B-K lighting BKSSL MINI-MICRO iLUME Installation Instructions page 3

Stability flange
Pea gravel or sand
Faceplate
THIS PRODUCT IS AVAILABLE WITH A FACTORY INSTALLED LED.
COMPONENT REPLACEMENT - IF REQUIRED
BKSSL
Power Pipe™
Stability flange
2 window
Pea gravel or sand
faceplate
shown
1. Loosen #8-32 set screw on faceplate assembly
using a 5/64" Allen wrench and remove.
Optical opening on
Loosen set screw on collar and remove.
faceplate will align with
alignment arrows on
temporary cover
Stability Flange
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
B-K LIGHTING
Flush Mount Installation
Collar 2 window
faceplate
shown
Optical opening on
faceplate will align with
alignment arrows on
temporary cover
Power Pipe™
LINE
COM
2. Pull the heat sink from the body to expose
the LED board and Driver components.
Utilize quick disconnects to change modular
LED and driver components. Re-install the
heat sink into body.
40429 Brickyard Drive • Madera, CA 93636 • USA
www.bklighting.com • info@bklighting.com
MINI-MICRO ™ iLUME™
Finished grade
8 3/4"
PROJECT:
TYPE:
Rebar or stake (by others)
Finished grade
Temporary cover
Surface mount collar
Power Pipe™
12V
Remote
Transformer
FIXTURE
COM
Rebar or stake (by others)
Finished grade
Finished grade
8 3/4"
559.438.5800 • FAX 559.438.5900
Stability flange
Concrete
Pea gravel or sand
3. Replace faceplate assembly and tighten set
screw. Re-Install fixture.
Stability flange
Concrete
2 window
Pea gravel or sand
faceplate
shown
Optical opening on
faceplate will align with
alignment arrows on
temporary cover
Stability Flange
RELEASED REFERENCE NUMBER
11-21-16 INS001080.2
Surface
