Spectur HD5 Installation Manual

Hide thumbs Also See for HD5:
Table of Contents

Advertisement

Quick Links

Download this manual
HD5 Installation
Guide
1300 802 960 | www.spectur.com.au

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD5 and is the answer not in the manual?

Questions and answers

Related Manuals for Spectur HD5

Summary of Contents for Spectur HD5

  • Page 1 HD5 Installation Guide 1300 802 960 | www.spectur.com.au...

  • Page 2: Table Of Contents

    Step 2: ............................. 6 Installing the Antennas ........................7 Step 1: ............................. 7 Step 2: ............................. 7 Installing a SIM card in the Spectur Modem ................8 Step 1: ............................. 8 Step 2: ............................. 9 Assembling the solar panel ......................9 What you need ..........................
  • Page 3 Spectur Guide for HD5 Installation Step 5: ............................16 Step 6: ............................16 Step 7: ............................17 Step 8: ............................17 Step 9: ............................17 Step 10: ............................. 18 Step 11: ............................. 18 Step 12: ............................. 19 Step 13: ............................ 19 Step 14: ............................

  • Page 4: A Message From The Ceo: Gerard Dyson

    A Message From the CEO: Gerard Dyson Hi, I am Gerard Dyson, the CEO of Specur Ltd. Congratulations on your purchase of one of our Spectur Systems. Please read the installation manual fully prior to conducting an installation. We strongly recommend the use of PPE throughout the installation and a site-specific job hazard assessment.

  • Page 5: Camera Box Setup

    Spectur Guide for HD5 Installation Camera box setup What you need ○ Solar panel ○ Main camera box ○ Pole mounting bracket ○ 50 W flood light ○ Screws ○ Sign ○ Battery ○ Adjustable or 6mm set spanner. ○ Sim pin...

  • Page 6: Attach The Floodlight

    Spectur Guide for HD5 Installation Attach the Floodlight Step 1: Unscrew the nuts at the bottom of the Main camera box. Remove the two M6 washers and M6 spring washers. Place the floodlight bracket over the bolt, ensuring that the white cable is at the bottom of the flood light.

  • Page 7: Installing The Antennas

    Spectur Guide for HD5 Installation Installing the Antennas Step 1: Open the Main camera box using the provided key and remove the two antennas from the box. Step 2: Screw the two antennas to the two SMA plugs above the speaker being careful not to overtighten.

  • Page 8: Installing A Sim Card In The Spectur Modem

    Installing a SIM card in the Spectur Modem Below are instructions for installing your own SIM card. Note that if you have purchased a Spectur SIM plan, the SIM card will be pre-installed, and you can skip this section. Step 1: Using a SIM pin open the SIM card tray in the Spectur Modem.

  • Page 9: Step 2

    Spectur Guide for HD5 Installation Step 2: Place the SIM card in the SIM card tray aligning the corner notch as shown. Reinsert the tray, taking care that the SIM is facing down, or else the modem will not be able to read the SIM.

  • Page 10: Step 2

    Spectur Guide for HD5 Installation Step 2: The solar panel will have three sets of bolts on each side. Do not remove the bubble wrap from the panel just yet. Step 3: Note the marked holes on the panel arm, we will be using these holes to connect the panel and solar bracket.

  • Page 11: Step 4

    Spectur Guide for HD5 Installation Step 4: Using the M6x20 bolts and washers provided, connect the arms to the solar bracket. Do not tighten the bolts, this will be done later. Note how the washers and spring washers are used. The spring washer is in between the flat washer and the nut. Once you have put in all the screws, use an M6 ratchet and spanner (not supplied) to tighten the nuts.

  • Page 12: In-Ground

    Spectur Guide for HD5 Installation In-ground What you Need: Step 1: Using a post-hole digger, dig a 700 mm deep hole and insert the Bottom pole. The bottom pole is the ○ Post-hole digger ○ 2 or 3 x 20 kg kwikset concrete ○...

  • Page 13: Step 2

    Spectur Guide for HD5 Installation Step 2: Check that the front of the pole is facing in the direction of the area you wish to monitor. To ensure this, align the pole such that the two top bolt holes (these...

  • Page 14: Step 4

    Spectur Guide for HD5 Installation concrete is consistently wet. Shovel dirt on top of the concrete to flatten out the area and to cover the concrete. Step 4: Wait 10 – 15 minutes for the concrete to set before proceeding to the Winch Vertical Pole section.

  • Page 15: Step 2

    Spectur Guide for HD5 Installation Step 2: Slide the mounting pole between the winch and the base pole. Secure the mounting pole with the winch cable by hooking it underneath the pole as shown. Step 3: Attach the mounting bracket to the mounting pole by securing it with 8 tec screws as shown ensuring that it is vertical.

  • Page 16: Step 5

    Spectur Guide for HD5 Installation Step 5: Rotate the cameras box to the correct view, and then lock in place by using two M6x30 bolts in the bottom bracket. Each M6 bolt should be inserted from the top and have an M6 spring washer, followed by an M6 washer.

  • Page 17: Step 7

    Step 9: Open the system and check the view of the camera by using the Spectur admin web interface. To change the view of the camera gently adjust the cameras position. When done checking and configuring the camera view close the camera box and lock it with the provided key.

  • Page 18: Step 11

    Spectur Guide for HD5 Installation Step 10: Confirm the PIR has been configured properly and is able to detect motion in front of it. To check this, activate the system and walk past the system. The flood light should turn on. To configure the PIR, remove the cover by unscrewing the Philips screw at the bottom and lifting the cover off.

  • Page 19: Step 12

    Remove the winch by loosening the cable, detaching the hook, and then removing the bolts fastening it to the pole. Step 13: Using 2 tec screws attach the Spectur sign to the pole, such that it faces in the same direction as the camera. Step 14: Attach the post sign wrap by removing the rectangular cut outs from the sign.

  • Page 20: Step 10

    Spectur Guide for HD5 Installation Other Base Options Mobile Base installation Commented [GP2]: Put these sections below winch section. That is, finish one compete install and then talk about other base options What you need: ○ 2 x sheet metal covers.

  • Page 21: Step 2

    Spectur Guide for HD5 Installation Step 2: Load 20 bags of sand into the frame, this will provide an additional 400 kg of mass to keep the base stable. Step 3: Cover the inside of the base with the two sheet metal covers provided, ensure that the holes on the corners of the sheet line up with the holes on the frame’s corners.

  • Page 22: Step 4

    Spectur Guide for HD5 Installation Step 4: Commented [GP6]: Maybe some circled elements in photo with notes Using 4 M15 washers and 4 M15x30 bolts (blue), secure the frame at each corner as shown below. Secure the two pole supports with 2 M15x25 bolts and 2 M15 nuts.

  • Page 23: Trailer Installation

    Spectur Guide for HD5 Installation Trailer installation Step 1: Commented [GP7]: Add marked up Pictures When in the desired location, lower legs on the trailer by pulling the blue handle towards yourself. Once in position push the handle back into place. Proceed to conduct the mobile base installation.

  • Page 24: Non-Standard Installation

    Suggest add this to HD5 manual as well Step 1: Using a phone or computer login into the Spectur admin portal (Installer) or into the web interface or app (customer, refer to web or app guide). For the installer search for the camera by typing in its MAC number in the search bar.

  • Page 25: Leaving Sites Orderly

    Spectur Guide for HD5 Installation Leaving sites orderly Step 1: When removing a system from site, completely fill in the hole and smooth out any mounds. If doing an install, shovel dug up dirt on top of the concrete and then flatten the mound.

  • Page 26: How To Ensure Customers Know How To Use Services And Get Assistance

    Spectur Guide for HD5 Installation How to ensure customers know how to use services and get assistance Step 1: Go through with the customer how to use the app and web interface. Information regarding the use of these platforms can be found in the user manuals of each respective platform.
