Ford Performance M-9603-M8B Instruction

2018 – 20my mustang 5.0 gt cold air kit with cal. procal 4 tool
Hide thumbs

Advertisement

Quick Links

Download this manual
NO PART OF THIS DOCUMENT MAY BE REPRODUCED WITHOUT PRIOR AGREEMENT AND WRITTEN PERMISSION OF
PRIOR TO INSTALLATION READ THESE INSTRUCTION COMPETELY
For questions, Call the FORD PERFORMANCE Techline 1-800-367-3788
Please visit
Ford Factory Shop Manual purchase options
Techline 1-800-367-378
M-9603-M8B
2018 – 20MY Mustang 5.0 GT Cold Air Kit with Cal.
Instruction
FORD PERFORMANCE PARTS © Ford Motor Company 2020
https://www.performanceparts.ford.com
Kit contains:
1 – Ford Performance Cold Air Intake
1 – Ford Performance ProCal 4
1 – ProCal 4 Voucher
1 – 87 mm Throttle Body
4 – Throttle Body Bolts (Hex Head)
1 – Throttle Body Adaptor
4 – Throttle Body Adaptor Bolts (Socket Head)
1 – Throttle Body Adaptor Seal
1 – EO Label
1 – Foam Seal
1 – Air Inlet
1 – Sound Symposer Plug
1 – Premium Fuel Label
2 – Wiring Stud Retainers
Warning: Read ProCal voucher before starting installation!
for warranty information
www.motorcraftservice.com
Page 1 of 12
IS M-9603-M8B 032730

Advertisement

loading
Need help?

Need help?

Do you have a question about the M-9603-M8B and is the answer not in the manual?

Questions and answers

Related Manuals for Ford Performance M-9603-M8B

Summary of Contents for Ford Performance M-9603-M8B

  • Page 1 2018 – 20MY Mustang 5.0 GT Cold Air Kit with Cal. Instruction NO PART OF THIS DOCUMENT MAY BE REPRODUCED WITHOUT PRIOR AGREEMENT AND WRITTEN PERMISSION OF FORD PERFORMANCE PARTS © Ford Motor Company 2020 PRIOR TO INSTALLATION READ THESE INSTRUCTION COMPETELY For questions, Call the FORD PERFORMANCE Techline 1-800-367-3788 Please visit https://www.performanceparts.ford.com...
  • Page 2 2018 – 20MY Mustang 5.0 GT Cold Air Kit with Cal. Instruction NO PART OF THIS DOCUMENT MAY BE REPRODUCED WITHOUT PRIOR AGREEMENT AND WRITTEN PERMISSION OF FORD PERFORMANCE PARTS © Ford Motor Company 2020 NOTE: Removal steps in this procedure may contain installation details. Disconnect the battery ground cable.
  • Page 3 Instruction NO PART OF THIS DOCUMENT MAY BE REPRODUCED WITHOUT PRIOR AGREEMENT AND WRITTEN PERMISSION OF FORD PERFORMANCE PARTS © Ford Motor Company 2020 4. Detach and position the sound symposer from the air cleaner. 5. Remove the bolt and the air cleaner. Save fastener for installation 6.
  • Page 4 Instruction NO PART OF THIS DOCUMENT MAY BE REPRODUCED WITHOUT PRIOR AGREEMENT AND WRITTEN PERMISSION OF FORD PERFORMANCE PARTS © Ford Motor Company 2020 7. Remove the engine appearance cover caps. 8. NOTE: The engine appearance cover rubber grommets may remain on the cover. If so, remove the grommets from the cover and install them on the intake manifold before installing the cover.
  • Page 5 NO PART OF THIS DOCUMENT MAY BE REPRODUCED WITHOUT PRIOR AGREEMENT AND WRITTEN PERMISSION OF FORD PERFORMANCE PARTS © Ford Motor Company 2020 9. Disconnect and position aside the brake booster tube, crankcase ventilation tube and resonator air inlet tube.
  • Page 6 Instruction NO PART OF THIS DOCUMENT MAY BE REPRODUCED WITHOUT PRIOR AGREEMENT AND WRITTEN PERMISSION OF FORD PERFORMANCE PARTS © Ford Motor Company 2020 12. Remove the nut and position aside the sound symposer assembly. Torque: 62 lb.in (7 Nm) 13.
  • Page 7 Instruction NO PART OF THIS DOCUMENT MAY BE REPRODUCED WITHOUT PRIOR AGREEMENT AND WRITTEN PERMISSION OF FORD PERFORMANCE PARTS © Ford Motor Company 2020 16. Disconnect the throttle body electrical connector. 17. Remove the throttle body retaining bolts, then remove the throttle body.
  • Page 8 Instruction NO PART OF THIS DOCUMENT MAY BE REPRODUCED WITHOUT PRIOR AGREEMENT AND WRITTEN PERMISSION OF FORD PERFORMANCE PARTS © Ford Motor Company 2020 18. Inspect the throttle body gasket, clean and replace the throttle body gasket as needed. 19. Install throttle body adapter.
  • Page 9 NO PART OF THIS DOCUMENT MAY BE REPRODUCED WITHOUT PRIOR AGREEMENT AND WRITTEN PERMISSION OF FORD PERFORMANCE PARTS © Ford Motor Company 2020 22. Install the 87 mm throttle body, then install and tighten the throttle body retaining bolts in the following 2 stages.
  • Page 10 Instruction NO PART OF THIS DOCUMENT MAY BE REPRODUCED WITHOUT PRIOR AGREEMENT AND WRITTEN PERMISSION OF FORD PERFORMANCE PARTS © Ford Motor Company 2020 24. On the MAF wiring, remove the two wiring harness retainers 25. Wiring harness may need to be extended for new MAF location. Be careful not to damage wiring when doing so 26.
  • Page 11 NO PART OF THIS DOCUMENT MAY BE REPRODUCED WITHOUT PRIOR AGREEMENT AND WRITTEN PERMISSION OF FORD PERFORMANCE PARTS © Ford Motor Company 2020 27. Connect the dirty air inlet to the Ford Performance Cold Air Intake 28. Install the Ford Performance Cold Air Intake 29.
  • Page 12 2018 – 20MY Mustang 5.0 GT Cold Air Kit with Cal. Instruction NO PART OF THIS DOCUMENT MAY BE REPRODUCED WITHOUT PRIOR AGREEMENT AND WRITTEN PERMISSION OF FORD PERFORMANCE PARTS © Ford Motor Company 2020 34. Modify engine appearance cover to clear brake aspirator tube 35. Reinstall engine appearance cover 36.
  • Page 13 ***NOTE*** The ProCal 4 tool is shipped without a calibration; the end user must register with Ford Performance Parts (FPP) and download the ProCal 4 software and follow the instructions below. The software provided to install performance calibrations to the ProCal 4 tool is compatible only with Windows 7 or above and can be found at www.performanceparts.ford.com/downloads.
  • Page 14 4. After successful backup of stock calibration, the software will download the FPP performance calibration. a. Follow any on-screen prompts that may occur 5. Confirm software now shows Ford Performance calibration in addition to Stock file Installing performance calibration in vehicle ***NOTE*** ONCE CALIBRATION PROCESS HAS BEGUN, DO NOT PRESS ANY BUTTONS OR DISCONNECT TOOL UNTIL PROMPTED TO DO SO.
  • Page 15 M-12655-F PROCAL4 INSTRUCTIONS NO PART OF THIS DOCUMENT MAY BE REPRODUCED WITHOUT PRIOR AGREEMENT AND WRITTEN PERMISSION OF FORD PERFORMANCE PARTS © Ford Motor Company 2020 Diagnostic Features of ProCal 4Tool 1. Module Info a. Identified VIN, Vehicle description, calibration, and software installed in the PCM 2.
  • Page 16 M-12655-F PROCAL4 INSTRUCTIONS NO PART OF THIS DOCUMENT MAY BE REPRODUCED WITHOUT PRIOR AGREEMENT AND WRITTEN PERMISSION OF FORD PERFORMANCE PARTS © Ford Motor Company 2020 Datalogging 4. Gauges a. Allows user to monitor real-time data supported by the tool.
