Table of Content
■ Introduction
Overview... ... ... ... ... ...... ... ... ... ... ... ... ... ... ... ... ....1
Features... ... ... ... ... ... ... .... ... ... ... ... ... ... ... ... ..... .2
Console Connection... ... ... ... ... ... .... ... ... ... ... ... ...3
Computers Connection... ... ... ... ... ... .... ... ... .... .... 4
Initial Power-up... ... ... ... ... ... .... ... ... ... ... ... ..... ... .6
Front Panel operation... ... ... ... ...... ... ... ... ...... ..... .7
Hot-key commands... ...... ... ... ... ...... ... ... ... ... ..... .7
■ Appendices
Specifications... ... ... ... ... ... ..... ... ... ... ... ... ... ... ... .9
Please read this manual thoroughly
and follow the Installation procedures to
prevent any damage to the KVM Switch or any
connecting device.
This device is tested and complies with Part 15 of
FCC/class B, CE and VCCI rules.
----------------- Introduction
Overview
The KVM Switch SW0202C is a computer switch that
allows access to two IBM compatible computers from
one keyboard, mouse and monitor. Switching between
computers is as easy as pressing the push button or
entering hot-key commands from your keyboard. There
is no interface card and software to install.
powerful KVM Switch is independent of the computer
operating system, allowing the attached computers to run
different applications. The space-saving design enables
you to connect all the cables to the back of the
SW0202C taking the least amount of space on your desk.
It is a valuable tool for your computer management.
Automatic Mouse Conversion
This technology enables you to connect computers with
either PS/2 or serial mouse ports to the KVM Switch, and
control both computers from one PS/2 mouse.
KVM Switch automatically identifies the mouse and
switches to proper mouse protocol.
-
1
-
The
The
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Equip SW0202C
Summary of Contents for Equip SW0202C
-
Page 1: Table Of Contents
Front Panel operation… … … … ...… … … … ...… ..… .7 you to connect all the cables to the back of the SW0202C taking the least amount of space on your desk. Hot-key commands… ...… … … … ...… … … … … ..… .7 It is a valuable tool for your computer management. -
Page 2: Features
-----------------Installation Features nSupports both PS/2 and serial mouse Console Connection nCascade configuration expands system capability nAuto scan automatically selects computers Turn your computers off. Connect a PS/2 keyboard and sequentially a PS/2 mouse to the mini-DIN-6 ports of the nSupports Microsoft IntelliMouse (Pro), IntelliTrackball (CONSOLE) marked with respectively. -
Page 3: Computers Connection
3. If your PC uses an AT style keyboard, you will need an AT-to-PS/2 keyboard adapter, DIN-5 male to mini-DIN-6 female, at PC side in order to plug the cable to the SW0202C. Figure 2: COMPUTER Connection If your computer uses serial mouse, a mouse adapter should be connected to the computer’... -
Page 4: Initial Power-Up
----------------- Operations Initial Power-up Make sure all computers and KVM Switch are Front Panel operation powered down during installation. After connection, you just power up the computers; the KVM Switch will get enough power to operate from the computers. You may switch to a different computer by pressing the This procedure ensures the KVM Switch receive front panel push-button directly or by issuing hot-key computer settings correctly when computer boots. -
Page 5: Specifications
To abort the Auto Scan mode, press the left Ctrl Specifications key twice. When Auto Scan detects any keyboard or mouse activity, it suspends the scanning till SW0202C activity stops; it then resumes with the next Computer port number computer in sequence. The length of the Auto... - Page 6 SW0202C. mouse, wait for few Not functional In master/slave SW0202C can be a slave seconds then plug it back. in cascade configuration, the of SW0202C, SW0403C, Keyboard error Loose keyboard Make sure keyboard configuration.
- Page 7 If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off 2-port SW0202C and on, the user is encouraged to try to correct the interference by one or 4-port...
- Page 8 PP5-N1200-007 Printed in Taiwan...
