Enable MicroSD Card in 1-wire Mode
1. AUX Input detection may be enabled by toggling the DIP SW 7 ON
In this mode:
• JTAG functionality is not available
• Vol- touch button is available for use with the API
Enable MicroSD Card in 4-wire Mode
In this mode:
• JTAG functionality is not available
• Vol- touch button is not available for use with the API
• AUX Input detection from the API is not available
Enable JTAG
1.10. Related Documents
Read the Docs Template Documentation, Release
DIP SW Position
1 OFF
2 OFF
3 OFF
4 OFF
5 OFF
6 OFF
1
7 OFF
8 n/a
DIP SW Position
1 ON
2 ON
3 OFF
4 OFF
5 OFF
6 OFF
7 OFF
8 n/a
DIP SW Position
1 OFF
2 OFF
3 ON
4 ON
5 ON
6 ON
7 ON
8 n/a
