  • Page 1 Assembly & Installation Instructions Spectur Assembly & Installation Instructions P01-1112-GD-2...
  • Page 2: Table Of Contents

    1 Introduction ..........................3 2 System contents .......................... 3 3 Setup Instuctions ......................... 4 3.1 Recommended tools ......................4 3.2 Assembling your Spectur system ..................4 3.2.1 Solar Panel Assembly ....................5 3.2.2 Solar Panel Assembly ....................9 3.2.3 HD5 Assembly......................11 3.3 Testing ..........................
  • Page 3: Introduction

    1 Introduction The purpose of this document is to present instructions for a user to set up the Spectur HD5 security camera system. This document encompasses product assembly, testing and installation. For further advice or information, please contact your nominated Spectur representative, or call directly on 1300 802 960.
  • Page 4: Setup Instuctions

    3 Setup Instuctions 3.1 Recommended tools Please have the following tools handy to complete assembly and installation. NOTE: tools are NOT included with your Spectur system. Utility knife   Spanners (metric) – 10mm, 13mm, 17mm 3.2 Assembling your Spectur system Unpack contents of each box.
  • Page 5: Solar Panel Assembly

    3.2.1 Solar Panel Assembly Set aside the following parts needed for assembling the Solar Panel and bracketing. iii. Unpack the fastener pack and check contents as follows: Spectur Assembly & Installation Instructions Page 5 of 23...
  • Page 6 Lay the solar panel on a flat, clean surface as shown below. NOTE: Take care to ensure solar panel glass is protected during assembly. Do not fasten any bolts for now. Spectur Assembly & Installation Instructions Page 6 of 23...
  • Page 7 Secure the solar panel bracket assembly to the solar panel as indicated below. NOTE: the larger M6 washer is installed on the outside of the panel and the smaller M6 washer installed on the inner side of the panel with an M6 nut. Spectur Assembly & Installation Instructions Page 7 of 23...
  • Page 8 Ensure process is repeated for both sides. NOTE: after assembly the panel and bracket will appear symmetrical. To complete panel and bracket assembly, tighten all M6 nuts and bolts. IMPORTANT NOTICE: Failure to properly tighten nuts and bolts as instructed may cause serious injury. Spectur Assembly & Installation Instructions Page 8 of 23...
  • Page 9: Solar Panel Assembly

    Set aside the following parts needed for assembling the enclosure. Remove the 50W LED flood light from its packaging and prepare as shown below. The LED light will secure to the enclosure using the pre-installed M6 fasteners indicated below. Spectur Assembly & Installation Instructions Page 9 of 23...
  • Page 10 Connect LED light cable as shown below. NOTE: connector and socket has a 1-way fit; very little force is required to ensure proper connection. Secure LED light to bottom of enclosure as shown below. Ensure M6 nuts are firmly secured. Spectur Assembly & Installation Instructions Page 10 of 23...
  • Page 11: Hd5 Assembly

    3.2.3 HD5 Assembly xiii. Open the HD5 enclosure using the keys provided. Inside you will find 2x LTE High Gain antennas, remove packaging ahead of installation. xiv. Install antennas by gently screwing to external ports located on the right side of the enclosure as shown below.
  • Page 12 Remove and dispose of the protective plastic film covering the Perspex viewing window. xvi. If your system has a pre-installed SIM or Spectur SIM, please skip to section 3.3. If you plan to use your own SIM card, please locate the SIM tool and proceed with the SIM installation steps below.
  • Page 13 NOTE: Be careful not apply excessive force or the SIM tray may be damaged. xviii. Remove the SIM card tray as shown below. Spectur Assembly & Installation Instructions Page 13 of 23...
  • Page 14 Insert a full size SIM card into the SIM tray, aligning the SIM as shown. Spectur Assembly & Installation Instructions Page 14 of 23...
  • Page 15 Incorrect insertion can damage these components which will not be covered by warranty. If you are unsure or require additional guidance, please contact your nominated Spectur representative or call 1300 802 960 for further assistance. Spectur Assembly & Installation Instructions...
  • Page 16: Testing

    Before doing so, we recommend activating your system to ensure proper operation prior to installation. To activate your Spectur system, simply connect the battery as shown below. Please allow up to 10 minutes while the camera boots up and establishes a connection to the Spectur cloud server.
  • Page 17: System Login

    ‘Login’ as indicated below. ii. Once on the login screen, enter the Username and Password provided to you by Spectur. If you have not received these or are unsure, please contact your nominated Spectur representative, or call 1300 802 960 for assistance.
  • Page 18 Finally, log out by using the ‘Log Out’ button found in the top right of screen. You are now ready to install your system on-site. Spectur Assembly & Installation Instructions Page 18 of 23...
  • Page 19: Installation

    3.4 Installation Once assembly and testing is complete, you can install your Spectur system. IMPORTANT NOTICE: Ensure that the pole or supporting infrastructure that will be used for mounting the Spectur camera is fit for purpose. During installation it is the customers responsibility to comply with all relevant OH&S regulations.
  • Page 20 Remove the 2x M8 bolts and washer from the top of the box. Then remove the M24 locking nut and washer from the solar cable assembly in the middle of the box as indicated below. Spectur Assembly & Installation Instructions Page 20 of 23...
  • Page 21 Feed the solar cable through the hole, then feed the cable through the M24 locking nut. Place the solar panel assembly onto the threaded gland and re-attach the M24 washer, M24 nut and the 2x M8 bolts & washers to lock into place. Spectur Assembly & Installation Instructions Page 21 of 23...
  • Page 22 The picture below shows a suggested mounting method onto a steel pole using the self-tapping screws provided. Note – Failure to attach the unit securely could cause fatal injuries. Spectur Assembly & Installation Instructions Page 22 of 23...
  • Page 23 Your system is now fully installed and should automatically begin its start-up process. Please wait for 10 minutes for the system to connect to the Spectur server, then log in and check the live view and positioning of the camera. If required, move the camera module left, right, up or down inside the enclosure to adjust the field of view.
