FURNA HEMINGWAY FNAE2FRMGRY1 Assembley Manual

Electric standing desk

Advertisement

Quick Links

HE MIN GWAY ELE CT RIC
STA NDING D ES K
A B ET T ER D ES K F OR A BETT ER YOU
A SS EM BL EY GUI DE
MODEL - F N AE 2F RM GRY1

Advertisement

loading
Need help?

Need help?

Do you have a question about the HEMINGWAY FNAE2FRMGRY1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for FURNA HEMINGWAY FNAE2FRMGRY1

  • Page 1 HE MIN GWAY ELE CT RIC STA NDING D ES K A B ET T ER D ES K F OR A BETT ER YOU A SS EM BL EY GUI DE MODEL - F N AE 2F RM GRY1...
  • Page 2 Thank you for purchasing our electric adjustable height desk. Please take time to identify all the parts and hardware prior to assembly. Place all components on a padded/carpeted area to avoid damage. For safety, we recommend two people for assembly.
  • Page 3: Parts List

    Parts List Part 3 Part 1 Part 2 2 x Connecting Rods 2 x Lifting 2 x Retractable May be sitting inside Part 2 Columns Bracket Part 4 Part 5 Part 6 2 x Arms 2 x Desk Feet 1 x Pair Cross Beams Part 7 Part 8 Part 9...
  • Page 4 If not already inserted into Parts 2, insert Parts 3 (2 x Connecting Rods) into the slots in Part 2 to connect both sides of the desk frame. The Connecting Rods may or may not have cutout parts as shown in the picture, and if so they should be facing inwards towards the frame.
  • Page 5 Use 4 x Parts A, F and G to attach each desk top mounting bracket (Part 4) as shown in the picture. Once this is done, tighten all bolts in the frame. Parts used: 4,A,F,G Use 4 x Parts A, F and G to attach each foot (Part 5) to the legs.
  • Page 6 If you purchased a FURNA frame with 6 x pre-drilled holes you can now fix the desk top to the frame using 6 x Part A bolts, or otherwise drill in 6 x (M5 x 20mm) wood tapping screws which would be supplied separately.
  • Page 7 Connect the wires as per the diagram. The exact plug positions around the control box (Part 7) may vary slightly though only the correct cables fit in each spot.) Note: Do not plug in the power cable to a power source at this stage.
  • Page 8 Lift the unit to an upright position and plug in to a power source. The LED Control Panel will turn on automatically. If there is no height and just an error message shown, this is because the legs need to calibrate their height to exactly the same level.
  • Page 9 Safety In the event of a power outage or if the power cord is unplugged, a manual reset may be necessary. This product is designed with a duty cycle of 10% (2min, on, 18min, off) Keep children away from electric height adjustable desks, control units and handsets, There is a risk of injury and electric shock.
  • Page 10: Need Help

    Need help? Get in touch my emailing contact@furna.co.uk or by using our Live Chat feature on our website!
