EMOJO PROWLER Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PROWLER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for EMOJO PROWLER

  • Page 1 OWNER’S MANUAL...
  • Page 2 PAS Control 9- 1 2 Front wheel installation and seat adjustment Contact us...
  • Page 3 Instructions 1. Please read the manual carefully before using the electric bicycle. 2. Make sure all parts are locked tightly, such as the frame joint, driver hand pipe, seat post and pedal, etc. before using. Do not use electric bicycle before carefully reading the instructions and knowing about the performance of the electric bicycle. Do not lend the electric bicycle to anyone who does not know how to operate it.
  • Page 5 Overall Bike Layout Handlebar adjustment clamp Handlebar connectors Seat pole Seat pole quick release lever Stem Front shocks Battery Mid-Drive Electric motor Pedals Gears cassette Derrailleur Actual product may slightly differ from this picture...
  • Page 6 Diagram of the Electric Bicycle:...

  • Page 7: Main Technical Parameters

    Main Technical Parameters Item Index Total Weight lbs. <66 Load weight (including the Weight of Cyclist) lbs. ::;250 Travel Mileage on a single Charge Miles w/pedal assist Winter::::20 Summer::::30 Power Consumption on a single Charge (kilowatt) <0.8 Power Consumption per Kilometer (kilowatt) <1.5 Type Lithium Ion Battery...

  • Page 8: Hand Throttle Control

    Hand Throttle Control Your EMOJO electric bike is equipped with a power and throttle control on the left hand side. To power on your bike first make sure the switch to your battery is in the ON position. You control the throttle by pushing with your thumb the paddle, the farther you push from its resting position, the more power is delivered to the motor to accelerate.
  • Page 9 Gears This EMOJO e-bike model is equipped with 9 speeds. The first gear is for easier and uphill pedaling, and the last gear is for maximum speed on level or downhill terrain. Change gears only while pedaling. The rear wheel contains seven chain sprockets. When the chain is around the largest sprocket, you are in 1st gear, or the lowest gear.
  • Page 10 Correct Operation Stages ! Warning: For your safety, please practice in open tracts the first time you ride. After mastering the controls of an electric bicycle, you may ride on regular roads and follow the traffic rules consciously. Do not let inexperienced people ride the electric bicycle, do not disassemble and refit the electric bicycle, please pay attention and brake in advance to allow longer braking distance in rainy or snowy weather.
  • Page 11 Pedal Assist Mode Control Controls Your model EMOJO PROWLER is equipped with an handlebar 1-Power On/Off control module to turn on and set the PAS (Pedal Assist).Before you turn the control on, make sure the battery is fully inserted into Press the Power button to power on the display.

  • Page 12: Lcd Display Controls

    LCD DISPLAY CONTROLS • Switch between distance and speed modes Press the " i" button to switch between distance and speed. Please read the following steps and images to help you understand how Single-trip distance (TRIP km) , total distance (TOTAL km) to read and operate all the functions.

  • Page 13: Parameter Settings

    PARAMETER SETTINGS Pedal Assist Mode LCD Screen • Items to be Set 〉Data reset 〉Km/mile 〉Light sensitivity 1-Battery level 〉Display backlight brightness 2-Maintenance warning 〉Automatic off time 3-Headlight indicator 〉Maintenance warning settings 4-Distance mode 〉Check wheel diameter 5-Assistance 〉Speed Limit Setting 6-Malfunction indication 7-Menu 〉Speed model...
  • Page 14 Error code Error definition Error-shooting method Check if throttle is stuck or has returned “04” The throttle has not returned “05” Throttle fault Check the throttle “07” Overvoltage protection Check the battery voltage “08” Motor hall signal cable fault Check the motor module “09”...
  • Page 15 Charging Methods and Steps 1. Always charge the battery fully for the first time. When the battery level is low plug it to charge it, use only the original charger provided with the battery. Slide open the protective hatch to access the charging port 2.
  • Page 16 Attention: I. Make sure the charger is the original charger. 2. All charging plugs must be inserted tightly. 3. The average charging time of the whole battery pack is 6-8 hours, pl ease operate in strict accordance with above instructions and keep charger away from children.
  • Page 17 Read the instructions carefully to identify and understand the components of the electric bicycle such as pedal, seat post etc. and the name of relevant spare parts. When specialized servicing of bike is required, please go to an authorized EMOJO repair shop or store or another trusted bike professional.

  • Page 18: Disc Brakes

    WARNING: • Disc brake rotors become hot during use. Do not touch Your EMOJO e-bike is equipped with disc brakes for maximum or come in contact with the disc rotor shortly after use. reliability. Applying hand pressure to the brake levers will engage the •...
  • Page 19 4. Pedal Installation and Adjustment: Take out pedals from the accessory box, install one of the pedals (pedals are marked with the letters "L" and "R" to indicate the side they belong to). When installing the pedals, insert the wrench stuck on the flat end of pedal axial head, and twist into the crank in clockwise direction. 5.

  • Page 20: Common Faults And Maintenance

    7. Adjustment of Power Assisting Hall Sensor A: Turn the bike upside down, have it rest on the floor. I: The distance between the sensor and the disk shall be 3-5 millimeters :: Installing the sensor on the side of chain ring, when forwarding the chain ring, the power assistance is effective.
  • Page 21 Check the charger and power. Check whether the battery connection is in good condition and is stable. Check whether the charger plugs board fails. Check for any blown fuses in the battery case or any Battery Not Charging disconnected wiring. Note: if you experience problems contact your retailer, dealer or the manufacturer.
  • Page 22 Power Shut Off Troubleshooting If your EMOJO Prowler experiences a sudden power shut off while in use, this can be related to several reasons but the problem could have an easy fix. Fig. 2 1-Open the motor box by removing the left side cover, gently pull...
  • Page 23 The range with throttle only lasts about 20 miles (35 km) headwinds on my EMOJO electric bike? A. Yes. One of the main advantages of cycling on an EMOJO electric bicycle is that it How do I know when the battery is low? literally flattens hills and increases your average speed when tackling inclines and A.
  • Page 24 At EMOJO we are commited to the consumers and the experience first, put a smile on the face of each of EMOJO rider and revive childhood memories when riding a bike meant freedom regardless of your age or gender, life doesn’t stop and neither should you, that’s why we say: “RIDE LIFE”...
