- Page 1 Global Top Smart MCU Innovation Company Global Top Smart MCU Innovation Company Global Top Smart MCU Innovation Company Hand Writer User Manual Version 1.0.0 Jun. 28, 2019 For additional information or inquiry, please contact ABOV Semiconductor or visit its website at www.abov.co.kr.
- Page 2 Revision History Date Date Version Version Description Description Jun. 28, 2019 Jun. 28, 2019 1.0.0 1.0.0 Document created. Document created. Hand Writer Page 2 / 12 Version 1.0.0...
-
Page 3: Table Of Contents
3.5. Software error messages ......12 Version 1.0.0 Page 3 / 12 Hand Writer... -
Page 4: Chapter 1. Introduction
Introduction Chapter 1. Introduction Hand Writer is a universal programmer series, specifically designed as a portable programmer. Hand Writer: • Is powered by a 9V battery. Additionally, it can be connected to a USB power adapter and power bank. • Is a standalone product that performs firmware updates and saves hex files for continuous programming. -
Page 5: Chapter 2. Hardware
This is the USB port used to connect Hand Writer to a PC when updating firmware. In addition to firmware updates, the USB port can be used to connect to a power bank in case of power shortage. -
Page 6: 10-Pin Connector Pin Configuration
In case of an error even with an alkaline battery, connect an alternative USB battery pack to the USB connector of Hand Writer to supply sufficient power. Do not supply power directly to the target board when using Hand Writer. Programming with a powered target board can cause severe damage to the Hand Writer hardware. -
Page 7: Chapter 3. Software
3.2 Software installation To install the software, perform the following: 1. Visit the ABOV website at www.abov.co.kr > Development Tools > Rom Writer > Hand Writer. 2. Under Downloads, download the Hand Writer Guide and Hand Writer Software. Version 1.0.0... - Page 8 – Do not change the installation location; an error may occur. 4. Connect Hand Writer to your PC, and the driver will be automatically installed in Windows (The driver will be installed only at the first connection). Wait until installation is complete.
-
Page 9: Software Ui Descriptions
5. You will find the driver added under Human Interface Devices in Device Manager. 3.3 Software UI descriptions The PC program for Hand Writer is provided in the form of a dialog box, which presents all information in a single screen. You can check the progress, hex dump, and device information. - Page 10 Press the Device button for the Device List dialog box, and select the desired device from the list. If the desired device is not available, contact the developer to add it to the list. Hand Writer Page 10 / 12...
- Page 11 When the update is complete, the total time consumed is displayed under Time. This field displays all data, including address values of the loaded hex file. This field displays all status information. Version 1.0.0 Page 11 / 12 Hand Writer...
-
Page 12: Device Selection
ABOV device. 4. Click Update Tool to save the hex file and options in Hand Writer. This updates the tool with the active device firmware and hex file. Update Tool updates the tool only, and is not to program the IC.
