SEGA ENTERPRISES DIRT DEVILS Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Installation space:
Height:
Weight:
Power maximum current:
MONITOR:
INTRODUCTION OF THE OWNERS MANUAL
SEGA ENTERPRISES, LTD., has for more than 30 years been supplying various innovative and
popular amusement products to the world market. This Owners Manual is intended to provide
detailed descriptions together with all the necessary installation, game settings and parts ordering
information related to DIRT DEVILS, a new SEGA product.
This manual is intended for those who have knowledge of electricity and technical expertise, espe-
cially in ICs, CRTs, microprocessors, and circuit boards. Read this manual carefully to acquire
sufficient knowledge before working on the machine. Should there be a malfunction, non-technical
personnel should under no circumstances touch the interior system. Should the need arise, contact
our main office, or the closest branch office listed below.
SEGA ENTERPRISES, INC. (USA)
Customer Service
45133 Industrial Drive
Fremont, CA 94538
Phone 650-802-1750
Fax
650-802-1754
7:30 am - 4:00 pm, Pacific Standard Time
Monday thru Friday
SPECIFICATIONS
64 in.(L) x 39 in.(W)
77 in.
Approx. 550 lbs.
8 Amp AC 120V 60 Hz
29" NANAO MONITOR
27" WELLS GARNER MONITOR
