Our instruments' quality level is the results of the product continuous development. This
can bring about differences between the information written in this manual and the instru-
ment that you have purchased. We cannot entirely exclude errors in the manual, for which
we apologize.
The data, figures and descriptions contained in this manual cannot be legally asserted. We
reserve the right to make changes and corrections without prior notice.
HD2205.2
HD2206.2
HD2256.2
REV. 1.0
18 Oct. 2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD2205.2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Delta OHM HD2205.2

Summary of Contents for Delta OHM HD2205.2

  • Page 1 REV. 1.0 18 Oct. 2006 HD2205.2 HD2206.2 HD2256.2 Our instruments' quality level is the results of the product continuous development. This can bring about differences between the information written in this manual and the instru- ment that you have purchased. We cannot entirely exclude errors in the manual, for which we apologize.
  • Page 2 HD2205.2 Dual pH - Temperature HD2206.2 Conductivity - Temperature HD2256.2 pH - Conductivity - Temperature 1. LCD Display 2. CONTRAST+ key, allows to increase the display contrast. 3. CONTRAST- key, allows to decrease the display contrast. 4. Function keys F1, …, F5.
  • Page 3 HD2205.2 connectors: Dual pH - Temperature 20. Power supply input 12Vdc for the ∅ 5.5mm - 2.1mm connector. Positive at centre. 21. RS232C serial port, sub D 9-pole male connector. 22. 8-pole DIN45326 connector, input for Pt100 temperature probes with SICRAM module, 4 wire direct Pt100 probes, 2 wire direct Pt1000 probes 23.
  • Page 4 HD2206.2 connectors: Conductivity - Temperature 20. Power supply input 12Vdc for the ∅ 5.5mm - 2.1mm connector. Positive at centre. 21. RS232C serial port, sub D 9-pole male connector. 22. 8-pole DIN45326 connector, input for combined 4-ring or 2-ring conductivity/temperature probes complete with SICRAM module 23.
  • Page 5 HD2256.2 connectors: pH - Conductivity - Temperature 20. Power supply input 12Vdc for the ∅ 5.5mm - 2.1mm connector. Positive at centre. 21. RS232C serial port, sub D 9-pole male connector. 22. 8-pole DIN45326 connector, input for combined 4-ring or 2-ring conductivity/temperature probes complete with SICRAM module 23.

  • Page 6: Introduction

    They are fitted with a large backlit LCD display. The HD2205.2 is fitted with two BNC inputs for pH, mV, redox potential (ORP) measurement us- ing pH, redox electrodes or separate reference electrodes, and two inputs for pH/temperature probes complete with SICRAM module.

  • Page 7: Display Description

    ISPLAY ESCRIPTION HD2205.2 HD2206.2 HD2256.2 The above appears when you turn the instrument on. The display is backlit. The contrast level is adjusted using CONTRAST+ and CONTRAST-. The display has three lines described below: First line HD2205.2 It indicates, from left to right: 1.
  • Page 8 3. The temperature value used to compensate the pH measurements (for a detailed description, see the chapter dedicated to temperature on page 36). HD2206.2 It indicates, from left to right: 1. The conductivity, resistivity, TDS, NaCl concentration measured by the conductivity probe, with SICRAM module, connected to the input or by the direct probe, without SICRAM mod- ule, connected to the input...
  • Page 9 HD2256.2 It indicates, from left to right: 4. In models HD2205.2 and HD2256.2: The symbol indicates the quality of the pH electrode con- nected to the inputs , or the CAL blinking message if the probe connected to the pH input is not calibrated.
  • Page 10 In the following figure you can see an example of the measurement process with the EPT AUTO function enabled. After setting the EPT = AUTO function using the F4 key, the elec- trode is immersed into a liquid. To perform the measurement, press MEAS. the EPT symbol blinks to indicate that the measurement is in the stabilization phase.
  • Page 11 Bottom line The following is reported in the bottom line: 8. Identifier of the sample being measured: The automatically increased progressive number associated with the PRINT and MEM functions. The identifier is indicated in the printout and in the recorded samples together with the date, time and measured values. To set the number associated to the first sample, press ID, then use the arrows to se- lect the desired number: Confirm by pressing ENTER.
  • Page 12 HD2205.2 HD2206.2 HD2256.2 12. F1 - Models HD2205.2 and HD2256.2 - If you press it repeatedly, it changes the unit of meas- urement of the electrode connected to the BNC input or of the SICRAM pH probe con- nected to the input between pH, mV, or no indication.
  • Page 13 15. F5 = °C/°F: If the temperature sensor is present, the key changes the unit of measurement be- tween °C or °F. If no temperature or combined temperature probes are present, the key allows manual input of the temperature value used for compensation and of the unit of measurement (°C or °F).

  • Page 14: Keyboard Description

    EYBOARD DESCRIPTION Each key specific function is described in detail below. ON-OFF key The instrument is turned on and off using the ON/OFF key. Press this key for at least two sec- onds. The turning on starts a self test including the detection of the probes connected to the inputs. As the probes’...
  • Page 15 Function keys F1, …, F5 … The function of the F1, …, F5 keys is described by the message near each key in the bottom line of the display. A complete description of these keys is reported on page 12. SHIFT/FNC key The F1…F5 keys have two functions: the main and the secondary functions.
  • Page 16 It stores the displayed data. The data refer to the following measurements: pH, mV and temperature for the HD2205.2; conductivity, resistivity, total dissolved solids, NaCl and temperature for the HD2206.2, pH, mV, conductivity, resistivity, total dissolved solids, NaCl and temperature for the HD2256.2,...

  • Page 17: Menu Description

    ENU DESCRIPTION The SETUP key is used to access the menu main screen. To select one item, use the arrow keys ( Press ENTER to access the selected item. Use the arrows to browse the submenus and modify the single parameters. Press ENTER to confirm the value of the selected parameter, press ESC to cancel the operation: In both cases, you return to the initial menu.
  • Page 18 3. “SYSTEM PARAMETERS” 3.1. “ “Date and Time” This function manages the instrument date and time setting. Use the arrows to move the cursor, and the arrows to edit the selected value. The SETUP key clears the seconds to synchronize them to the minute: Use the arrows to set the current minute plus one, and as soon as that minute is reached press SETUP.
  • Page 19 ENTER. When pressing PRINT the data are sent to the Bluetooth printer. 4. “MEASUREMENT AND pH CALIBRATION OPTIONS” (for HD2205.2 and HD2256.2) 4.1. “pH Resolution”: Selects the number of leading digits for the pH measurement: using arrows select 7.12 to obtain the pH hundredths or 7.123 to obtain the...
  • Page 20 Note for the model HD2205.2: as the pH electrode non SICRAM calibration data are saved in the instrument's memory, it is important to connect the electrode in the same input used during calibration. The SICRAM pH probe calibration data are read directly in the probe's memory, so these probes do not need to be connected to the same input used for calibration.

  • Page 21: User Management

    ANAGEMENT The user must identify himself or herself by entering a user name and password: The registered user name is shown in all performed operations: printing, logging, calibration... The available users are: administrator, user_1, user_2, user_3 and anonymous user. The different users have different usage levels: The Administrator is enabled to use all of the instrument functions and assigns the password to the other users.

  • Page 22: Functions Reserved To The Administrator

    Functions reserved to the administrator Some functions are reserved to the user registered as "Administrator" (see the details on page 17). Only the Administrator can: • Modify the instrument identifier, • Perform the instrument partial and total reset, • Set the user exit mode (“User Exit Mode”), •...

  • Page 23: Ph Measurement

    SICRAM probe to a pH electrode: For example, you can move the module linked to the electrode from an input to another (for the HD2205.2) or from an instrument pH SICRAM input to a second instrument, without performing a new calibra- tion.

  • Page 24: Automatic Or Manual Ph Compensation

    The electrode for pH measurement The electrode for pH measurement, generally in glass, generates an electrical signal proportional to the pH according to Nernst law. Of this signal the following aspects are considered: Zero point: The pH where the electrode generates a potential of 0 mV. In most electrodes, this value is found at about 7 pH.

  • Page 25: Ph Electrode Calibration

    In absence of the temperature probe or sensor, the lower display shows the MTC (Manual Compen- sation Temperature). If the correct value is not entered manually, the extent of the error committed in pH measurement is proportional to temperature and measured liquid pH value itself. In MTC mode, in order to manually change the compensation temperature press F5=°C/°F once: The indicated temperature value starts blinking.
  • Page 26 The display shows on the left the current pH measurement value according to current calibra- tion. The buffer value compensated for temperature is displayed in the center. The detected and temperature compensated buffer value, shown in the center, can be modified using the arrows 6.

  • Page 27: Temperature Characteristics Of Delta Ohm Standard Solutions

    The 13 standard buffers reported in the table on page 25 are memorized in the instruments with relevant variations according to temperature: The characteristics of the three Delta Ohm standard buffers at 6.86pH, 4.01pH and 9.18pH (@25°C) are reported below.

  • Page 28: Conductivity Measurement

    Conductivity measurement The HD2206.2 and HD2256.2 work with direct conductivity/temperature probes (input ), direct 4-electrode and 2-electrode only conductivity probes (input ), or combined conductiv- ity/temperature probes with SICRAM (input ). The 4 wire Pt100, 2 wire Pt1000 sensors may be used for measuring temperature, which is used for the automatic compensation of the conductivity.
  • Page 29 The conductivity probes must be periodically calibrated. To facilitate this operation, four standard calibration solutions are automatically recognized by the instrument: • 0.001 Molar KCl solution (147μS/cm @25°C), • 0.01 Molar KCl solution (1413μS/cm @25°C), • 0.1 Molar KCl solution (12880μS/cm @25°C), •...

  • Page 30: Automatic Or Manual Temperature Compensation For Conductivity Measurement

    Choosing the cell constant The cell constant K is a piece of information which characterizes the cell. It depends on its geome- –1 try and is expressed in cm . There is no cell capable of measuring the entire conductivity scale ac- curately enough.

  • Page 31: Resistivity, Tds And Salinity Measurements

    Resistivity, TDS and salinity measurements The HD2206.2 and HD2256.2 measure electric conductivity and temperature of a solution, and cal- culates resistivity, salinity and TDS. By repeatedly pressing “F1 = cond.” (HD2206.2) and “F2 = cond.” (HD2256.2) you can select the measurement. The resistivity is defined as the reciprocal of conductivity.
  • Page 32 (point 5.3 on page 20). 3. Set the α temperature coefficient in the menu (point 5 on page 20): For Delta OHM calibration solutions, enter 2.00%/°C. 4. Set the reference temperature in the menu (20°C or 25°C) (point 5.1 on page 20): 5.

  • Page 33: Manual Calibration Of Conductivity Using Not-Memorized Standard Solutions

    13. To end the calibration and return to measurement, press F3 = EXIT (step 17), or continue the calibration for the next point. 14. Extract the probe from the calibration solution, wash it, clean it carefully, and insert it in the following solution.
  • Page 34 If the read value is sufficiently close to the theoretical one, the central column reports the actual value, at the measured temperature, of one of the four standard solutions: an arrow blinks near the detected standard solution, displayed in the list on the right. Continue the calibration from point 10 of the previous chapter “Automatic calibration of conductivity using memorized stan- dard solutions”.

  • Page 35: Table Of Standard Solutions At 147Μs/Cm, 1413Μs/Cm, 12880Μs/Cm And 111800Μs/Cm

    • If you get the “CAL ERROR” message during calibration, check that the input cell constant is correct. • The most frequent causes of error are due to the probe malfunctioning due to deposits, dirt or to the standard solutions deterioration (bad preservation conditions, alteration due to pollution with other solutions, …).

  • Page 36: Temperature Measurement

    EMPERATURE MEASUREMENT The instrument accepts Platinum temperature probes with resistances of 100Ω or 1000Ω at 0°C, with SICRAM module or direct sensor, in the dedicated input reserved to temperature probes. The Pt100 are connected to 4 wires, the Pt1000 to 2 wires. The instrument, according to the version, can also measure the temperature using the combined pH/temperature, conductivity/temperature probes.

  • Page 37: Instructions To Connect The Tp47 Connector For Pt100 Probes Or Pt1000

    Instructions to connect the TP47 connector for Pt100 probes or Pt1000 All Delta Ohm probes are provided with a connector. The HD2205.2, HD2206.2 and HD2256.2 in- struments also work with direct 4 wire Pt100, and 2 wire Pt1000 probes manufactured by other pro- ducers: For the instrument connection is prescribed the TP47 connector to which the probe's wires should be welded.

  • Page 38: Direct Connection Of The 4 Wire Pt100 Sensor To A Din45326 Connector

    Sensor Card connection Jumper to close Pt1000 Pt1000 2 wires 2 wires Ensure the welds are clean and perfect. Once the welding operation is complete, close the two shells, insert the gasket in the module, and screw the fairlead. At the other end of the module, enter the ring with the O-ring as indicated in the picture.

  • Page 39: Warnings And Operating Instructions On The Temperature Sensors

    ARNINGS AND OPERATING INSTRUCTIONS ON THE TEMPERATURE SENSORS 1. Do not expose the probes to gases or liquids that could corrode the material of the sensor or the probe itself. Clean the probe carefully after each measurement. 2. Do not bend the probe connectors or force them upward or downward. 3.

  • Page 40: Ph And Conductivity Measurements - Most Frequent Problems , Possible Causes And Handling

    AND CONDUCTIVITY MEASUREMENTS MOST FREQUENT PROBLEMS POSSIBLE CAUSES AND HANDLING Instrument functioning When selecting some functions the “Operation reserved to the administrator” message is displayed on the screen. Some functions are reserved to the user registered as "Administrator". The other users cannot exe- cute them (see the details on page 21).

  • Page 41: Conductivity Measurement

    Conductivity measurement The service life of a cell can be unlimited, provided that the necessary maintenance is performed and that it does not break. Some of the most frequent problems and their possible solutions are re- ported below. Measurement of conductivity different from the expected value. Check that the probe is connected to the correct input: input for a SICRAM type probe, input...

  • Page 42: Nstrument Ignals And Aults

    NSTRUMENT IGNALS AND AULTS The following table lists all error indications and information displayed by the instrument and sup- plied to the user in different operating situations: Display indication Explanation This message appears if the pH measurement exceeds the -2.000pH…19.999pH limits. And if the mV measurement exceeds the ERROR ±2.4V limits.

  • Page 43: Serial Interface And Usb

    Before sending commands to the instrument via the serial port, locking the keyboard to avoid func- tioning conflicts is recommended: use the P0 command. When complete, restore the keyboard with the P1 command. COMMAND ACTION RESPONSE NOTES HD2205.2 = two pH channels HD2256-2 Model request HD2206.2 = conductivity pH/chi/temperature HD2256.2 = pH+conductivity Firmware version Firmware 1.00.100...
  • Page 44 Same as manual print It increases the ID Calibration status pH1 Same as manual print Calibration status pH2 Same as manual print Only HD2205.2 Calibration history pH1 Same as manual print Calibration history pH2 Same as manual print Only HD2205.2...
  • Page 45 COMMAND ACTION RESPONSE NOTES Read cell constant Kcell Chi nominal Kcell = 0.700 Read parameter “Print and 0 = only print, Print&mem = 0 Storage Mode” 1 = print and record Read parameter “Storage 0 = standard Memory mode = 0 Mode”...

  • Page 46: Connection To Apc

    USB type B connector for connection to the instrument. The Bluetooth HD22BT module, directly installed by Delta Ohm, is also available. This module al- lows wireless connection of the instrument to a PC fitted with a Bluetooth HD USB.KL1, to a Blue- tooth S’Print-BT printer, or to a PC with built-in Bluetooth interface.
  • Page 47 Close DeltaLog11. Connect the instrument to the PC USB port. When Windows detects the new device, the "New software installation wizard" is started. If you are asked for the authorization to search an updated driver, answer NO and continue. In the installation window, select “Install from a list or specific location”. In the next window select “Search for the best driver in these locations”...

  • Page 48: Bluetooth Connection

    The instruments can be wireless connected to a PC or printer, via a Bluetooth connection that re- quires installation of the HD22BT module by Delta Ohm. For connection to a PC, if the PC is not fitted with a Bluetooth interface, you need to connect the USB/Bluetooth interface, code HD USB.KL1.

  • Page 49: Storing And Transferring Data To Apc

    RANSFERRING ATA TO A The HD2205.2, HD2206.2 and HD2256.2 instruments can be connected to a personal computer via an RS232C serial port or an USB port, and exchange data and information through the DeltaLog11 software running in a Windows operating environment (see the details on the previous chapter). All models can print the measured values on (S’print-BT) a 24 column printer (PRINT key) and store...

  • Page 50: Clearing The Memory

    F1 and F2 function keys. A printer with serial input can be connected to the RS232C port (e.g. the Delta Ohm 24 column printer code S’print-BT).
  • Page 51 Example of a printout obtained using the S'print-BT printer NOTES Instrument model HD2256.2 pH/chi/temperature Current date and time in the format 2006 – 01 - 31 12:00:00 year-month-day hours:minutes:seconds Instrument name LAB POSITION #1 Operator (Administrator or User_1, User_2, Operator = Administrator User_3 or Anonymous) Number of the sample SAMPLE ID = 00000001...

  • Page 52: Ackup Battery Replacement

    ACKUP BATTERY REPLACEMENT The instruments are fitted with a backup battery that maintains the configuration data in the mem- ory and ensures the functioning of the clock without power supply. The battery operates only when the instrument is not powered by the mains. The low power con- sumption ensures a long life of the battery.

  • Page 53: Functioning Notes And Operating Security

    UNCTIONING OTES AND PERATING ECURITY Authorized use The instrument has been designed exclusively for laboratory measurements. Comply with the technical specifications outlined in the chapter TECHNICAL DATA on page 56. Its use is authorized only in conformity with the instructions written in this manual. Any different use is considered improper.

  • Page 54: Hd22.2 Laboratory Electrode Holder With In Built Magnetic Stirrer

    HD22.2 L ABORATORY ELECTRODE HOLDER WITH IN BUILT MAGNETIC STIRRER HD22.3 L ABORATORY ELECTRODE HOLDER HD22.2 The HD22.2 is a laboratory electrode holder with an ultra slim magnetic stirrer. The height adjust- able electrode holder supports two standard ∅ 12 mm electrodes. The stirring is performed by a small magnetic bar immersed in the liquid: The motion is generated by a rotary magnetic field controlled by microprocessor.
  • Page 55 Technical Information HD22.2 HD22.3 Power 12Vdc, 200mA Stirring speed 15…1500 rpm Stirring capacity Max. 1000 ml Stirring magnetic bar L = 30…40 mm Material Body ABS; staff AISI 304 Body ABS; base Fe 360 Weight 1150g 1900g Bearing surface ∅ 100 mm Dimensions Base: 215x145x25 mm Height max.

  • Page 56: Common Technical Characteristics Of The Hd22

    HD22… OMMON TECHNICAL CHARACTERISTICS OF THE SERIES Instrument Dimensions (Length x Width x Height) 265x190x75mm Weight 1300 g Materials ABS, rubber Display Backlit, Dot Matrix. 240x64 points, visible area: 128x35mm Operating conditions Operating temperature -5…50°C Warehouse temperature -25…65°C Working relative humidity 0…90% RH without condensation Protection degree IP66...
  • Page 57 Bluetooth interface Optional, for PC fitted with Bluetooth in- put or Bluetooth/RS232 HD USB.KL1 adaptor. The interface can be installed only by Delta Ohm EMC Standard Regulations Safety EN61000-4-2, EN61010-1 level 3 Electrostatic discharges EN61000-4-2 level 3 Fast electric transients...

  • Page 58: Hd2205.2 Technical Characteristics Measurement

    HD2205.2 T ECHNICAL HARACTERISTICS pH - mV - °C - °F MEASUREMENT Measured quantities pH - mV °C - °F; Connections Input for the temperature probes with SICRAM module 8-pole male DIN45326 connector pH/mV inputs Female BNC ∅ 4mm standard plug...
  • Page 59 • Measurement of temperature by Instrument Pt100 measurement range -50…+150°C Pt1000 measurement range -50…+150°C Resolution 0.1°C ±0.1°C ±1digit Accuracy Drift after 1 year 0.1°C/year...

  • Page 60: Hd2206.2 Technical Characteristics Χ - Ω - Tds - Nacl - °C -°Fmeasurement

    HD2206.2 T ECHNICAL HARACTERISTICS χ - Ω - TDS - NaCl - °C -°F MEASUREMENT χ - Ω - TDS - NaCl Measured quantities °C - °F; Connections Input for the temperature probes with SICRAM module 8-pole male DIN45326 connector 4-ring/2-ring conductivity direct input 8-pole male DIN45326 connector SICRAM probes conductivity input...
  • Page 61 Measurement of resistivity by Instrument Measurement range (Kcell=0.01) / Resolution Up to 1GΩ⋅cm / ( )Measurement range (Kcell=0.1) / Resolution Up to 100MΩΩcm / (*)Measurement range (Kcell=1) / Resolution 5.0…199.9Ω⋅cm / 0.1Ω⋅cm 200…999Ω⋅cm / 1Ω⋅cm 1.00k…19.99kΩ⋅cm / 0.01kΩ⋅cm 20.0k…99.9kΩ⋅cm / 0.1kΩ⋅cm 100k…999kΩ⋅cm / 1kΩ⋅cm 1…10MΩ⋅cm / 1MΩ⋅cm Measurement range (Kcell=10) / Resolution...
  • Page 62 Standard solutions automatically detected (@25°C) 147μS/cm 1413μS/cm 12880μS/cm 111800μS/cm • Measurement of temperature by Instrument Pt100 measurement range -50…+150°C Pt1000 measurement range -50…+150°C Resolution 0.1°C ±0.1°C ±1digit Accuracy Drift after 1 year 0.1°C/year...

  • Page 63: Hd2256.2 Technical Characteristics Ph - Mv - Χ - Ω - Tds - Nacl - °C - °Fmeasurement

    HD2256.2 T ECHNICAL HARACTERISTICS pH – mV - χ - Ω - TDS - NaCl - °C - °F MEASUREMENT Measured quantities pH - mV χ - Ω - TDS - NaCl °C - °F; Connections Input for the temperature probes with SICRAM module 8-pole male DIN45326 connector pH/mV input...
  • Page 64 • Measurement of conductivity by Instrument Measurement range (Kcell=0.01) / Resolution 0.000…1.999μS/cm / 0.001μS/cm Measurement range (Kcell=0.1) / Resolution 0.00…19.99μS/cm / 0.01μS/cm Measurement range (Kcell=1) / Resolution 0.0…199.9μS/cm / 0.1μS/cm 200…1999μS/cm / 1μS/cm 2.00…19.99mS/cm / 0.01mS/cm 20.0…199.9mS/cm / 0.1mS/cm Measurement range (Kcell=10) / Resolution 200…1999mS/cm / 1mS/cm ±0.5% ±1digit Accuracy (conductivity)
  • Page 65 Measurement of salinity Measurement range / Resolution 0.000…1.999g/l / 1mg/l 2.00…19.99g/l / 10mg/l 20.0…199.9 g/l / 0.1 g/l ±0.5% ±1digit Accuracy (salinity) 0...100°C with α Automatic/manual temperature compensation = 0.00…4.00%/°C Reference temperature 0…50°C (default 20°C or 25°C) χ/ TDS conversion factor 0.4…0.8 Preset cell constant K (cm 0.01 - 0.1 - 0.5 - 0.7 - 1.0 - 10.0...

  • Page 66: Technical Data In Line Probes For The Instruments Of The Series Hd22

    TECHNICAL DATA IN LINE PROBES FOR THE INSTRUMENTS OF THE SERIES HD22… HD2205.2 HD2256.2 LECTRODES pH electrodes without SICRAM module ORDER CODE MEASUREMENT RANGE DIMENSIONS 0…14pH / 0…80°C / 3bar Body in glass - GEL 1 diaphragm in ceramic Waste water, drinking water,...
  • Page 67 ORDER CODE MEASUREMENT RANGE DIMENSIONS 0…14pH / 0…80°C / 3bar Body in glass - GEL 1 diaphragm in ceramic Colours, varnishes, drinking KP62 water, aqueous emulsions, fruit-juices, electroplating waters, stock waters, titration, waste water. 0…14pH / 0…80°C / 1bar Body in glass Liquid reference KCl 3M 1 diaphragm in ceramic Cable L=1m with BNC...

  • Page 68: Hd2205.2 And Hd2256.2 Redox Electrodes 1 2

    Please see the technical charac- KP47 teristics of the electrode con- nected to the module. HD2205.2 HD2256.2 R EDOX LECTRODES MEASUREMENT RANGE ORDER CODE DIMENSIONS AND USE ±2000mV 0…80°C...

  • Page 69: And 4 Electrode Conductivity Probes For Hd2206.2 And Hd2256.2

    HD2206.2 HD2256.2 ELECTRODE CONDUCTIVITY PROBES FOR Conductivity probes without SICRAM module MEASUREMENT RANGE ORDER CODE DIMENSIONS AND USE K=0.7 5μS/cm …200mS/cm 0…90°C 4-electrode cell SP06T in Platinum Ø 12 Ø 17 Pocan probe material General use Not heavy duty Pt100 sensor K=0.01 0.04μS/cm …20μS/cm 0…120°C...

  • Page 70: Temperature Probes

    Conductivity probes with SICRAM module ORDER CODE MEASUREMENT RANGE DIMENSIONS 10μS/cm …10mS/cm 0…80°C 2-electrode cell in Platinum wire SPT1GS Glass probe material General heavy duty use, me- dium conductivity Pt100 sensor EMPERATURE PROBES Temperature probes Pt100 using SICRAM module Model Type Application range Accuracy...

  • Page 71: Rder Codes The

    HD22… RDER CODES THE SERIES INSTRUMENTS HD2205.2 The kit is composed of: instrument HD2205.2, performs measurements of pH - redox - temperature, datalogger, stabilized power supply with Vin=100- 240Vac/12Vdc-1A (SWD10), operating manual, case and DeltaLog11 software. HD2206.2 The kit is composed of: instrument HD2206.2, performs measurements of conduc-...

  • Page 72: Ph Electrodes Without Sicram Module (Inputs 1 And 2)

    HD2205.2 HD2256.2 CCESSORIES FOR THE INSTRUMENTS WITH INPUT FOR P MEASUREMENT SICRAM ELECTRODES WITHOUT MODULE NPUTS KP20 Combined general use pH electrode, gel-filled, with screw connector S7, body in Epoxy. KP30 Combined general use pH electrode, gel-filled, 1m cable with BNC, body in Ep- oxy.
  • Page 73 NPUTS ELECTRODES KP90 REDOX PLATINUM electrode for general use, with screw connector S7, KCl 3M electrolyte, body in glass. KP91 REDOX PLATINUM electrode for general non heavy duty use, gel-filled, 1m ca- ble with BNC, body in Epoxy. STANDARD SOLUTIONS HD8642 Buffer solution 4.01pH - 200cc.

  • Page 74: Accessories For The Hd2206.2

    HD2206.2 HD2256.2 CCESSORIES FOR THE INSTRUMENTS WITH INPUT FOR CONDUCTIVITY MEASUREMENT ONDUCTIVITY AND COMBINED CONDUCTIVITY TEMPERATURE PROBES NPUT SICRAM WITHOUT MODULE SP06T Conductivity/temperature combined probe, 4-electrode cell in Platinum, body in Pocan. Cell constant K = 0.7. Measuring range 5μS/cm …200mS/cm, 0…90°C. SPT401.001 Conductivity/temperature combined probe, 2-electrode cell in AISI 316 steel.

  • Page 75: Ccessories For The

    HD22… CCESSORIES FOR THE SERIES INSTRUMENTS WITH INPUT FOR TEMPERATURE MEASUREMENT SICRAM NPUT EMPERATURE PROBES COMPLETE WITH MODULE TP87 Pt100 sensor immersion probe. Probe's stem Ø 3 mm, length 70mm. Cable length 1 metre. TP472I.0 Pt100 sensor immersion probe. Stem Ø 3 mm, length 230 mm. Cable length 2 me- tres.

  • Page 76: Table Of Contents

    Automatic or manual pH compensation........................24 pH electrode calibration ............................25 Calibration procedure.............................. 25 Temperature characteristics of Delta OHM standard solutions................27 Conductivity measurement ............................28 Automatic or manual temperature compensation for conductivity measurement ........... 30 Resistivity, TDS and salinity measurements ......................31 Calibration of conductivity............................
  • Page 77 TECHNICAL DATA IN LINE PROBES FOR THE INSTRUMENTS OF THE SERIES HD22…......66 HD2205.2 and HD2256.2 pH Electrodes 1 2......................66 HD2205.2 and HD2256.2 Redox Electrodes 1 2 ...................... 68 2 and 4 electrode conductivity probes for HD2206.2 and HD2256.2 ................69 Temperature probes ..............................
