Model #
384W
Rustic Sideboard
Assembly Instructions
Congratulations!
This fine piece of furniture will make a handsome
addition to your home. For the best results, start by
reading both the Assembly Instructions and
Finishing Hints before you begin your project.
For normal household use only.
recommended for commercial use.
Do not climb, sit or stand on this piece of
furniture.
Unload items from this unit prior to moving.
Do not overload shelves and drawers on this unit.
Before loading or moving this unit, check all screws
and supports for tightness.
For maximum stability, attach unit to the wall using
the enclosed hardware as per instructions.
Natural characteristics
such as knots provide a
natural feel.
P.O. Box 2827
Eugene, OR 97402 USA
Service Policy:
which are defective, missing or damaged
during assembly. Please contact Whittier
Wood Products customer service department
directly (by phone, fax, mail or email) for
replacement parts.
Hours:
Our friendly customer service staff
can be reached Monday-Friday 7:00 a.m. to
5:00 p.m. (Pacific Time). A message can be
left 24 hours a day, 7 days a week.
To Order:
Provide the complete furniture
model number (upper left corner of this
page), part letter, production code, quantity
needed, reason for replacement and your full
name and address along with a telephone
number in case we need to contact you.
Parts ship from our Eugene, Oregon factory
within 1 or 2 business days from the time
we receive the request. Please allow 5-10
business days for delivery.
Outside U.S. or Canada: 541-687-0213
Fax: 541-687-2060 • Email: info@whittierwood.com
Mail: P.O. Box 2827 • Eugene, Oregon 97402, U.S.A.
Read both the Assembly Instructions and Finishing
Hints completely before beginning.
Store the parts: 1) in their box; 2) in a dry place; 3) in
temperatures ranging from 40° to 90°. (Not on a cold,
possibly damp, cement floor.)
Inspect your furniture periodically for any loose glue
joints or screws, or any other problem which may
be affecting the stability of your furniture. Tighten or
repair as needed.
Production Code:
We will replace any parts
10/05

Advertisement

loading
Need help?

Need help?

Do you have a question about the 384W and is the answer not in the manual?

Questions and answers

Summary of Contents for John Greenleaf 384W

  • Page 1 Model # 384W Rustic Sideboard Assembly Instructions Service Policy: We will replace any parts which are defective, missing or damaged during assembly. Please contact Whittier Wood Products customer service department directly (by phone, fax, mail or email) for replacement parts.
  • Page 2 384W Rustic Sideboard — Parts List BEFORE BEGINNING ASSEMBLY, check that the quantities of the parts received match those on the parts list below. A — Bottom Shelf — Qty. 1 G — Back — Qty. 2 B — Base — Qty. 1 H —...
  • Page 3 384W Rustic Sideboard — Parts List (cont.) ZE — #6 x 1/2" Undercut N — Wood Dowel — Qty. 6 V — #6 x 1/2" Philtruss Screw Screw — Qty. 4 — Qty. 28 O — Rafix Cam — Qty. 4 X —...
  • Page 4: Tools Required

    Veneer parts – apply stain to unexposed portion of Bottom Shelf (A). See FIGURE 3. b) Alder pieces – apply stain to back of Base (B). See FIGURE 3. FIG. 1 1. Lay out the wood parts in their approximate location to aid in the identification and assembly. Page 4 — 384W...
  • Page 5: Top View

    Tap in two Rafix Cams (O), with notch facing • Two in each Side Assembly (C & E) the edge, into the larger holes near the top • Four in the Base (B) edge of each Side Assembly (C & E). 384W — Page 5...
  • Page 6 Attach the Bottom Shelf Assembly (A & B) to the Left Side Assembly (C) gluing the Wood Dowel (N) in the Left Side Assembly (C) into the Base (B). Fasten Bottom Shelf (A) in place with two Cam Housings (R). Page 6 — 384W...
  • Page 7 6. Lay the Top (F) on a protected surface and lower the Side Assemblies down over the Rafix Bolts (P) in the top. Tighten Rafix Cams (O). Secure the upper Sleeper (D) to the Top (F) using Screw (T) through the pre-drilled holes in the upper Sleeper (D). See FIGURE 6 384W — Page 7...
  • Page 8 8. Stand the unit upright. Remove the outer slide section from each Ball Bearing Slide (ZA). To do so, fully extend the slide as shown, press the release lever and remove each outer section. See FIGURE 8. Page 8 — 384W...
  • Page 9 If one is longer, hold the drawer by the corners on the longest line and squeeze them together until square. See FIGURE 10B. Attach two Knobs (ZB) to the Drawer Face (K) using two 1½” Machine Screws (ZC). See FIGURE 10C. 384W — Page 9...
  • Page 10 (D). Make sure the back of the Magnetic Catch (ZF) is flush with the back edge of the lower Sleeper (D). Use the pan head screws provided in the kit to secure the catch in place. See FIGURES 12C & 12D. Page 10 — 384W...
  • Page 11 Use Screw (ZH) in these holes. See FIGURE 14A. Once each door is in place use a second Screw (ZH) in each hinge to hold it securely. See FIGURE 14B. Attach a Knob (ZB) to each door using a 1¼” Machine Screw (ZI). See FIGURE 14C. 384W — Page 11...
  • Page 12 When both doors are adjusted insert the third Screw (ZH) in each hinge. See FIGURE 15C. 16. Once in place and level, install the Furniture Tipping Restraint (ZJ). Carefully follow the instructions contained on the package. Page 12 — 384W...
