IMMI Driver Knee Airbag Installation

Driver Knee Airbag
Installation

What is the driver knee airbag and how does it work?

The driver knee airbag is a part of the 4Front frontal collision protection system by IMMI -- the leading provider of advanced safety systems for fire
apparatus. During a frontal crash, the knee airbag is inflated. The inflated knee airbag provides a cushion for the driver's knees during a frontal
impact.

Important Facts

PLEASE READ THIS ENTIRE GUIDE BEFORE
INSTALLING THE DRIVER KNEE AIRBAG.
1. The driver knee airbag is to be used in a specific vehicle and
seating position. Check the part number on the module to ensure
correct application.
2. Always follow the vehicle manufacturer's installation guide. Use
this guide in addition to the vehicle manufacturer's guide.
WARNING
DISCONNECT THE BATTERY
With battery disconnect in the OFF position,
disconnect and isolate the battery negative cable before
beginning knee airbag installation. Allow system capacitor to
discharge for two minutes before beginning installation. Failure
to disconnect the battery could result in accidental airbag
deployment and could cause serious injury or death.
3. DO NOT PUNCTURE, DRILL OR APPLY HEAT to the driver knee
airbag. This may result in accidental knee airbag deployment
which could cause serious injury or death.
4. DO NOT MOUNT ANYTHING NEAR the driver knee airbag that
could interfere with the inflation of the airbag. Obstructions to the
airbag deployment could reduce the airbag's effectiveness.
5. The driver knee airbag is only designed to activate once. If the
driver knee airbag is activated or damaged, unit must be replaced
by authorized personnel.
WARNING
DO NOT APPLY HEAT
Temperatures over 150° C (257° F) could cause the unit to deploy. The
deploying knee airbag could cause serious injury or death.
Driver knee airbag location
Stowed
Deployed
1
