- Page 1 Table of contents Operating instructions CAN communication package BA-KommCAN_EN / F0353400 June 2016 BA-KommCAN_EN / F0353400...
- Page 2 Table of contents Thank you for purchasing a high-quality relyon plasma GmbH product. To get the best from your product, please read these instructions carefully. Important! Read these instructions carefully before assembling, installing and starting up the machine! Always follow the safety instructions! Failure to follow the safety instructions may result in accidents, serious injury and serious damage to the machine.
-
Page 3: Table Of Contents
Table of contents Safety ............................4 Residual risks ............................ 4 Information and obligations for the operator ..................4 Intended use ............................. 5 Impermissible operating conditions ....................5 System description ........................6 Function ............................6 System overview ..........................6 2.2.1 Description of the components ................... 6 2.2.2 Scope of delivery ........................ -
Page 4: Safety
Safety The system was designed in accordance with the relevant international standards. However, as with any technical product, hazards may arise if the system is not used properly or is used for purposes other than its intended use. Working with the system can be dangerous and may result in serious or fatal injury. It is therefore essential to protect yourself and others. -
Page 5: Intended Use
Intended use The system is intended solely for operation with the PS2000 high-voltage source and a plasma generator from relyon plasma GmbH. Coupled with a suitable plasma generator, the machine is intended solely for the plasma treatment of surfaces (metals, textiles, glass, plastics) to activate, clean, coat or remove residue at atmospheric pressure. -
Page 6: System Description
System description Function The components of this system are the basic elements for communicating with a PS2000 current source using the CAN bus with a higher level PLC. System overview 2.2.1 Description of the components No. Components CAN cable (length 2 m) CAN terminal resistor (Sub-D) CAN terminal resistor bushing (Sub-D) USB stick with EDS file... -
Page 7: Scope Of Delivery
2.2.2 Scope of delivery The scope of delivery includes the following components: • CAN cable (length 2 m) • CAN terminal resistor (Sub-D) • CAN terminal resistor bushing (Sub-D) • USB stick with EDS file • Operating instructions 2.2.3 Other hardware components needed Depending on the PLC used, additional hardware components are needed for a functioning overall system. -
Page 8: System Component Installation
System component installation To install the system, carry out the following steps in the order specified: 1. Connect the CAN terminal resistor (bushing) to the intended module of the higher level PLC (for more information, see Chapter 2.2.3 Other hardware components needed). 2. -
Page 9: Operation
Operation Start-up To operate the system, the following points must be met: The main switches of the connected PS2000 current source must be switched on. The emergency stop circuit must be connected correctly. The CAN bus cables must be connected, both ends must be terminated with terminal resistors and the correct CAN bus address on the rear side of the current source must be set. -
Page 10: Environment
Electrical and electronic equipment used must not be disposed of along with normal waste. The machine contains valuable materials that can be recycled. Take the machine to a suitable collection point. relyon plasma GmbH Weidener Strasse 16 93057 Regensburg Germany...
