Omega OBMF468X Instruction Manual

Bottom mount 486l
Hide thumbs

Advertisement

Quick Links

Download this manual
Instruction Manual
Fridge Freezer
Bottom Mount 486L
OBMF468X

Advertisement

loading
Need help?

Need help?

Do you have a question about the OBMF468X and is the answer not in the manual?

Questions and answers

Related Manuals for Omega OBMF468X

Summary of Contents for Omega OBMF468X

  • Page 1 Instruction Manual Fridge Freezer Bottom Mount 486L OBMF468X...
  • Page 2 Thank you for purchasing an Omega appliance Tailored for the modern aesthetic and lifestyle of busy people, your new Omega Appliance will make a welcome addition to the family. Omega caters to style-savvy customers who look for balance between stunning form and clever function.

  • Page 3: Table Of Contents

    The manufacturer will not be responsible for any damage to property or to persons caused by incorrect installation or improper use of the appliance. Due to continual product development, Omega reserves the right to alter specifications and appearances without notice.

  • Page 4: Important Safety Warnings

    Important Safety Warnings Read the safety precautions and assembly instruction section of this booklet carefully before removing the contents of this carton. This appliance is not to be use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience or knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety.
  • Page 5 Warnings for Disposal  Refrigerant and cyclopentane foaming material used for the refrigerator are flammable. Therefore when the refrigerator is scraped, it shall be kept away from any fire source and be recovered by a special recovering company with corresponding qualification other than be disposed by combustion, so as to prevent damage to the environment or any other harm.

  • Page 6: Installation Instruction

    Installation Instruction Unpacking the appliance  Before use, remove all packing materials, including bottom cushions, foam pads and tapes inside of the refrigerator; tear off the protective film on the doors and the refrigerator body.  Keep away from heat and avoid direct sunlight. Do not place the freezer in moist or watery places to prevent rust or reduction of insulating effect.
  • Page 7 Installation Instruction Door space requirement The fridge’s door must be able to open fully as shown below. W×D≥1080×1215mm Door handle installation Precaution shall be taken be taken to prevent fall of the handle from causing any personal injury. List of tools to be provided by the user Allen wrench...
  • Page 8 Installation Instruction Levelling feet Adjusting procedures: a. Turn the feet clockwise to raise the refrigerator. b. Turn the feet counter-clockwise to lower the refrigerator. c. Adjust the right and left based on the procedures above to a horizontal level. Door right-left change List of tools to be provided by the user Phillips head screwdriver Putty knife thin-blade...
  • Page 9 Installation Instruction 2. Dismantle the upper decorative cover, screws and upper hinge. Unplug the wiring connector of the top right side of refrigerator (1 and 2 wiring connector). 3. Take off refrigerating chamber door, middle hinge (use an alien wrench to remove the middle hinge screw) and hole cap of other side.
  • Page 10 Installation Instruction 4. Take off freezing chamber door, dismantle bottom hinge, hole caps, levelling foot, Install shaft of bottom hinge on the other side and install the bottom hinge on the other side. 5. a) Remove the upper cover of refrigerating chamber door and the left decorative cover, install the upper hinge sleeve, door signal line to the other side and install the door upper cover.
  • Page 11 Installation Instruction 6. Put freezing door on bottom hinge and install middle hinge, hole caps 7. Dismantle the right hinge cover from the decorative cover, then take out left hinge cover from accessory bag, install left hinge cover on the left side of decorative cover.
  • Page 12 Installation Instruction 8. Take out the top left hinge from accessory bag. Put refrigerating chamber door on middle hinge, install top left hinge. Connect signal line terminal 4 with signal line terminal 1, connect signal line terminal2 with signal line terminal3; Install top hinge cover. For the assembly of handle, please refer to Door handle installation.
  • Page 13 Installation Instruction Before using your unit  Do not damage the power cord under any condition so as to ensure safety use, do not use when the power cord is damaged or the plug is worn.  Do not put flammable, explosive, volatile and highly corrosive items in the refrigerator to prevent damages to the product or fire accidents.

  • Page 14: Operation Instruction

    Operation Instruction Refrigerating chamber • The Refrigerating Chamber is suitable for storage of a variety of fruits, vegetables, beverages and other food consumed in the short term. • Cooking foods shall not be put in the refrigerating chamber until cooled to room temperature. •...
  • Page 15 Operation Instruction Functions Display screen 1. Refrigerating chamber temperature display area 4. Quick freeze icon 2. Freezing chamber temperature display area 5. Vacation icon 3. Quick cool icon 6. Lock icon Operation button A. Temperature setting button of refrigerating chamber B.
  • Page 16 Operation Instruction Lock /unlock In the unlock state, long press the lock button for 3 seconds, enter the lock state, the icon lights up and buzzer sounds, it means the display panel is locked, at this time, button operation cannot be implemented; In the lock state, long press the lock button for 3 seconds, enter the unlock state, the icon goes...
  • Page 17 Operation Instruction Vacation model Press the button to set vacation model, the icon lights up. The refrigerating chamber temperature display goes out, the freezing chamber temperature display -18° C. Under vacation mode, press the button again, the icon goes out, it exits in Quick freeze mode. The temperature setting of refrigerating chamber and freezing chamber will automatically switch back to set temperature before vacation mode.

  • Page 18: Care And Maintenance

    Care and Maitanence Cleaning the Interior and the Exterior of the Unit Warning: Unplug the refrigerator for defrost and cleaning.  Dusts behind the refrigerator and on the ground shall be timely cleaned to improve the cooling effect and energy saving. ...
  • Page 19 Care and Maitanence Changing the Internal Light Any replacement or maintenance of the LED lamps is intended to be made by the manufacturer, its service agent or similar qualified person. Defrosting The refrigerator is made based on the air-cooling principle and thus has automatic defrosting function. Frost formed due to change of season or temperature may also be manually removed by disconnection of the appliance from power supply or by wiping with a dry towel.

  • Page 20: Trouble Shooting

    Trouble Shooting You may try to solve the following simple problems by yourself. If they cannot be solved, please contact customer service.  Check whether the appliance is connected to power or whether the plug is in well contact  Check whether the voltage is too low Failed operation ...

  • Page 21: New Zealand Product Warranty Statements Of Standard Warranty Conditions

    Our Warranty is for a period of forty eight (48) months from HOW TO CLAIM YOUR WARRANTY the date of purchase. Please refer to our website address below for Omega to register your warranty online. This is in addition to (and does not exclude, restrict or...
