B-K lighting BKSSL MINI-MICRO iLUME Installation Instructions page 2

1. Drill 2-1/4" diameter hole, 3" deep minimum, for
fixture.
2 window
faceplate
Align holes
shown
2 window
with window
faceplate
orientation
shown
4. Fit flush mount collar into hole so it is flush with
finished surface. Wipe off any excess adhesive.
NOTE: The optical opening on faceplate will
Wire nuts must
6"
align with the threaded holes in the flush
clear opening
min.
mount collar.
Finished grade
Wire nuts must
clear opening
6"
min.
Finished grade
6. Pull low voltage wire through flush mount collar
and make two low voltage connections using
proper wire connectors (By Others). Insert wires
and fixture back into hole.
2 window
faceplate
shown
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
Optical opening on
faceplate will align with
alignment arrows on
B-K LIGHTING
temporary cover
Rebar or stake (by others) Stability flange
Concrete
Finished grade
Pea gravel or sand
shown
Flush Mount Installation
2. Prepare epoxy according to instructions on
packaging.
Align holes
Finished grade
with window
orientation
5. Supply low voltage wiring necessary for
installation (By Others). Loop minimum of 6" of
low voltage wire behind mounted collar to allow
for fixture service.
Concrete
Align holes
NOTE: Leave sufficient wire length in hole for
2 window
with window
future service.
faceplate
orientation
shown
7. Mount faceplate to collar using (2) #6-32 x 5/8"
flat head cap screws (provided) with 5/64" Allen
wrench.
Finished grade
40429 Brickyard Drive • Madera, CA 93636 • USA
www.bklighting.com • info@bklighting.com
2 window
faceplate
shown
MINI-MICRO ™ iLUME™
PROJECT:
TYPE:
6"
min.
2 window
faceplate
shown
Wire nuts must
6" Concrete
clear opening
min.
559.438.5800 • FAX 559.438.5900
8 3/4"
2 window
faceplate
shown
Optical opening on
faceplate will align with
alignment arrows on
temporary cover
3. Use mixing stick to apply the epoxy to the interior
of the 2-1/4" hole as shown.
LINE
Remote
Transformer
Align holes
COM COM
with window
orientation
WIRING DIAGRAM
Finished grade
8 3/4"
6"
min.
Finished grade
RELEASED REFERENCE NUMBER
11-21-16 INS001080.2
Rebar
Finished
12V
FIXTURE
Rebar
Finished
