- Page 1 Operation anual Power istributor P -6359 * Rack mount products in the Western Hemisphere(North merica, South merica, and the Caribbean) do not have handles installed due to customer preference.
- Page 2 Welcome personal welcome to you from the management and employees of Inter-M ll of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value, and we are delighted you have purchased one of our products.
-
Page 3: Table Of Contents
Important Safety Instructions......................2 Features ............................3 Caution when ssembling Racks ....................3 Equipment Setting and Checking ....................4 Front Panel ............................6 Rear Panel ............................7 pplications ..........................10 Block Diagram ..........................11 Specifications ..........................12 Service Procedures............................13 Schematic .............................13 Parts List ............................13 Variations and Options .......................13 Warranty ............................13 PD-6359... -
Page 4: Unpacking
POWER DISTRIBUTOR Unpacking Unpacking lthough your PD-6359 is neither complicated nor difficult to operate, we recommend you take a few minutes to read this brief manual and familiarize yourself with the important information regarding product features, setup and operation. s with most electronic devices, we strongly recommend you to retain the original packaging. In the unlikely event the product must be returned for servicing, the original packaging (or reasonable equivalent) is required. -
Page 5: Features
- Connect C and DC powers based on the power of the device to be connected. - When supplying the rack power, interlock C OUTLET(Switched: 3 Group/Unswitched: 1 Group) and DC power output (DC 24V, 5 ) should be less than rated outputs. PD-6359... -
Page 6: Equipment Setting And Checking
2) Set the termination switch to LO D only for the first and last-numbered equipment units. ll others must be set to OPEN. Equipment 1 Equipment 2 Equipment 3 Equipment N S/W: LoaD S/W: oPEn S/W: oPEn S/W: LoaD ※ Caution: Communication error may occur if setting is performed incorrectly. PD-6359... - Page 7 2) Remove the C power cord, then check the operation status with battery power in case of black out. ※ To prepare the black out, the battery and battery charger (PB-6207) is required 3) Check on/off controls through remote terminal and monitoring status for communication. PD-6359...
-
Page 8: Front Panel
6. POWER LED It will be on when power switch is pushed and device is operated remotely. 7. POWER SWITCH It is the switch which controls C/DC power output of rear panel, and the power is supplied when it is ON. PD-6359... -
Page 9: Rear Panel
2 seconds interval, and if power is off, it will be off in reverse orders. C OUTLET (UNSWITCHED) It is the terminal which C power is supplied all the times, and it connects the devices which power should not be off. PD-6359... - Page 10 It is the terminal which supplies the power to the device operated by DC 24V. 9. C POWER CORD 10. REMOTE TERMIN L This is the input terminal for remote-controller When the contact signal sent to this terminal (HOT, COM) ,it operates automatically. But only works when the power switch is off. PD-6359...
- Page 11 Caution to polarities when it connects. 13. DC POWER OUTPUT TERMIN L (FOR R CK) It is the terminal supplying DC power to the rack system as rated 24V power output. It can be controlled with front power switch ON/OFF or remotely. PD-6359...
-
Page 12: Pplications
POWER DISTRIBUTOR pplications pplications PD-6359... -
Page 13: Block Diagram
POWER DISTRIBUTOR Block Diagram Block Diagram PD-6359... -
Page 14: Specifications
POWER DISTRIBUTOR Specifications Specifications PD-6359 C Outlet Europe,Saudi rabia SWITCHED : 2000W x 3, UNSWITCHED : 700W x 1 U.S. SWITCHED : 1000W x 3, UNSWITCHED : 350W x 1 Remote Control DC Power Output DC 24V, 3.5 Operation Temperature -10°C ~ +40°C... -
Page 15: Service
To obtain specific warranty information and available service locations contact Inter-M directly or the authorized Inter-M Distributor for your specific country or region. - Page 16 Inter-M, Ltd. (Korea) began operations in 1983. Since then, Inter-M has grown to become one of the largest manufacturers of professional audio and commercial sound electronics equipment in the world. Inter-M has gained worldwide recognition for its own branded products, as well as private label manufacturing of electronics sold under other names (OEM).
