula Gas Name/Description R-22 ..(60%) R409A See information on individual gases. R-124 ..(25%) R-142b ..(15%) R-32 ..(50%) Difluoromethane R410A R-125 ..(50%) Pentafluoroethane R-125 ..(65.1%) R422d See information on individual gases.

  • Page 118: Factory Gas Types

    Supported Gas Types H25-IR PRO Instruction Manual Gas Abbr Formula Gas Name/Description R-134a ..(44%) R513A See information on individual gases. R-1234yf ... (56%) HFO1336mzz(Z) ....(74.7%) R514A See information on individual gases. R-1130(E) ....(25.3%) H1234YF 2,3,3,3-Tetrafluoropropene Difluoromethane H1301...

  • Page 119: Table C-2. Factory (Secondary) Gas Types

    H25-IR PRO Instruction Manual Supported Gas Types Table C-2. Factory (Secondary) Gas Types Gas Abbr Formula Gas Name/Description R600a** Isobutane or methylpropane R290** Propane CO2_A** Carbon dioxide SF6** Sulfur hexafluoride ** Requires a different NDIR sensor inside the instrument. Ñ Ñ Ñ...
  • Page 120 H25-IR PRO Instruction Manual Declaration of Conformity P/N: 3015-5678 Rev 6...

  • Page 121: Index

    ......... 4 connection ............... 12 cord ............16, 33, 95, 96 removing prior to service ..........2 Bacharach Service Centers ........2, 101 source ................3 back panel ..........33, 34, 39, 89, 91 supply ..............16 background gas rejection ..........3 accuracy ............
  • Page 122 Index H25-IR PRO Instruction Manual basic gas types ..........9, 84, 108 current loop Basic Setup menu ....20, 21, 27, 28, 29, 37, 40, 41, output ..............3, 5 46, 48, 50, 54, 55, 68, 86, 88, 103, 104 scaling ..............28 Baud Rate ..............
  • Page 123 H25-IR PRO Instruction Manual Index conditions ..............5 calculation of ..........3, 36, 50, 52 message ..............5 gas exhaust ..............12 ESC button ..11, 20, 21, 22, 23, 24, 26, 37, 41, 44, 45, 47, gas leaks ............1, 9, 19, 44 50, 51, 53, 62, 63, 75, 81, 83, 84, 88, 96, 105 GAS PPM LEVEL ............
  • Page 124 Index H25-IR PRO Instruction Manual MASS FLOW ..............81 error ................ 79 J2 ................33, 34 rate ................5 J5 ................95 Measure flow fault ............79 J7 ................33, 34 measure mode ... 4, 5, 9, 13, 14, 19, 20, 21, 23, 27, 28, 29,...
  • Page 125 H25-IR PRO Instruction Manual Index operation .. 1, 2, 4, 6, 13, 19, 20, 21, 22, 26, 31, 35, 38, 84, programmable button ..........13, 72 85, 86, 89, 93, 103 protective caps ............94 optimal ..............103 protective ground ............2 optional hardware devices ...........
  • Page 126 Index H25-IR PRO Instruction Manual reference conditions ..........6, 7, 8 SENSOR TEMP ............. 81 reference leak source........6, 83, 103 serial cable ............33, 97, 99 reference standard ............6 serial communications software ........33 reference temperature ..........6 Serial Data ..............
  • Page 127 H25-IR PRO Instruction Manual Index removed ..............18 user-defined setups ....5, 21, 28, 48, 55, 56, 103 totalization applications ......1, 44, 64, 67, 104 using a different probe ........12, 13, 73 totalizing gas leaks ........... 1, 44 using a reference leak source .........
  • Page 128 Index H25-IR PRO Instruction Manual Headquarters: 621 Hunt Valley Circle, New Kensington, PA 15068 Website: www.mybacharach.com • E-mail: help@mybacharach.com Printed in U.S.A. ® Registered Trademark of Bacharach Inc. P/N: 3015-5678 Rev 6...

Table of Contents
