Blodgett 966 Specifications

MODEL 951/966
Deck Oven
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Flexible gas hose with quick disconnect and
restraining device:
36" (914 mm)
48" (1219mm)
Ultra Rokite shelves, 1-1/2" (38.1mm) thick
(pizza type shelf)
Steam jets
OPTIONS AND ACCESSORIES
(AT NO ADDITIONAL CHARGE)
FDTH 300° to 650° temperature thermostat
Centigrade dial, 100°C to 300°C
44 Lakeside Avenue, Burlington, VT 05401 • Phone: (802) 658-6600 • Fax: (802) 864-0183
Project
Item No.
Quantity
All ovens consist of basic sections and are a complete and separate unit
capable of operating alone or in combination.
All data is shown per oven section, unless otherwise indicated.
Refer to operator manual specification chart for listed model name.
EXTERIOR CONSTRUCTION
Full angle iron frame
Stainless steel front, top, sides and back
Counterbalanced doors with concealed hinges
Heavy chrome plated tubular steel door handle
7" (178mm) stainless steel legs are adjustable for leveling
Burner door opens easily for ignition, cleaning or adjustment, without
removal of any fastenings
Vitreous fiber insulation at top, back, sides, bottom and doors
INTERIOR CONSTRUCTION
(1 – 951) 42" x 32" x 12" (1067mm x 813mm x 305mm)
(1 – 966) 42" x 32" x 16-1/4" (1067mm x 813mm x 413mm)
oven compartment interior
Aluminized steel baking compartment liner
Aluminized steel combustion chamber
Steel deck supported by an angle iron frame
12 gauge (3.02mm) press-formed, reinforced and flanged aluminized steel
deck
OPERATION
Free-floating, easily removable duplex-tube burner
Removable fixed orifices on main and pilot burner
Main gas valve, temperature control valve and safety pilot valve fully within
section body and are accessible through a covered and ventilated compart-
ment in front.
Air mixers with adjustable air shutters and locking device
Snap throttle thermostat with temperature control range of
200°F (93°C) to 500°F (288°C)
STANDARD FEATURES
Fahrenheit dial 200°F to 500°F
Vent kit
Large crown angle trim
Double connector for stacking
Steel oven deck
Two year parts and one year labor warranty
Five year limited oven door warranty*
* For all international markets, contact your local distributor.
BLODGETT OVEN COMPANY
www.blodgett.com
