P750TM1
1. What you get:
A. RTX20XX MXM3.1 GPU Module (X-bracket &
proper vBIOS Installed)
B. GPU Power Cable | P/N: 6-43-P7750-210-1
Length: 110mm / 4.3in
C. Screws (2pcs) – Silver | P/N: 6-35-B2125-4R2
D. Thermal Pad – 28.12x4.5x3.6mm
Blue Protective Film
E. Thermal Pad – 47x34.5x3.6mm
Over Capacitors – Yellow Protective film
F. Thermal Paste
G. Updated Standard BIOS/EC (via Email) if required
P750TM1
RTX 2080/2070/2060 HEATSINK UPGRADE KIT
2. What you get:
H. P750TM1 Heatsink | P/N: 6-31-P75F3-202
Thermal Pads (attached)
I. Screws (4 pcs) – Black | P/N: 6-35-82125-6RA
3. Tools and Parts you need before you start: (not included in GPU upgrade kit)
Precision Slotted and Phillips
Screwdriver
WIHA 261/PH1x60
4. Extras: (can be bought separately)
RTX 2080/2070/2060 GPU UPGRADE KIT
ESD Strap
ESD Mat
Thermal Paste
RTX20XX CPU+GPU
Heatsink [P750TM1]
P/N:6-31-P75F3-202
5/28/19
5/28/19
Advertisement
Related Manuals for Clevo P750TM1
Summary of Contents for Clevo P750TM1
- Page 1 RTX 2080/2070/2060 HEATSINK UPGRADE KIT 5/28/19 2. What you get: H. P750TM1 Heatsink | P/N: 6-31-P75F3-202 Thermal Pads (attached) I. Screws (4 pcs) – Black | P/N: 6-35-82125-6RA 3. Tools and Parts you need before you start: (not included in GPU upgrade kit)
- Page 2 5. Installation Steps: Step 1. Unlock the Battery Step 3. Remove the existing Step 4. Disconnect the Step 2. Remove Bottom case and move the latch to CPU+GPU heatsink (9 screws) power cable from the GPU of your laptop (5 screws) remove the battery and remove existing GPU (2 screws)
