- Page 1 Designed to Enhance E S T. � 9 8� Installation + User Manual OIFDF439 Integrated French Door Refrigerator 439L omegaappliances.com.au V1.3 0225...
-
Page 2: Table Of Contents
User Manual Refrigerator Contents Welcome Safety Information Your Refrigerator Installing Your Refrigerator Operating Instructions Food Storage Advice Cleaning & Maintenance Troubleshooting Purchase Details Warranty Information... -
Page 3: Welcome
It is important that you read through the following user manual thoroughly, in order to familiarise yourself with the installation and operation requirements of your appliance, and to ensure optimum performance. Again, thank you for choosing an Omega appliance and we look forward to being of service to you. Kind Regards,... -
Page 4: Safety Information
Before Using Your Appliance Read Carefully and Keep for Future Reference This manual explains the proper use of your Omega Refrigerator. Please read this manual carefully before using the product. Read this manual thoroughly before first use, even if you This manual should be kept in a safe place for handy reference. -
Page 5: Children And Vulnerable People Safety
Designed to Enhance User Manual Refrigerator Safety Information (Continued) Children & Vulnerable People Safety Electrical Connection WARNING: Risk of suffocation, injury or permanent disability. CAUTION: Risk of fire and electrical shock! • Ensure the appliance's plug is easily accessible. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, •... -
Page 6: Appliance Placement
User Manual Refrigerator Safety Information (Continued) Appliance Placement Appliance Use • Use this appliance in a domestic household only. WARNING: Risk of fire, explosion, electric shock or damage to the appliance. • Avoid installing it in wet or high humidity environments to prevent deterioration and electrical hazards. -
Page 7: Disposal Of The Appliance
Designed to Enhance User Manual Refrigerator Safety Information (Continued) Disposal of the Appliance Unpacking • Disconnect the appliance from the mains supply, cut off the • During transportation, protective packaging was used to mains cable and discard it. protect the appliance against any damage. After unpacking, please dispose of all elements of packaging in a way that •... -
Page 8: Your Refrigerator
User Manual (×1) F. Freezer Drawers (×3) Quick Start Guide (×1) G. Ice Tub * Not pictured, also available online: www.omegaapliances.com.au Model: OIFDF439 Note: The diagrams and images in this user manual are for explanatory purposes only. Your appliance may appear differently. -
Page 9: Product Dimensions
Designed to Enhance User Manual Refrigerator Your Refrigerator (Continued) Product Dimensions The dimensional diagrams for this refrigerator provide essential information about its size and layout. These diagrams detail the fridge's measurements enabling you to plan its placement effectively. Note: The diagrams and images in this user manual are for explanatory purposes only. Your appliance may appear differently. 115°... -
Page 10: Installing Your Refrigerator
User Manual Refrigerator Installing Your Refrigerator Preparing the Cabinetry • The height of the Base Trim should be between 80–120mm. In order to ensure that the built-in appliance functions properly, the cabinet containing it must be appropriate. The diagram If it exceeds this range, it may impact cooling performance. below gives the dimensions of the cut-out for installation and •... -
Page 11: Installation Of Power Supply
Designed to Enhance User Manual Refrigerator Installing Your Refrigerator (Continued) Transportation Installation of Power Supply • Avoid transporting the refrigerator horizontally or laying it down. Please follow these guidelines for safe installation and use: Keep it upright during transportation to prevent damage. •... -
Page 12: Cabinet Inspection
User Manual Refrigerator Installing Your Refrigerator (Continued) Cabinet Inspection IMPORTANT: Rick of Electric Shock! • Ensure the cabinet dimensions and door panel match the • Electrical grounding is required. The appliance is equipped with specifications (refer to the dimension drawing on page 10). a three-pin plug to protect against electric shocks. -
Page 13: Installation Accessories
Designed to Enhance User Manual Refrigerator Installing Your Refrigerator (Continued) Installation Accessories The following installation accessories are supplied with your Refrigerator: A. Anti-Tip Bracket (×2) M. M5×5, Cross Head Screws (×2) B. Anti-Tip Bracket Screws and Dowels (×8) N. Freezer Top Door Cover (×1) C. - Page 14 User Manual Refrigerator Installing Your Refrigerator (Continued) Your Installer Will Require: Preparing the Cabinetry Mounting the Anti-Tip Brackets The following items are required for the installation process of your Refrigerator: • Mark the inside cabinetry walls for anti-tip brackets. Cordless Drill 1/2"...
- Page 15 Designed to Enhance User Manual Refrigerator Installing Your Refrigerator (Continued) Attaching Brackets to the Cabinetry Figure 4 3 mm Thickness • Secure the cabinetry brackets using the ST4×12 crossed flat head tapping screws. (Refer to Fig. 7 & 8) Figure 7 1925 mm •...
-
Page 16: Positioning The Unit
User Manual Refrigerator Installing Your Refrigerator (Continued) Positioning the Unit • Remove the 4 screws holding the vent grille. (Refer to Fig. 12). • Carefully push the refrigerator toward the cabinetry until it fits securely in place. (Refer to Fig. 10). Figure 12 Figure 10 Connecting the Water Line... - Page 17 Designed to Enhance User Manual Refrigerator Installing Your Refrigerator (Continued) Positioning Adjustment Tool Adjusting for Level and Height • Begin by raising the front adjustable feet to reduce the risk of Adjust the Position Adjustment Tool to match the depth thickness of the door panel.
- Page 18 User Manual Refrigerator Installing Your Refrigerator (Continued) Attaching the Cabinetry Door • Attach the lower cabinetry brackets to the cabinetry with four screws (ST4×14). (Refer to Fig. 20 & 21). • Attach the cabinet door connecting bracket to the cabinetry door using two ST4×14 screws.
- Page 19 Designed to Enhance User Manual Refrigerator Installing Your Refrigerator (Continued) Water Hose Connection Cabinetry Door Installation Instructions • Remove the upper and lower adjusting mechanism assemblies Use two wrenches to securely connect the hose from the mains to the hose from the valve. (Refer to Fig. 22). from the refrigerator doors.
- Page 20 User Manual Refrigerator Installing Your Refrigerator (Continued) • Install the cradles using chipboard screws (ST4×14). • Use the adjustment bolts for precise alignment, allowing (Refer to Fig. 27). for up/down, front/back, and left/right adjustments. (Refer to Fig. 29–32). Figure 27 Figure 29 •...
- Page 21 Designed to Enhance User Manual Refrigerator Installing Your Refrigerator (Continued) • Use the cabinet door connecting bracket and 2 screws (ST4×12) • Attach the cabinet door bracket covers over the cabinet door to fasten the cabinetry door to the fridge door. connecting brackets.
- Page 22 User Manual Refrigerator Installing Your Refrigerator (Continued) • Attach the cabinet door to the freezer door. (Refer to Fig. 35). • Secure the brackets using 2 screws (M5×16) and 2 shim washers. Figure 35 Figure 37 Front & Back • Use the adjustment bolts for precise alignment, allowing •...
-
Page 23: Final Checks
Designed to Enhance User Manual Refrigerator Installing Your Refrigerator (Continued) Limiting the Door Opening to 90° • Attach the door side trims by removing the backing paper of the double-sided tape. (Refer to Fig. 39). If desired, you can restrict the door's opening angle to 90° to NOTE: Ensure the backing paper is removed before attaching prevent it from swinging too wide and potentially hitting adjacent the trim. - Page 24 User Manual Refrigerator Installing Your Refrigerator (Continued) Rearranging the Door Tray Crisper Compartment To Remove a Door Tray: To Remove the Crisper: • Lift up the door tray and then 1. Pull the crisper drawer out until it stops. pull it out straight. 2.
-
Page 25: Operating The Product
Designed to Enhance User Manual Refrigerator Installing Your Refrigerator (Continued) 5 Operating the product Special fridge compartment Freezer Drawer You can control the temperature in this section to store your food such as fish, meat, vegetables and delicatessen products for a longtime. The freezer compartment maintains a temperature between -24°C and -18°C to keep your food fresh for extended periods. -
Page 26: Operating Instructions
User Manual Refrigerator Operating Instructions Control Panel A. Temperature Display B. Power Button C. Menu Button D. Temperature Button E. Select Button F. Fridge/Variable Zone/Freezer Icon The Functions Fast Chill Fast Freeze Vacation Mode Ideal for quickly chilling large quantities Helps preserve nutrients in fresh foods Saves energy by maintaining safe of groceries or drinks after stocking the... -
Page 27: Functions Selection
Designed to Enhance User Manual Refrigerator Operating Instructions (Continued) Before First Use Functions Selection • Ensure that the refrigerator is correctly installed following the Pressing the "Feature" button will cycle through the available Installing Your Refrigerator section. refrigerator functions with each press. •... -
Page 28: Child Lock
User Manual Refrigerator Operating Instructions (Continued) Child Lock Dual Cooling System The refrigerator is equipped with a Dual Cooling System, While in Child Lock mode, the refrigerator's control panel disables the functionality of other buttons, ensuring the safety featuring two separate cooling circuits for the Fridge and of settings and preventing accidental changes by children. -
Page 29: Food Storage Advice
Designed to Enhance User Manual Refrigerator Food Storage Advice • Ensure that foods do not block the air outlet to maintain CAUTION: Avoid direct contact between food, especially oily proper air circulation and prevent abnormal operation. items, and the refrigerator liner. Promptly clean any oil or oily food stains to prevent prolonged contact, which can lead to liner •... -
Page 30: Freezing Fresh Food
User Manual Refrigerator Food Storage Advice (Continued) Fridge Storage Recommendations Freezing Fresh Food • Temperature Settings: • When freezing food, it's important to use fresh and undamaged Setting the temperature too high or too low can shorten the items. For optimal nutritional value, flavour, and colour retention, shelf life of your food, resulting in increased food waste. -
Page 31: Cleaning And Maintenance
Designed to Enhance User Manual Refrigerator Cleaning & Maintenance Defrosting On Vacation Automatic Defrosting: With a built-in program, the unit controls Before leaving for vacation, it's recommended to keep the the frequency and duration of freezer defrosting, eliminating the refrigerator running continuously and leave foods that can be need to manually defrost the freezer. -
Page 32: Low Voltage
User Manual Refrigerator Cleaning & Maintenance Troubleshooting Button Failure Fault Display If you experience button failure, please check the control panel This appliance features a Fault Display & Alarm function. If a to see if the fridge is in Child Lock mode. When the fridge is in sensor malfunctions, an alarm will appear on the temperature Child Lock mode, all buttons are disabled and won't function. - Page 33 Designed to Enhance User Manual Refrigerator Troubleshooting (Continued) For Minor Faults Problem Possible Cause Solution No display on the The mains plug of the appliance is not Check whether the power is on. display panel in the socket properly. Alarm sound Door is slightly open or not close more Close the door completely.
-
Page 34: Purchase Details
User Manual Refrigerator Purchase Details Attach your receipt to this page For future reference, please record the following information which can be found on the rating plate and the date of purchase which can be found on your sales invoice. Store Details Store Name Address... - Page 35 Designed to Enhance User Manual Refrigerator Notes...
- Page 36 User Manual Refrigerator Notes...
- Page 37 Designed to Enhance User Manual Refrigerator Notes...
-
Page 38: Warranty Information
User Manual Refrigerator Warranty Information WARRANTY TERMS AND CONDITIONS In this warranty REFRIGERATORS ‘acceptable quality’ as referred to in clause 10 of this warranty has the same meaning referred to in the ACL; This document sets out the terms and conditions of the product ‘... - Page 39 Designed to Enhance User Manual Refrigerator Warranty Information For Appliances and services provided by Residentia You will bear the cost of transportation, travel and delivery of the Appliance to and from Residentia Group or its ASR. If you Group in Australia, the Appliances come with a guarantee reside outside of the service area, you will bear the cost of: by Residentia Group that cannot be excluded under the travel of an authorised representative;...
- Page 40 E S T . 1 9 8 1 Designed to Enhance Omega is proudly owned, designed and engineered @residentia.group in Australia by Residentia Group Pty. Ltd. www.residentia.group...
