Vertical - Knob on the Bottom
Example shows Confi guration 1a. See other confi guration options under the knob rotation section.
Keypad
Shown in the locked position.
Cam Options
Offset Cam
Cylinder Length Options
16mm
9
RFID
Flat Cam
22mm
Cam Guide
Standard Knob
Cam-Stop
Flat Washer
Star Washer
Phillips Screw M5
Cam-Stop Options
Lifter Cam
30mm (Standard)
Flat Cam
(See below for other cam options)
90° Cam-Stop
180° Cam-Stop
38mm
standard
