Steps
1. Place the power-button assembly and its cable in the slot on the palm-rest assembly.
2. Place the power-button bracket on the power-button assembly.
3. Align the screw holes on the power-button bracket to the screw holes on the palm-rest assembly.
4. Replace the three (M2x1.9) screws that secure the power-button bracket to the palm-rest assembly.
5. Adhere the power-button assembly cable on the palm-rest assembly.
Next steps
1. Follow the procedure from step 3 to step 24 in
2. Install the right IO-board.
3. Install the rear IO-cover.
4. Install the M.2 2230 solid-state
5. Install the M.2 2280 solid-state
6. Install the battery.
7. Install the base cover.
8. Follow the procedure in

Keyboard

Removing the keyboard

Prerequisites
1. Follow the procedure in
2. Remove the base cover.
3. Remove the battery.
4. Remove the M.2 2230 solid-state
5. Remove the M.2 2280 solid-state
6. Remove the rear I/O-cover.
7. Remove the speakers.
8. Remove the right I/O-board.
9. Follow the procedure from step 1 to step 19 in
58
Installing the system
drive. (if applicable)
drive. (if applicable)
After working inside your
Before working inside your
drive. (if applicable)
drive. (if applicable)
Removing the system
board.
computer.
computer.
board.
