- Page 1 Weight Indicator X1M . X3(A)M. X5M User Manual v.201802 An ISO9001 registered company @No.335 Haishen, Xingxin Road, Huinan Town, Pudong District, Shanghai 201301, China www.hiweigh.com All rights reserved, specifications subject to change without notice...
-
Page 3: Safety Precautions
1 Introduction Safety precautions WARNING! ▲ Do not use X*M Series indicators in hazardous area or in dusty environments. ▲ Never flood the Indicator, immerse it in liquid or pour liquids on it. ▲ Do not expose indicator to either direct sun light or any heat sources. ▲... -
Page 4: Specifications
• X3AM: plastic • X3M: stainless steel • X5M: stainless steel • X1M: plastic • X3AM: 275 x 160 x 120 mm Dimensions • X3M: 275 x 160 x 120 mm • X5M: 275 x 160 x 80 mm • X1M: 255 x 170 x 130 mm Weight •... -
Page 5: Front Panel
Front Panel 3.1 LCD Symbols Symbols Meaning 888888 6-digit display Weight unit in kilogram Weight displayed to X10 resolution AC adapter is connected Low battery warning 10% of full charge Configuration mode Calibration mode set point A ≤ weight < set point B set point B ≤... -
Page 6: Switching Off
Proceed to next step Move flashing digit that can be changed to the next digit on the right → Display weight to X10 resolution ↑ Zero display or enter a tare value →0/T← 3.4 LCD Error Code Code Meaning OUEr Weight >... -
Page 7: Acquire Tare
4.7 Tare 4.7.1 Acquire tare 1. Tare can be set only after the display has been zeroed. Check to make sure zero status turned on. 2. Place the empty container on the platform. 3. Wait until the weight is stable when the stable status is displayed. -
Page 8: Clear Accumulation Data
The factory default AUt = 0 Press AUt 0 Zero AUt and the digit is flashing Press → AUt 0 Set AUt = 1 Press ↑ AUt 1 Set AUt = 2. Repeat pressing ↑ to select the desired mode Press ↑... - Page 9 5.2 Set point There are 4 set points A, B, C and D and 3 status symbols LO, OK and HI. These symbols are displayed under the following conditions: Symbols Trigger condition set point A ≤ weight < set point B set point B ≤...
-
Page 10: Connecting To A Printer
6.2 RS232 serial interface 6.2.1 RS232 settings Number of bits Parity Number of stop bit 6.2.2 RS232 / RS485 connector Pin No. Label Description RS232 TxD RS232 TxD RS232 GND RS485 A RS485 B 6.2.3 Connecting to PC X*M DB9 Pin No. PC DB9 Pin No. -
Page 11: Zero Command
Output format Weight –1234.5 – Adr = 99 output format Byte No. Output format Weight 1234.5 ‘ ‘ 6.4 RS232 ASCII commands When the indicator address (Adr) is set to 01 to 98, RS232 commands can be transmitted to the indicator configure, query and operate the indicator. -
Page 12: Tare Command
6.4.2 Tare command Adr = 5, gross weight = 88.68kg, stable status is displayed PC Command Byte No ASCII Indicator response Indicator sets tare to 88.68kg, zero display and displays tare status . There is no RS232 response. 6.4.3 Remove tare Adr = 5, net weight = 59.08kg, tare = 29.60kg, stable and tare status are displayed... - Page 13 Byte No ASCII Indicator response Byte No. ASCII 6.5 Printer format n = 3, gross = 88.69kg, tare = 29.41kg, net = 59.28kg No:XXXX G:XXXXXXkg G: 88.69kg T:XXXXXXkg T: 29.41kg N:XXXXXXkg N: 59.28kg Accumulated weight No:XXXX W:XXXXXXXkg W: 118.09kg 7 Services Services include a full range of technical on site services and workshop repair, preventative maintenance and calibration facilities.
- Page 15 X1M.X3(A)M.X5M User Manual An ISO9001 registered company @No.335 Haishen, Xingxin Road, Huinan Town, Pudong District, Shanghai 201301, China www.hiweigh.com All rights reserved, specifications subject to change without notice...
