B-K lighting PRECISION2 HP2 Series Installation Instructions Manual page 5

Lamp and Accessory Holder Installation
Failure to clean groove of debris will cause
fixture to fail and void product warranty.
Optional Accessory Holder Installation for AR111/ PAR36 / CDM-R111
Insert any accessory lens with the smooth side
towards the lamp. If using a honeycomb baffle,
position it farthest from the lamp.
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
B-K LIGHTING
PROJECT:
TYPE:
Do not use a power tool to install screws. Do
not exceed 40 in-lbs.
2 2
HP & CO SERIES
AR111 / PAR36 / CDM-R111
SUBMITTAL DATE REFERENCE NUMBER
7-13-16 INS-2155-00
