Vertical - ADA Handle on the Bottom
Example shows Confi guration 1a. See other confi guration options under the handle rotation section.
Keypad
Shown in the locked position.
Cam Options
Offset Cam
Cylinder Length Options
16mm
11
RFID
Flat Cam
22mm
Cam Guide
ADA Handle
Cam-Stop
Flat Washer
Star Washer
Phillips Screw M5
Cam-Stop Options
Lifter Cam
30mm (Standard)
Flat Cam
(See below for other cam options)
90° Cam-Stop
180° Cam-Stop
38mm
standard
