AP-S15HRIP / AP-S15IP / AP-S158IP
IP Power Distribution Systems
AP-S15HRIP
AP-S15IP
AP-S158IP
AP-LEDIP
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
– 1 –
TELEPHONE: (800) 876-3333
SUPPORT@ATLASIED.COM
AtlasIED.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AP-S15HRIP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Atlas IED AP-S15HRIP

  • Page 1 AP-S15HRIP / AP-S15IP / AP-S158IP IP Power Distribution Systems AP-S15HRIP AP-S15IP AP-S158IP AP-LEDIP 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 1 –...
  • Page 2: Table Of Contents

    AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual Table of Contents Important Safety Instructions ....................................3 Introduction ..........................................5 Key Features and Applications ....................................6 Opening the Carton ........................................ 6 System Overview ........................................7 Features ..........................................10 Installing the AP-IP Power Distribution System ..............................12 Accessing the WEB GUI Interface ..................................
  • Page 3: Important Safety Instructions

    AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual Important Safety Instructions The lightning flash with arrowhead symbol within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage “ within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
  • Page 4 AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual WARNING - When The Device Is In Use • WARNING: For the terminals marked with symbol of may be of sufficient magnitude to constitute a risk of electric shock. The external wiring connected to the terminals requires installation by an instructed person or the used of ready-made leads or cords.
  • Page 5: Introduction

    Through the UI, alarms can be set to alert users when a fault condition has occurred via the network UI or fault contacts. Models AP-S15IP and AP-S15HRIP include rear outlets that are programmable and can be scheduled to sequence On / Off individually or in groups on a 24-hour / 7-day schedule.
  • Page 6: Key Features And Applications

    AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual Applications The flexible AP-IP power distribution system family was designed with features enabling them to be used in a variety of applications. They can be used for AC distribution or for system power and protection against voltage surges or dropouts. They are ideal for systems that need to be powered On or Off at specific times to conserve energy or to monitor the system for faults and operability.
  • Page 7: System Overview

    AP-S158IP is a vertical mount power strip with eight programable outlets. The AP-S15IP is a 19" rack mount power strip with eight programable rear outlets and 1 front panel unswitched outlet. The AP-S15HRIP is half rack, rack mount power strip with five programable rear outlets and 1 front panel switched outlet.
  • Page 8 AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual AP-S15IP The AP-S15IP is a 19" rack mount power distribution system with eight programable rear outlets and 1 front panel unswitched outlet. Fault Report connected to Texas Tough Rack will Change Logo Color when...
  • Page 9 AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual AP-S158IP The AP-S158IP is a vertical mount power distribution system with eight programable outlets. Control EQUIPMENT RACK System WIRELESS MIC RECEIVER SOURCE MEDIA PLAYER Programmed Local Lan Local Lan for Always SIGNAL PROCESSOR...
  • Page 10: Features

    AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual Unit Features AP-S158IP Shown AC Mains Input - Connect the IEC 14-Gauge 6' (2m) power cord to a 15A 120VAC outlet to provide power to the unit. An IEC power cord retainer clip is included to prevent accidental removal of the power cord from the unit.
  • Page 11 9. AC Power Programmable Outlets - The AP-S158IP and the AP-S15IP feature eight programable NEMA 5-15P AC switched outlets and the AP-S15HRIP has five. These switched AC outlets are “live” when the front panel power switch is in the ON position and the outlet is activated via the WEB interface or by pressing the AC outlet indicator ON/OFF switch (see AC outlet Switches &...
  • Page 12: Installing The Ap-Ip Power Distribution System

    Rack Mounting the AP-S15HRIP A rack kit is included with the purchase of the AP-S15HRIP . The AP-S15HR width fits most rack cabinets that are classified as half-width. There are no industry standards for these types of racks and rack widths may vary between manufactures. The AP-S15HRIP can be mounted into an AtlasIED wall mount half-width rack or a 19”...
  • Page 13 AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual Configuration 1 - Mounting a Single 1 RU Model Remove amplifier from electrical source. 2. Remove the four feet. 3. Align and secure the chassis extension plate to a rack mount ear with the enclosed screws and nuts.
  • Page 14 Note: Not all 1RU half rack models can be joined next to each other. The following combinations can be joined: ASP-MG2240, DPA102PM, MA40G, MA60G, PA40G, PA60G, AP-S15HR, AP-S15RTHR, and AP-S15HRIP are interchangeable. Note: Two AP-S15HR units cannot be rack mounted together side-by-side.
  • Page 15 AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual Front Panel Joiner Plate Not used on PA702 or PA1001G 4-40 x Flat Head Screw 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 15 –...
  • Page 16: Accessing The Web Gui Interface

    AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual Accessing the Unit’s Web UI Interface The AtlasIED AP-IP power distribution system’s GUI control panel is designed to be accessed via the LAN (Local Area Network) or local computer. External software is not required for operation. The Web browser UI control interface software is embedded in the unit. Remote access to the device can be set up through a VPN connection by working with the client or facility’s IT administrator.
  • Page 17 AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual IP Scan Range In this section of the discovery software enter the Start and End range of the IP address search. Select the drop-down arrow in the “Select NIC” window. The number listed in this window is the IP address of the computer’s NIC. Select the IP address and it will auto fill the Start and End IP fields.
  • Page 18: Logging Into The Unit

    AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual Logging Into the Unit Each unit has a unique password assigned to it. Enter the unit’s factory default password as show in the illustration below. The password is the last 4 digits of the MAC address. Find the MAC address label on the chassis. Example: A MAC address looks like (40-D8-55-10-D0-66). Input D066 (No dash) as the password to access the unit.
  • Page 19 AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual Static IP Address This setting can be found in the web interface under the Network Settings page. Static mode can be selected, and the Static IP address, Subnet Mask and Gateway can be entered. Note: If the selection is changed to “Static” , the user must select “Save” and the unit’s power must reset the power switch.
  • Page 20: Status Settings Web Page

    Owner’s Manual Status Settings WEB Page This section uses the AP-S158IP as an example. UI features are the same for all three models. Note The AP-S15HRIP has 5 programmable outlets and the AP-S15IP and the AP-S158IP have 8 programmable outlets.
  • Page 21 AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual 5. Voltage Alarm Status Indicator • This indicator is always enabled and cannot be disabled for the protection of the equipment. • Over Voltage (High) & Under Voltage (Low) trigger voltage settings can be set in the alarm page.
  • Page 22 AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual 8. Outlet Manual On / Off Switches • To manually turn an AC outlet On or Off, mouse click on the box - the AC outlet will turn On and a check will appear in the box indicating the outlet is On.
  • Page 23: Alarm Settings Web Page

    AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual Alarm Settings WEB Page Alarm Page is selected. 2. Save Button - Make sure to select this after every change or the new setting will not be applied. 3. Temp Alarm Enabled Button •...
  • Page 24 AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual 6. Humidity Alarm Settings • Enter the value for the humidity alarm to trigger. The operating range is 15-95% • Select Save. • If the alarms are activated the GUI and front panel indicators will turn red until the values are within safe operating range.
  • Page 25 AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual 11. Voltage Alarm Recovery - Manual Reset or Auto Recovery • Voltage Alarm Recovery can be set to Auto Recover or Manual Reset. • Auto Recover selection, if the alarm is triggered and the AC outlets are shut Off and the AC mains voltage is within the safe operating parameters, all outlets will turn back On automatically.
  • Page 26: Scheduler Settings Web Page

    AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual Scheduler Settings WEB Page Scheduler Page is selected. 2. Save Button - Make sure to select this after every change or the new setting will not be applied. 3. Day / Time NTP (Network Time Protocol) - Reflects the Date and Time of the associated LAN.
  • Page 27 12. Message Note • Note 1: If the Fan control is enabled, outlet 5 (AP-S15HRIP) and outlet 8 (AP-S15IP & AP-S158IP) cannot be assigned to the Group setting. • Note 2: If an outlet is enabled, it is assigned to the Group Assignment and cannot be assigned to an individual schedule.
  • Page 28: Network Settings Web Page

    AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual Network Settings WEB Page - Network Interface Section Network Settings Page is selected. 2. Save Button - Make sure to select this after every change or the new setting will not be applied.
  • Page 29 AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual Network Settings WEB Page - Password, Reboot, Factory Default Section 10. Password - Enter “Admin” here to change the Factory Default password. If the password is lost, a hard reset is required to reset it back to ’admin” .
  • Page 30: Configuration Settings Web Page

    • Note: If the Fan control is enabled, outlet 5 (AP-S15HRIP) and outlet 8 (AP-S15IP & AP-S158IP) cannot be assigned to the Group setting. 11. Save Button - Make sure to select this after every change or the new setting will not be applied.
  • Page 31: Updating The Firmware

    AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual Configuration Settings WEB Page - Outlet Naming Section 12. Unit Name - This is the name of the unit. It can be changed to make identifying the AP-S158IP easier when there are more than one on the same LAN.
  • Page 32: Specifications

    Outlet On / Off Switches Momentary Manual NEMA5-15R Switched (Programmable), Qty 8 (AP-S15HRIP Qty 5) AC Outlets Note: Outlet 8 Can Be Used to Activate a Fan Triggered by Temperature Range of On: 51° - 176°F / Off: 50° - 175°F...
  • Page 33 North America UL60950-1, CAN/CSA C22.2 No. 60950-1, UL1449 Note 1: The AP-S15HRIP , AP-S15IP , and AP-S158IP meet the Californian law SB-327 . Each unit is shipped with a unique password that can be changed for accessing the device over the network. They are LAN (Local Area Network) devices and require a firewall or VPN for secure connection outside the network operation.
  • Page 34: Dimensional Drawings

    AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual Dimensional Drawings - AP-S15HRIP 10.4" (264.1mm) Switched Alarms AC Fault 1.75" (45mm) AP-S15HRIP AC Ground OC/OV IP Addressable Power Distribution Unit Fault Report Display 5 / Fan Sensor 8" (204mm) 1601 Jack McKay Blvd. • Ennis, TX 75119 800.876.3333 •...
  • Page 35 AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual Dimensional Drawings - AP-S15IP 19" (480.8mm) Alarms Unswitched Reset OC/OV AC Ground AC Fault 1.75" (45mm) AP-S15IP IP Addressable Power Distribution Unit 8 / Fan Fault Sensor Display Report 6" (153.2mm) 7.35" (186.7mm) 1601 Jack McKay Blvd.
  • Page 36 AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual Dimensional Drawings - AP-S158IP 40.5" (1028.7mm) 39" (990.6mm) Alarms 8 / Fan 2.24" Reset Fault Report AC Ground AC Fault OC/OV (57mm) Display Sensor AP-S158IP Vertical IP Addressable Power Distribution Unit 3.33" (85mm) 1601 Jack McKay Blvd.
  • Page 37 AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual Notes: 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 37 –...
  • Page 38 AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual Notes: 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 38 –...
  • Page 39 AP-S15HRIP / AP-S15IP / AP-S158IP Owner’s Manual Notes: 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 39 –...
  • Page 40: Warranty

    Limited Warranty All products manufactured by AtlasIED are warranted to the original dealer/installer, industrial or commercial purchaser to be free from defects in material and workmanship and to be in compliance with our published specifications, if any. This warranty shall extend from the date of purchase for a period of three years on all AtlasIED products, including SOUNDOLIER brand, and ATLAS SOUND brand products except as follows: one year on electronics and control systems;...
