Spectur HD5 Assembly Manual

Hide thumbs Also See for HD5:
Table of Contents

Advertisement

Quick Links

Download this manual
HD5 Assembly Guide
Document No.
OPSMN011
OPSMN011
OPSMN011
Author
M Dyson
M Dyson
M Dyson
Revision
1
2
3
Review Date
6/12/21
22/01/22
29/06/22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD5 and is the answer not in the manual?

Questions and answers

Related Manuals for Spectur HD5

Summary of Contents for Spectur HD5

  • Page 1 HD5 Assembly Guide Document No. Author Revision Review Date OPSMN011 M Dyson 6/12/21 OPSMN011 M Dyson 22/01/22 OPSMN011 M Dyson 29/06/22...

  • Page 2: Table Of Contents

    Guide for HD5 Assembly Contents Top Cover Assembly ..........................4 Materials:............................4 Step 1: ..............................4 Step 2: ..............................5 Step 3: ..............................5 Step 4: ..............................6 Step 5: ..............................6 Bottom Cover assembly ......................... 7 Materials:............................7 Step 1: ..............................7 Step 2: ..............................
  • Page 3 Guide for HD5 Assembly Materials:............................18 Step 1: ............................... 19 Step 2: ............................... 19 Step 3: ............................... 20 Step 4: ............................... 21 Step 6: ............................... 21 Step 7: ............................... 22 Step 8: ............................... 23 Step 9: ............................... 24 Step 10: ............................. 24 Step 11: .............................

  • Page 4: Top Cover Assembly

    Guide for HD5 Assembly Top Cover Assembly Materials: Item Quantity M24 Washers M24 Nuts M4x10 Bolt Door Cover Brass solar gland Solar Gland Solar Plug Nut Clip Top Cover Step 1: With the thread on top, screw the Brass solar gland into the top of the cover.

  • Page 5: Step 2

    Guide for HD5 Assembly Step 2: Secure on both sides with 2 M24 washers and 2 M24 Nuts. And add nut clip Step 3: Using 4 M4x10 bolts to attach the Door cover. Tighten until firm. OPSMN011 Rev 3 Dated: 29.06.2022...

  • Page 6: Step 4

    Guide for HD5 Assembly Step 4: Using the solar plug and the solar gland. Remove the nut from the bottom of the plug securer and place it over the solar plug as shown in the image below. The nut can be discarded, it has no use.

  • Page 7: Bottom Cover Assembly

    Guide for HD5 Assembly Bottom Cover assembly Materials: Item Quantity M4x10 Bolt M6x20 Bolt M6 Spring Washer M6 Nut M6 Washer Battery Base Bottom Cover Type 4 gland 4pinh female chassis plug Base grill Step 1: Secure the Base Grill using 4 M4x10 bolts.

  • Page 8: Step 2

    Guide for HD5 Assembly Step 2: Bolt the two M6x25 bolts into the bottom cover. On the other side place a M8 washer, M6 spring washer, then a M6 nut. Step 3: Place the glands as shown below and secure with the previously removed nuts. Attach the 4 pin female chassis plug such that the plug is on the outside of the cover.

  • Page 9: Solar Assembly

    Guide for HD5 Assembly Solar Assembly Materials: Item Quantity Solar Bracket Solar Charge Controller M4x6 Bolts O-droid Step 1: Attach the Solar charge controller to the Router bracket using 4 M4x6 bolts. It should be oriented as shown below. OPSMN011 Rev 3 Dated: 29.06.2022...

  • Page 10: Step 2

    Guide for HD5 Assembly Step 2: Attach the O-droid board by removing the washers at the bottom of the board, lining up the bolts as shown below and tightening them. OPSMN011 Rev 3 Dated: 29.06.2022...

  • Page 11: Router Assembly

    Guide for HD5 Assembly Router assembly Materials: Item Quantity Spectur Camera (4k or 3.4mp) Router Bracket Wifi Antenna Mobile antenna Router – Teltonika RUT240 M4x20 Bolt M4x10 Bolt M4 nut – 4k camera only 4k camera mount—4K camera only M6x10 Button head SOC screw...

  • Page 12: Step 1

    Step 2: Attach the Spectur camera to the front of the Router bracket with an M4x20 bolt through both the bracket and the camera base. This process is the same for both 3.4mp and 4k cameras. For the 4k Camera there will be a usb-a to usb-c cable that connects the camera to the watchdog.

  • Page 13: Door Assembly

    Guide for HD5 Assembly For The 4k camera attach the camera to the camera mount using the M6x10 SOC button head screw. Then feed the M4x10 bolt through the frame and secure on the other side with a M4 nut.

  • Page 14: Step 1

    Guide for HD5 Assembly Door Frame Window M4x6 bolt Visor Sticker Lock 4.5mm Grommet PIR Cover M4x10 bolt Zip-tie Cable management adhesive Step 1: Using 8 M4x6 bolts attach the window to the back of door frame as shown below.

  • Page 15: Step 3

    Use a squeegee to get any bubbles out from under the sticker. Step 4: Apply the Spectur logo sticker to the front of the system as shown below. Ensure hands are clean when applying this sticker as fingerprints and dirt will be visible on the sticker if they are not.

  • Page 16: Step 5

    Guide for HD5 Assembly Step 5: Using 3 M4x10 bolts attach the PIR to the front of the door; it will be necessary to make a hole in the sticker where it covers the hole. Before placing the cover on the PIR ensure that the PIR is facing forward and it is angled 45 degrees, pointing down.
  • Page 17 Guide for HD5 Assembly Step 7: Place the other stickers on the back of the door as shown below. Remove bubbles with the squeegee. Step 8: Attach the lock to the door. To attach remove the nut from the bottom of the lock, insert the lock through the hole, then replace the nut.

  • Page 18: Full Assembly

    Guide for HD5 Assembly Full Assembly Materials: Item Quantity M4x10 Bolt Zip-tie Mobile extension cable Ethernet cable 5mm Grommet Router power cable Battery cable Mounting Bracket M4x12 Bolt Solar Assembly cable management adhesives Door Assembly M6x10 Bolts Load Cable 10-way plug...
  • Page 19 Guide for HD5 Assembly Step 1: Line up the Solar Assembly such that it is in line with the four holes on each side. Then attach the hinge with 2 M4x10 bolts. Step 2: Using 8 M4x10 bolts, secure the Solar assembly on both sides with 4 bolts.
  • Page 20 Guide for HD5 Assembly Step 3: Attach 8 cable management adhesives to the inside of the camera box frame as shown below. OPSMN011 Rev 3 Dated: 29.06.2022...
  • Page 21 Guide for HD5 Assembly Step 4: Insert zip-ties into the cable management adhesives for future use. Step 6: Attach the two mobile extension cables to the side of the box by removing the washers and replacing them on the other side. Then, using a zip-tie, zip-tie the two extension cables together and tuck them to the side of the O-droid board.
  • Page 22 Guide for HD5 Assembly Step 7: Attach the ethernet cable to the O-droid board and arrange as shown below. OPSMN011 Rev 3 Dated: 29.06.2022...
  • Page 23 Guide for HD5 Assembly Step 8: Open the door assembly kit. It should contain 8 bolts and the mounts for the door. To attach the door first attach the mounts with the pole sticking out. Both should be facing towards the centre.
  • Page 24 Guide for HD5 Assembly Step 9: Attach the bottom cover using 4 M4x10 bolts. The cover should be inside the frame and should be as shown below. Attach the door stop (Shown in the right image) using 2 M4x12 bolts.
  • Page 25 Guide for HD5 Assembly Step 11: On the right-hand side of the system place a grommet as shown below. Then proceed to attach the speaker using 3 M6x10 bolts as shown below. Insert the speaker cable through the grommet. Step 12:...
  • Page 26 Guide for HD5 Assembly Step 13: Cut router power cable to a metre in length. Then strip off the coverings of both wires. Then connect it to the teltonika. Step 14: Attach the mobile extension cable to the router as shown below and the patch cable and power cable.
  • Page 27 Guide for HD5 Assembly Step 16: Zip-tie the Ethernet, router power, camera usb, and mobile extension cables. Plug the ethernet into the router and the O-droid board then plug the blue usb cable into the o-droid board. Step 17: Attach the load cable to the solar charge controller as shown below.
  • Page 28 Guide for HD5 Assembly Step 18: 1. Solder together the red cables of the router power cable and the PIR cable. 2. Solder together the blue cable from the floodlight power cable and the black cable from the PIR. 3. Solder together the black cable from the router power cable and the black cable from the load cable.
  • Page 29 Guide for HD5 Assembly 2. Insert the blue cable from the flood light power cable and the black cable from the PIR in slot 3. These will be soldered together from the previous step. 3. insert the red cable from the flood light power cable into slot 5.
  • Page 30 Guide for HD5 Assembly Step 20: Attach the battery cable to the solar charge controller. The red cable should go in the 3 slot, while the black is in the 4 . The order matters due to polarity. OPSMN011 Rev 3...
  • Page 31 Guide for HD5 Assembly Step 21: Attach the top to the system with 14 M4x10 bolts (4 on the front and back, 3 on each of the sides). Step 22: Attach the solar panel cable to the solar charge controller, as shown below.
  • Page 32 Blue is for M6x10, red is for M6x12. Step 24: Apply the “Made in Australia” sticker on the left side of the box. With the completion of this step the HD5 system assembly is complete. OPSMN011 Rev 3 Dated: 29.06.2022...
  • Page 33 Guide for HD5 Assembly OPSMN011 Rev 3 Dated: 29.06.2022...
