Summary of Contents for ROBINHOOD RHFL6W
- Page 1 Installation and Operating Instructions Issue: 1 Description: ROBINHOOD FRONT LOADING WAHSING MACHINE 6KG WHITE Model Number: RHFL6W Model pictured: RHFL6W Actual product may vary from the picture as above...
-
Page 2: Table Of Contents
It is important that you retain these instructions and your proof of purchase along with any other important documents about this product for future reference. Due to continual product development, Robinhood reserves the right to alter specifications or appearances without notice. Important Safety Instructions……………………………………………………………………………………………………………………..1-2 Appliance Details……………………………………………………………………………………………………………………………………………3... -
Page 3: Important Safety Instructions
Important Safety Instructions When using electrical appliances, in order to reduce the risk of fire, electric shock, and/or injury to persons, basic safety precautions should always be followed, including • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. - Page 4 Important Safety Instructions • Make sure that all pockets are emptied. Sharp and rigid items such as coin, brooch, nail, screw or stone etc. may cause serious damages to this machine. • Please check whether the water inside the drum has been drained before opening its door. Please do not open the door if there is any water visible.
-
Page 5: Appliance Details
Appliance details Model RHFL6W Maximum Drying Capacity 6 kg Rated Voltage 220 – 240 V Rated Frequency 50 Hz Rated Wattage 1950 W Net Weight 61 kg Dimension (WxDxH) 595x 495x 850mm (Depth without door frame) 595x 540x 850mm (Depth with door frame) -
Page 6: Installation
Installation Instructions Installation Area Warning! Stability is important to prevent the product from wandering! • Make sure that the product should not stand on the power cord. Before installing the machine, the location characterized as follows shall be selected: 1. - Page 7 Installation Instructions Levelling the washing machine Warning! The lock nuts on all four feet must be screwed tightly against the housing. 1. Check if the legs are closely attached to the cabinet. If not, please turn them to their original positions tighten the nuts.
- Page 8 Installation Instructions Connect the other end of inlet pipe to the inlet valve at the backside of product and fasten the pipe tightly clockwise. Drain Hose Warning! Do not kink or protract the drain hose. Position drain hose properly, otherwise damage might result of water leakage. There are two ways to place the end of drain hose: 2.
-
Page 9: Operating Instructions
Operation Instructions Quick Start Caution! Before washing, please make sure it’s installed properly. • Before washing at first time, the washing machine shall be operated in one round of the whole procedures without clothes in as follow. 1. Before Washing Open tap Plug in Close door... - Page 10 Operation Instructions Before Each Washing • The working condition of the washer should be (0-40) °C. If used under 0°C, the inlet valve and draining system may be damaged. If the machine is placed under condition of 0°C or less, then it should be transferred to normal ambient temperature to ensure the water supply hose and drain hose are not frozen before use.
- Page 11 Operation Instructions Detergent Dispenser Pre wash detergent Main wash detergent Softener Caution! Detergent only needs to be added in "case I “after selecting pre-washing for machines with this function. Caution! As for the agglomerated or ropy detergent or additive, before they are poured into the detergent box, it is suggested to use some water for dilution to prevent the inlet of detergent box from being blocked and overflowing while filling water.
- Page 12 Operation Instructions Control Panel Press the button to start or pause the Product is switched off. washing cycle. Available according to the laundry type. This allows you to select an additional function and will light when selected.
- Page 13 Operation Instructions Option Prewash: The Prewash function can get an extra wash before main wash. It is suitable for washing the dust rises to surface of the clothes. You need to put detergent into the Case (I) when select it. Extra Rinse: The laundry will undergo extra rinse once after you select it.
- Page 14 Operation Instructions Child Lock Choose the Start Press [ Extra Rinse ] and [ No Spin ] / program [ Spin Speed ] 3 seconds till buzzer beep Caution • Press the two button 3sec. also to be released the function. •...
- Page 15 Operation Instructions Program Programs are available according to the laundry type. Program Cotton Hard-wearing textiles, heat-resistant textiles made of cotton or linen. Synthetic Wash synthetic articles, for example: shirts, coats, blending. While washing the knitting textiles, detergent quantity shall be reduced due to its loose string construction and easily forming bubbles Daily Wash It is suitable for washing few and not very dirty clothes quickly.
- Page 16 Operation Instructions Washing Program Table Program Load (kg) Temp. (°C) Default Time (H:MM) Cotton Eco 40 °C 1:39 Cotton Eco 60 °C 4:56 Cotton Cold 1:35 Cotton 20 °C 1:19 Cotton 30 °C 1:20 Cotton 40 °C 1:40 Cotton 60 °C 1:45 Cotton 90 °C 2:40...
-
Page 17: Cleaning And Maintenance
Cleaning and Maintenance Cleaning And Care Warning! Before your maintenance starts, please unplug the machine and close the tap. Cleaning The Cabinet Proper maintenance on the washing machine can extend its working life. The surface can be cleaned with diluted non-abrasive neutral detergents when necessary. - Page 18 Cleaning and Maintenance Cleaning The Inlet Filter Note! Inlet filter must be cleaned if there is less water. Washing the filter in the tap: 1. Close the tap. 2. Remove the water supply hose from the tap. 3. Clean the filter. 4.
- Page 19 Cleaning and Maintenance Cleaning The Drain Pump Filter Warning! Be careful of the hot water! • Allow detergent solution to cool down. • Unplug the machine to avoid electrical shock before washing. • Drain pump filter can filter the yarns and small foreign matters from the washing. •...
-
Page 20: Troubleshooting
Troubleshooting Try to find a solution to the problem, if not, contact the service center. Description Reason Solution Washing machine cannot start up Door is not closed properly Restart after the door is closed Check if the clothes is stuck Door can’t be opened Washer's safety protection design Disconnect the power, restart the... - Page 21 Troubleshooting Description Reason Solution Door is not closed properly Restart after the door is closed Check if the clothes is stuck Water injecting problem while Check if the water pressure is too low washing Straighten the water pipe Check if the inlet valve filter is blocked Overtime water draining Check if the drain hose is blocked Water overflow...
-
Page 22: Warranty Certificate (New Zealand)
The following conditions apply in respect of the warranty given in this certificate: Monaco Corporation Limited (“Monaco”) warrants the following Robinhood products against manufacturing defects and faulty materials, under normal use and subject to the exclusions in this certificate, for a period of: ... -
Page 23: Warranty Certificate (Australia)
The product was used outdoors. All Robinhood Rangehoods are suitable for indoor use only and not suitable over BBQs or charcoal cookers designed for outdoor use. In addition, this warranty does not extend to damage or defects which in our opinion, directly or indirectly arise from or are due to: exposing the product to acidic or corrosive materials or chemicals such as dyes, solvents, denture cleaner or acetone;...
