INSTALLATION GUIDE
SCXI -MS100 T
™
M
EASUREMENT
Introduction
What You Need to Get Started
™
LabVIEW
, National Instruments
company names are trademarks or trade names of their respective companies.
371211A-01
© Copyright 1996, 2000 National Instruments Corp. All rights reserved.
EMPERATURE
S
YSTEM
This guide describes how to install, configure, and use the SCXI-MS100
temperature measurement system.
The SCXI-MS100 is a complete virtual-instrument-based temperature and
voltage measurement system for Windows 2000/NT/98/95. The system
includes the software and hardware needed to acquire and log up to
32 channels of data without any programming. You can configure each
channel for thermocouple or voltage input, and add additional SCXI
modules to expand the number of channels to 128.
The SCXI-MS100 is ideal for multichannel temperature applications in
many environments, such as process monitoring, industrial automation, and
instrumentation. The SCXI-MS100 combines SCXI and data acquisition
(DAQ) products to take accurate temperature measurements with
thermocouples. Taking measurements with thermocouples requires
amplification, cold-junction compensation (CJC), and high-resolution
analog-to-digital converters (ADCs). In addition, the included
VirtualBench-Logger software is an interface you use to display and
log data.
To set up and use your SCXI-MS100 temperature measurement system,
you need the following:
DAQ Quick Start Guide
SCXI Quick Start Guide
AT-MIO-16XE-50 or PCI-6035E data acquisition (DAQ) device
™
™
™
™
, ni.com
, NI-VISA
, SCXI
, and VirtualBench
™
are trademarks of National Instruments Corporation. Product and
January 2000
Advertisement
Related Manuals for NI SCXI-MS100
Summary of Contents for NI SCXI-MS100
- Page 1 SCXI -MS100 T ™ EMPERATURE EASUREMENT YSTEM This guide describes how to install, configure, and use the SCXI-MS100 temperature measurement system. Introduction The SCXI-MS100 is a complete virtual-instrument-based temperature and voltage measurement system for Windows 2000/NT/98/95. The system includes the software and hardware needed to acquire and log up to 32 channels of data without any programming.
- Page 2 Install your software before you install your hardware. Install the DAQ Device To install the NI-DAQ driver software and the plug-in DAQ device, carefully follow the steps in the DAQ Quick Start Guide until the step that explains how to confirm that your DAQ device is operating properly. You do not need to go further since you will use VirtualBench-Logger to test your system.
- Page 3 Back View Front View 1 Strain-Relief Bar 3 Earth Ground 4 Mating Connector 6 Top Cover Screws 2 Strain-Relief Screws Solder Lug 5 Thumbscrew 7 Top Cover Figure 1. SCXI-1303 Parts Locator Diagram © National Instruments Corporation SCXI-MS100 Temperature Measurement System...
- Page 4 3 Srain-Relief Screws Terminal Thermocouple 4 J-Type Thermocouple Terminal Figure 2. Thermocouple Connected to Channel 0 of the SCXI-1303 Terminal Block You are ready to connect the SCXI-1303 terminal block to the SCXI-1102 module front connector. SCXI-MS100 Temperature Measurement System www.ni.com...
- Page 5 Figure 3. Connecting the SCXI-1303 Terminal Block to the SCXI-1102 Module Note Place the SCXI chassis away from any extreme temperature differential to minimize the temperature gradient inside the terminal block and maintain its isothermal nature for accurate cold-junction compensation. © National Instruments Corporation SCXI-MS100 Temperature Measurement System...
-
Page 6: Configure The System
Assembly 7 Personal Computer Figure 4. Complete Installation Configure the System To complete the configuration of your SCXI-MS100 system using Measurement & Automation Explorer, perform the following steps: Double-click the Measurement & Automation Explorer icon on your desktop. Click the + next to the Devices and Interfaces icon to display the list of installed devices and interfaces. - Page 7 If the default settings are incorrect or incomplete, change them as needed as shown in Figure 5 and 6. Figure 5. SCXI Module General Tab Figure 6. SCXI Module Channel Tab © National Instruments Corporation SCXI-MS100 Temperature Measurement System...
- Page 8 Click the Accessory tab shown in Figure 7. Set the Accessory option to SCXI-1303 and click OK. Figure 7. SCXI Module Accessory Tab You can exit Measurement & Automation Explorer before using VirtualBench-Logger. SCXI-MS100 Temperature Measurement System www.ni.com...
- Page 9 From Windows, run the VirtualBench-Logger software, located under Start»Programs»National Instruments VirtualBench» VirtualBench-Logger. Figure 8 shows the main run-time window for the VirtualBench-Logger. Figure 8. VirtualBench-Logger Main Run-Time Window To configure the settings in the VirtualBench-Logger, select Edit»Settings. © National Instruments Corporation SCXI-MS100 Temperature Measurement System...
- Page 10 Set the Transducer type to Thermocouple. Set the Max input range to 1.000E+2. Set the Min input range to 0.000E+0. Set the Temp Units type to deg C. Set the TC Type to J. Click the Configure CJC button. SCXI-MS100 Temperature Measurement System www.ni.com...
- Page 11 Expand for More Channels Up to this point, this installation guide has explained how to use only one channel. To connect and measure more thermocouple or voltage signals, read the following sections. © National Instruments Corporation SCXI-MS100 Temperature Measurement System...
- Page 12 More Than 32 Channels You can expand the SCXI-MS100 system beyond 32 channels by adding up to three SCXI-MS100 32-channel expansion kits. Each kit includes one SCXI-1102 module and one SCXI-1303 terminal block.
